OTHER CONTROLS AND EQUIPMENT

Problem

Possible cause

Possible solution

MP3/WMA

No playback

The disc has unplayable formatted data.

Check the file format.

Playing VBR (Variable Bit Rate) files may

Sound skipping or noise

Play Non-VBR files.

cause sound skipping.

USB

There is no music stored in a format that

Check the file format.

Music is not played back even if the USB

is supported on this unit.

device is connected

The current consumption of the USB

Use a USB device with a current con-

device exceeds 500 mA.

sumption lower than 500 mA.

Bluetooth^®

The distance between this unit and the

Bluetooth^®-ready device is too long, or

Change the location of the Bluetooth^®-

the Bluetooth^®-ready device is hidden

ready device.

behind a metallic object from this unit.

Pairing failed

Refer to the Operating Instructions of the

The Bluetooth^® function of the Bluetooth^®-

Bluetooth^®-ready device. (With regard to

ready device is deactivated.

some devices, the power saving mode is

activated after a certain time.)

Drive your car to the service area of your

Cannot receive a call.

Your mobile phone is out of service area.

mobile phone.

The voice quality of

hands-free is

low

There is another wireless device near the

Switch off the wireless device or keep it

(Distortion, noise etc.).

unit.

away from the unit.

5-69

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Error Display Messages

Display

Possible cause

Possible solution

Ck Antenna

XM antenna unconnected.

Connect the XM antenna.

XM broadcasts unreceivable because of

Move to an area where XM broadcasts can be received

No Signal

poor receiving conditions.

well.

This channel is not currently in service. Tune to another

Ch Off Air

Channel not in service.

channel.

Ch Unavail

Channel unavailable.

This channel is out of service. Tune to another channel.

Ch Unauth

Channel unauthorized.

This channel is not authorized. Tune to another channel.

5-70

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Display

Possible cause

Possible solution

Insert the disc with its label side up.

Check the disc that it is not warped and is free of flaws.

ERROR 1

The disc cannot be read.

If ERROR 1 does not go out when a normal disc is

inserted, consult your dealer.

If CD is inserted in the unit, press the CD eject button to

The player developed an error of an uni-

ERROR 3

remove the disc.

dentified cause.

If the disc cannot be ejected, consult your dealer.

USB/iPod^®

Unplug the USB device and plug it again.

ERROR 1

No operation by some cause.

If ERROR 1 does not go out when a normal disc is

inserted, consult your dealer.

ERROR 3

The USB device is disconnected.

Check the connection of the USB device.

The current consumption of the USB

ERROR 4

Check the USB device.

device exceeds 500 mA.

5-71

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Display

Possible cause

Possible solution

Bluetooth^®

Disconnect the Bluetooth^®-ready device and connect it

The player developed an error of an uni-

ERROR 1

again.

dentified cause.

If ERROR 1 does not go out, consult your dealer.

Failed

Failed to establish pairing

Try to establish the pairing again.

Reaching the upper limit of the register-

Delete the registered data of unnecessary devices and

Memory Full

able device count

try to establish the pairing again.

Not Avail.

Inoperable during driving

Operate the system after pulling over your car.

Pardon?

Failed voice recognition

Press the Talk button and say what you said again.

Not Linked

Telephone disconnected

Try to establish the pairing again.

5-72

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Fuel Filler Door

The fuel filler door (3) is located on the left

rear side of the vehicle. To access the fuel

filler cap, the fuel filler door must be

(1)

(2)

opened by unlocking it using the power

door locking switch (1), keyless start sys-

(3)

tem remote controller, request switch, or

(4)

key and then pushing the fuel filler door (3)

(2)

at the location indicated by the arrow.

If the fuel filler door fails to open

If the fuel filler door fails to open due to a

problem in the system or a flat battery,

have the vehicle inspected by an autho-

rized SUZUKI dealer. If you must open the

door immediately, do the following.

