314

4-5. Using the driving support systems

Press

/

 of the meter con-

trol switches, select

.

Press

/

 of the meter con-

trol switches, select

.

Press

 of the meter con-

trol switch.

Each time

 is pressed, the function changes on/off.

When on, the indicator light comes on to inform the driver that the sys-
tem is operational.

Intuitive parking assist

∗

∗

: If equipped

The distance from your vehicle to nearby obstacles when paral-
lel parking or maneuvering into a garage is measured by the
sensors and communicated via the displays and a buzzer.
Always check the surrounding area when using this system.

Types of sensors

1
2
3
4

Turning the intuitive parking assist on/off

1

2

3

315

4-5. Using the driving support systems

4

Drivin

g

■

Multi-information display

Front corner sensor opera-
tion
Front center sensor opera-
tion
Rear corner sensor operation
Rear center sensor operation
Select to mute the buzzer
sounds.

■

Audio system screen

Intuitive parking assist
When the vehicle is moving
backward.

A simplified image is displayed
on the upper part of the screen
when an obstacle is detected.

■

Muting the buzzer sound

●

To mute the buzzer sound
The buzzer can be temporarily muted by pressing

 of the meter con-

trol switches while an obstacle detection display is shown on the multi-infor-

mation display.

●

To cancel the mute
Mute will be automatically cancelled in the following situations.
• When the shift position is changed

• When the vehicle speed has reached or exceeded approximately 6 mph

(10 km/h) with the shift lever in D

• When the intuitive parking assist is turned off once and turned on again

Vehicles without a smart key system:
• When the engine switch is turned off once and turned to “ON” position

again

Vehicles with a smart key system:
• When the engine switch is turned off once and turned to IGNITION ON

mode again

• When a sensor is malfunctioning

Display

1

2

3
4
5

1

316

4-5. Using the driving support systems

Distance display
Sensors that detect an obstacle will illuminate continuously or blink.

*

: The images may differ from those shown in the illustrations. (

→P. 315)

Sensor detection display, obstacle distance

Multi-

informa-

tion dis-

play

*

Insert display

Approximate distance to obstacle

Toyota

parking

assist

monitor

Pan-

oramic

view mon-

itor

Front and rear

center sensor

Front and rear

corner sensor

(continu-

ous)

(blinking

slowly)

(blinking

slowly)

Far

Near

Front center
sensor:
3.3 ft. (100 cm)
to
2.0 ft. (60 cm)
Rear center
sensor:
4.9 ft. (150 cm)
to
2.0 ft. (60 cm)

⎯

(continu-

ous)

(blinking)

(blinking)

2.0 ft. (60 cm)
to
1.5 ft. (45 cm)

2.0 ft. (60 cm)
to
1.5 ft. (45 cm)

(continu-

ous)

(blinking

rapidly)

(blinking

rapidly)

1.5 ft. (45 cm)
to
1.2 ft. (35 cm)

1.5 ft. (45 cm)
to
1.2 ft. (35 cm)

(blinking)

(continu-

ous)

(continu-

ous)

Less than
1.2 ft. (35 cm)

Less than
1.2 ft. (35 cm)

317

4-5. Using the driving support systems

4

Drivin

g

Buzzer operation and distance to an obstacle
A buzzer sounds when the sensors are operating.
● The buzzer sounds faster as the vehicle approaches an obstacle.

When the vehicle comes within the following distance of the
obstacle, the buzzer sounds continuously: Approximately 1.2 ft.
(35 cm).

● When 2 or more obstacles are detected simultaneously, the

buzzer system responds to the nearest obstacle. If one or both
come within the above distances, the beep will repeat a long
tone, followed by fast beeps.

Approximately 3.3 ft. (100 cm)
Approximately 4.9 ft. (150 cm)
Approximately 2.0 ft. (60 cm)

The diagram shows the detection
range of the sensors. Note that the
sensors cannot detect obstacles
that are extremely close to the
vehicle.
The range of the sensors may
change depending on the shape of
the object, etc.

Detection range of the sensors

1
2
3
