58

1-2. Child safety

■

When using a child restraint system

●

When a booster seat is installed, always ensure that the shoulder belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder.

●

Use child restraint system suitable to the age and size of the child and
install it to the rear seat.

●

If the driver’s seat interferes with the
child restraint system and prevents it
from being attached correctly, attach the
child restraint system to the right-hand
rear seat.

●

Adjust the front passenger seat so that
it does not interfere with the child
restraint system.

59

1-2. Child safety

1

Fo
r

safety and securi

ty

◆

Installing child restraint system using a seat belt (child
restraint lock function belt)

Install the child restraint system in accordance to the operation
manual enclosed with the child restraint system.

■

Rear-facing — Infant seat/convertible seat

Place the child restraint sys-
tem on the rear seat facing
the rear of the vehicle.

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

Child restraint system fixed with a seat belt

1

2

3

60

1-2. Child safety

While pushing the child
restraint system down into
the rear seat, allow the
shoulder belt to retract until
the child restraint system is
securely in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

After installing the child restraint system, rock it back and forth to
ensure that it is installed securely. (

→P. 64)

■

Forward-facing — Convertible seat

When using the front passenger seat: Adjust the seatback
If installing the child restraint system to the front passenger seat
is unavoidable, refer to P. 56 for the front passenger seat adjust-
ment.
If the head restraint interferes
with the child restraint sys-
tem installation and the head
restraint can be removed,
remove the head restraint.
(

→P. 162)

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

4

5

1

2

3

61

1-2. Child safety

1

Fo
r

safety and securi

ty

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child
restraint system into the rear
seat, allow the shoulder belt
to retract until the child
restraint system is securely
in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

If the child restraint has a top tether strap, follow the child
restraint manufacturer’s operation manual regarding the installa-
tion, using the top tether strap to latch onto the top tether strap
anchor. (

→P. 68)

After installing the child restraint system, rock it back and forth to
ensure that it is installed securely. (

→P. 64)

4

5

6

7

8