57L51056

57L51054

Pull the rod (2) toward you. The fuel filler

(2) Unlock

door will be unlocked.

Push the rod inward to lock the door.

(1)

(3) Unlock

(4) Lock

(3)

57L51055

Remove the trim (1) inside the trunk.

57L51058

5-73

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Fuel Filler Cap

EXAMPLE

(5)

(1)

(2)

Open

57L51057

57L51019

From the outside, push the part indicated

79K053

NOTE:

by the arrow of the fuel filler door (5) (see

The cap holder (1) can hold the fuel filler

To remove the fuel filler cap:

the illustration). The door will open slightly.

cap (2) when refueling.

1) Open the fuel filler door.

2) Remove the cap by turning it counter-

To reinstall the fuel filler cap:

clockwise.

1) Turn the cap clockwise until you hear

several clicks.

WARNING

2) Close the fuel filler door.

Remove the fuel filler cap slowly. The

fuel may be under pressure and may

WARNING

spray out, causing injury.

Fuel is extremely flammable. Do not

smoke when refueling, and make

sure there are no open flames or

sparks in the area.

5-74

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Engine Hood

WARNING

•

Avoid spilling fuel. Any spilt fuel

must be wiped clean with a soft

(1)

cloth. Leaving the fuel as is could

lead to a fire or other unexpected

(2)

accident. Fuel will also cause

spots, discoloration or cracks on

the paintwork in the area.

•

Close the fuel filler cap firmly after

refueling. A loose cap may cause

fuel leakage and eventually a fire.

•

If you need to replace the fuel cap,

use a genuine SUZUKI cap. Use of

57L51066

an improper cap can result in a

57L51020

Push the under-hood release lever (2)

malfunction of the fuel system or

emission control system. It may

sideways with your finger, as shown in

To open the engine hood:

the illustration. While pushing the lever,

also result in fuel leakage in the

1) Pull the hood release

handle

(1)

event of an accident.

lift up the engine hood.

located on the outboard

side of the

driver’s side of the instrument panel.

This will disengage the engine hood

lock halfway.

5-75

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

To close the engine hood:

1) Lift the hood up slightly and remove the

WARNING

prop rod from the hole (5). Put the prop

Make sure the hood is fully closed

rod back to the holding clip (4).

(5)

and latched before driving. If it is not,

2) Lower the hood close to the bumper,

it can fly up unexpectedly during

then let it drop down. Make sure the

(3)

driving, obstructing your view and

hood is securely latched after closing.

resulting in an accident.

(4)

57L50015

3) Continue to lift up the hood until it is

high enough to support with the prop

rod (3).

5-76

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Sun Visor

CAUTION

When unhooking and hooking a sun

Do not leave cards or similar plastic

visor, be sure to handle it by the hard

objects in the ticket holder when

(1)

(2)

plastic parts or the sun visor can be

parking under the sun. The cabin

damaged.

temperature may rise high enough to

cause the plastic objects to crack or

Both the driver’s and passenger’s sun

deform.

visors have a ticket holder on the side fac-

ing the interior when they are pulled down.

The ticket holder is on the vanity mirror

cover.

(3)

(4)

57L50032

(1) Hook

(2) Vanity mirror cover

(3) Ticket holder

(4) Extension

The sun visors can be pulled down to block

glare coming through the windshield, or

they can be unhooked and turned to the

side to block glare coming through the side

window.

The extension (4) can be drawn out to

block glare widely.

5-77

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Interior Light Switch

ON (1)

The light comes on and stays on regard-

EXAMPLE

Front

less of whether the door is open or closed.

DOOR (2)

(3)

(1)

The light comes on when the door is

(2)

opened. After closing all doors, the light

will remain on for about 15 seconds and

then fade out. If you press the engine

switch to change the ignition mode to

“ACC” or “ON” during this time, the light will

start to fade out immediately. If you change

the ignition mode to

“LOCK” (OFF) by

pressing the engine switch, the light will

remain on for about 15 seconds and then

79J075

go out.

