Toyota Camry (2018 year). Manual - part 42

178

3-5. Opening and closing the windows

Slide and hold the

 switch

backward. The electronic sun-
shade will fully open automati-
cally.

*

Closes the electronic sunshade

Slide and hold the

 switch for-

ward. The electronic sunshade will
fully close automatically.

*

*

: Quickly slide and release the

 switch in either direction to stop the

electronic sunshade partway.

Tilts the panoramic moon roof up
(press)

*

When the panoramic moon roof is
tilted up, the electronic sunshade
will open to the half-open position
of the roof.

*

: Lightly press the

 switch

again to stop the panoramic moon
roof partway.

Tilts the panoramic moon roof down (press and hold)

The panoramic moon roof can be tilted down only when it is in the tilt-up
position.

Panoramic moon roof

∗

∗

: If equipped

Use the overhead switches to operate the panoramic moon roof
and electronic sunshade.

Opening and closing the electronic sunshade

1

2

Tilting the panoramic moon roof up and down

179

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

*

Slide and hold the

 switch

backward. The panoramic moon
roof and electronic sunshade will
open automatically.

The panoramic moon roof can be
opened from the tilt-up position.

*

: Quickly slide and release the

switch in either direction to stop the
panoramic moon roof partway.

Closes the panoramic moon roof
Slide and hold the

 switch

forward. The panoramic moon
roof will fully close automatically.

■

The panoramic moon roof can be operated when
The engine switch is in IGNITION ON mode.

■

Operating the panoramic moon roof after turning the engine off
The panoramic moon roof and electronic sunshade can be operated for
approximately 45 seconds after the engine switch is turned to ACCESSORY
mode or turned off. They cannot, however, be operated once either front door
is opened.

■

Jam protection function
If an object is detected between the panoramic moon roof and the frame in
the following situations, travel is stopped and the panoramic moon roof opens
slightly:

●

The panoramic moon roof is closing or tilting down.

●

The electronic sunshade is closing.

■

Door lock linked panoramic moon roof operation

●

The panoramic moon roof can be opened and closed using the mechanical
key.

*

(

→P. 526)

●

The panoramic moon roof can be opened using the wireless remote con-
trol.

*

(

→P. 136)

*

: These settings must be customized at your Toyota dealer.

Opening and closing the panoramic moon roof

180

3-5. Opening and closing the windows

Closing both the panoramic moon roof and electronic sunshade
Slide the



switch forward.

The electronic sunshade will close to the half-open position and pause. The
panoramic moon roof will then fully close. Then the electronic sunshade will
fully close.

■

When the panoramic moon roof or electronic sunshade does not close
normally
Perform the following procedure:

Stop the vehicle.
Turn the engine switch to IGNITION ON mode.
Slide and hold the

 switch or

 switch forward. Continue pressing

the switch for approximately 10 seconds after the panoramic moon roof or
electronic sunshade closes and reopens. The panoramic moon roof and
electronic sunshade will start to close.

*

Check that the panoramic moon roof and electronic sunshade are fully
closed and release the switch.

*

: If the switch is released at the incorrect time, the procedure will have to be

performed again from the beginning.

If the panoramic moon roof or electronic sunshade does not fully close even
after performing the above procedure correctly, have the vehicle inspected by
your Toyota dealer.

■

Alarm
The alarm may be triggered if the alarm is set and the panoramic moon roof is
closed using the door lock linked panoramic moon roof operation function.
(

→P. 75)

■

Panoramic moon roof open warning buzzer
A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the panoramic moon roof open.

■

Customization
Some functions can be customized. (

→P. 567)

1

2

3

4

181

3-5. Opening and closing the windows

3

Op
eration

 o

f each

 compo

nen
t

Observe the following precautions.
Failing to do so may cause death or serious injury.

■

Opening and closing the electronic sunshade

■

Opening and closing the panoramic moon roof

●

The driver is responsible for panoramic moon roof opening and closing
operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the panoramic moon roof. It is possible for children and other
passengers to have body parts caught in the panoramic moon roof.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the electronic sunshade is being oper-
ated.

●

Do not let a child operate the electronic
sunshade. Closing the electronic sun-
shade on someone can cause death or
serious injury.

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the panoramic moon roof is being oper-
ated.

●

When using the wireless remote control
or mechanical key and operating the
panoramic moon roof, operate the pan-
oramic moon roof after checking to
make sure that there is no possibility of
any passenger having any of their body
parts caught in the panoramic moon
roof. Also, do not let a child operate
panoramic moon roof by the wireless
remote control or mechanical key. It is
possible for children and other passen-
gers to get caught in the panoramic
moon roof.