NOTE:

57L51021

OFF (3)

The number of doors involved in the light-

Rear

The light remains off even when the door is

ing operation of the interior light depends

opened.

on the vehicle specification. If there is a

switch

(rubber projection) at the door

(3)

(1)

NOTE:

(2)

opening as shown, the door is involved in

If the rear interior light switch is set to

the lighting operation. The trunk lid is not

“DOOR”, the light is turned on or off at the

involved in this operation.

same time the front interior light is turned

on or off.

57L51022

The interior light switch has three posi-

tions, which functions as described below.

5-78

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Courtesy Lights

Footwell Lights

Trunk Light

(1)

57L51023

57L51024

57L50019

Each front door has a courtesy light (1) on

A footwell light is provided in the leg space

When you open the trunk lid, the trunk light

its inside bottom. It lights automatically

in front of each front seat. When a front

comes on and remains on as long as you

when the door is opened.

door is opened, the footwell light on the

keep the lid open.

same side lights automatically.

CAUTION

Do not leave the trunk lid open for a

long time, or the battery will dis-

charge.

5-79

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Spot Light

Accessory Socket

The accessory socket will work when the

ignition mode is changed to “ACC” or “ON”

Lidded Instrument Panel Box

by pressing the engine switch.

(1)

12-volt accessory sockets are located both

on the center console and on the lidded

instrument panel box.

Each socket can be used to provide 12

volt/120 watt power for electrical accesso-

ries when used alone. Make sure that the

cap remains on the socket when the socket

is not in use.

CAUTION

•

To prevent the fuse from being

blown, when using sockets at the

57L51048

same time, do not exceed the total

Push the switch (1) to turn on the light and

57L51025

combined power capacity of 120

push it again to turn off the light.

watts.

Center Console Box

•

Use of inappropriate electrical

accessories can cause damage to

your vehicle’s electrical system.

Make sure that any electrical acces-

sories you use are designed to

plug into this type of socket.

•

When an electric device is con-

nected to the accessory socket,

close the lid carefully so as not to

damage the device or lid.

57L51062

5-80

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Universal Serial Bus (USB) Socket

Cigarette Lighter (if equipped)

CAUTION

To avoid damage to the cigarette

lighter socket, do not use it as an

accessory power source. Some

accessories’ power plug can damage

the inner mechanism of the cigarette

lighter socket.

57L51061

57L51068

Connect your portable digital music player,

The cigarette lighter will work when you

etc. to this socket to enjoy music through

press the engine switch to change the igni-

the vehicle’s audio system using it as a

tion mode to “ACC” or “ON”.

source. Refer to “Audio Systems” in the

To use the cigarette lighter, push it all the

“OTHER CONTROL AND EQUIPMENT”

way into the receptacle and release it. It

section.

will automatically heat up and will pop out

to its normal position when it is ready for

CAUTION

use.

If you close the lid of the lidded

instrument panel box with a device

CAUTION

still connected to the USB socket, the

Holding the cigarette lighter in can

equipment and the socket may be

overheat and damage the lighter.

damaged.

Release the lighter after you push it

in.

5-81

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Ashtray (if equipped)

Assist Grips

57L51065

79J047

54G249

You can fit the ashtray into any of the cup

CAUTION

Assist grips are provided for convenience.

holders on the center console.

When fitting the ashtray into a cup

holder on the center console, orient it

CAUTION

WARNING

as shown in the illustration. Doing

To avoid damaging the assist grip

Make sure tobacco is fully extin-

otherwise may damage the ashtray

and the molded roof lining, do not

guished before closing the ashtrays.

and/or the center console.

hang down the assist grip.

Never throw waste in the ashtrays: it

could create a fire hazard.

5-82

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Coat Hooks

Sunroof (if equipped)

You can tilt or slide the sunroof by operat-

ing the “TILT” part of the sunroof switch or

the “SLIDE” part of the sunroof switch after

pressing the engine switch to change the

ignition mode to “ON”.

There is a system to prevent being pinched

(2)

by the sunroof.

When the system senses that something is

pinched when the sunroof is sliding for-

ward, the sunroof will automatically reverse

(1)

direction and slide rearward. This system

will operate when the sunroof is closing

automatically. This system does not oper-

57L51026

ate when tilting the sunroof down.

57L51049

To tilt the sunroof up, slide the sun shade

Make sure there are no hands or other

rearward by hand and push the “TILT UP”

You can hang clothing on the coat hooks.

obstructions in the path of the sunroof

part (1) of the sunroof switch. To tilt the

These hooks are not designed for large or

when you close the sunroof even though

sunroof down, push the “SLIDE OPEN”

heavy items.

there is a system to prevent being pinched

part (2) of the sunroof switch.

by the sunroof.

If you push the switch for more than a sec-

WARNING

ond, the sunroof will automatically tilt up or

Your vehicle is equipped with side

WARNING

down fully. To stop the sunroof halfway,

curtain air bags, do not hang sharp

push the switch briefly.

items like a hanger on the coat hook.

• The system to prevent being

pinched by the sunroof does not

When hanging the clothes, hang it on

hook without using a hanger.

work in the area where the sunroof

is almost completely closed.

• The system to prevent being

pinched by the sunroof may not

work if the battery is not suffi-

ciently charged.

5-83

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

How to reactivate the system to prevent

being pinched by the sunroof

When you disconnect the negative (-) ter-

minal from the battery or change the fuses,

the features below will not operate.

• The system to prevent being pinched by

the sliding sunroof.

(2)

• The system to automatically open or

close the sunroof fully.

In this case, you must reactivate the fea-

(1)

tures using the following procedures.

1) Press the engine switch to change the

ignition mode to “ON”.

2) Push and hold the “TILT UP” part (1) of

57L51027

57L51028

the sunroof switch, the sunroof will tilt

To slide the sunroof rearward, push the

The sun shade will open manually and

up fully and then down slightly. After the

“SLIDE OPEN” part (2) of the sunroof

cannot be closed when the sunroof is slid

movement stops completely, release

switch. To slide the sunroof forward, push

rearward.

the switch. The features are reacti-

the

“TILT UP” part

(1) of the sunroof

vated.

switch.

3) Make sure you can open or close the

If you push the switch for more than a sec-

sunroof automatically by pushing the

ond, the sunroof will automatically slide

sunroof switch for more than about a

fully rearward or forward. To stop the sun-

second.

roof halfway, push the switch briefly.

5-84

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OTHER CONTROLS AND EQUIPMENT

Glove Box

CAUTION

Do not put your body weight on the

roof around the sunroof such as by

(1)

sitting on it.

• Be sure to close the sunroof when you

leave the vehicle unattended.

• Periodically inspect the guide rail for dirt

and clean it if any dirt has accumulated.

(2)

(3)

65D612

57L51029

WARNING

(2) Unlock

•

Never allow any part of your body

(3) Lock

such as hands or head to get out of

the sunroof opening while the vehi-

To open the glove box, pull the latch lever

cle is moving.

(1). To close it, push the lid until it latches

•

Be sure there are no hands or other

securely.

obstructions in the path of the sun-

To lock the glove box, insert the key

roof when you close the sunroof.

attached to your keyless start system

•

Always take the keyless start sys-

remote controller into the lock, turn the key

tem remote controller with you

fully clockwise, and pull it out of the lock in

when leaving the vehicle even if

this position.

only for a short time. Also do not

leave children alone in a parked

WARNING

vehicle. Unattended children could

Never drive with the glove box lid

use the sunroof switches and get

open. It could cause injury if an acci-

trapped by the sunroof.

dent occurs.

5-85

Suzuki Kizashi (2010 year). Manual - part 15
