Suzuki Grand Vitara (2010 year). Manual - part 18





-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSPECTION AND MAINTENANCE
Wiper Blades
For windshield wipers:
52D102
70G119
54G129
2)
Squeeze lock lever (1) towards wiper
1)
Hold the wiper arm away from the win-
arm (2) and remove the wiper frame
If the wiper blades become brittle or dam-
dow.
from the arm as shown.
aged, or make streaks when wiping,
replace the wiper blades.
To install new wiper blades, follow the pro-
cedures below.
CAUTION
To avoid scratching or breaking the
window, do not let the wiper arm
strike the window while replacing the
wiper blade.
NOTE:
Some wiper blades may be different from
the ones described here depending on
vehicle specifications. If so, consult your
SUZUKI dealer for proper replacement
method.
7-46
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSPECTION AND MAINTENANCE
Installation
60A260
52D124
52D125
3) Pull the locked end of the wiper blade
(3) Retainer
(4) Locked end
firmly to unlock the blade and slide the
blade out as shown.
4) If the new blade is provided without the
5) Install the new blade in the reverse
two metal retainers, move them from
order of removal, with the locked end
the old blade to the new one.
positioned toward the wiper arm. Make
sure the blade is properly retained by
all the hooks. Grasp the blade near the
locked end and pull in the direction of
the arrows to lock the end into place.
6) Reinstall wiper frame to arm, making
sure that the lock lever is snapped
securely into the arm.
7-47
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSPECTION AND MAINTENANCE
For rear wipers:
65D151
54G135
NOTE:
(1) Retainer
Do not flex the wiper blade frame end more
than necessary. If you do, it can break off.
4) If the new blade is provided without the
two metal retainers, move them from
the old blade to the new one.
5) Install the new blade in the reverse
order of removal.
Make sure the blade is properly
retained by all the hooks.
6) Reinstall wiper frame to arm in the
reverse order of removal.
80G146
1) Hold the wiper arm away from the win-
dow.
2) Remove the wiper frame from the arm
as shown.
3) Slide the blade out as shown.
7-48
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSPECTION AND MAINTENANCE
Windshield Washer Fluid
fluid tank. If the fluid level is near empty,
Air Conditioning System
refill it.
If you do not use the air conditioner for a
Front and rear (if equipped)
Use a good quality windshield washer
long period, such as during winter, it may
EXAMPLE
fluid, diluted with water as necessary.
not give the best performance when you
start using it again. To help maintain opti-
WARNING
mum performance and durability of your air
conditioner, it needs to be run periodically.
Do not use “anti-freeze” solution in
Operate the air conditioner at least once a
the windshield washer reservoir. This
month for one minute with the engine
can severely impair visibility when
idling. This circulates the refrigerant and oil
sprayed on the windshield, and also
and helps protect the internal components.
damage your vehicle’s paint.
CAUTION
(or opposite side)
Damage may result if the washer
66J008
motor is operated with no fluid in the
washer tank.
66J116
Check that there is washer fluid in the tank
by looking at the washer fluid level gauge
which is attached to the cap of the washer
7-49
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

EMERGENCY SERVICE
EMERGENCY SERVICE
Tire Changing Tool
8-1
Spare Tire Nut Lock (if equipped)
8-1
Jacking Instructions
8-2
Changing Wheels
8-3
Jump Starting Instructions
8-7
Towing a Disabled Vehicle
8-8
If the Starter Does Not Operate
8-8
If the Engine is Flooded
8-9
If the Engine Overheats
8-9
8
60G411
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Jacking Instructions: 5
EMERGENCY SERVICE
Tire Changing Tool
Spare Tire Nut Lock
WARNING
(if equipped)
After using the tire changing tools,
be sure to stow them securely, or
they could be thrown about in an
accident, causing injury.
To UNLOCK
To LOCK
64J124
The jack, wheel brace and jack handle are
64J172
stowed in the rear left corner of the lug-
A nut lock is used for the spare tire. To
gage compartment. Remove the cover to
unlock the spare tire nut, insert the ignition
access the tools.
key into the lock as far as the key will go
To remove the jack, turn its shaft counter-
and remove the lock with the key in. To lock
clockwise and pull the jack out of the stor-
the spare tire nut, put the lock on the nut
age bracket. To stow the jack, place it in
and push the lock in.
the storage bracket and turn the shaft
clockwise until the jack is securely held in
place.
WARNING
The tire changing tools should be
used only to change wheels. It is
important to read the jacking instruc-
tions in this section before attempt-
ing to use the jack.
8-1
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Jacking Instructions: 5
EMERGENCY SERVICE
Jacking Instructions
jack-head groove fits around the jacking
point beneath the vehicle body.
(3)
(1)
64J194
(2)
75F062
79K059
1) Place the vehicle on level, hard ground.
(2) Jack handle
2) Set the parking brake firmly and shift
(3) Wheel brace
into
“P” (Park) if your vehicle has an
automatic transmission, or shift into “R”
7) Continue to raise the jack slowly and
(Reverse) if your vehicle has a manual
(1)
smoothly until the tire clears the
transmission.
ground. Do not raise the vehicle more
3) Turn on the hazard warning flasher if
than necessary.
your vehicle is near traffic.
4) Block the front and rear of the wheel
diagonally opposite of the wheel being
lifted.
5) Place the spare wheel near the wheel
being lifted as shown in the illustration
79K058
in case that the jack slips.
(1) Jacking point
6) Position the jack as shown in the illus-
tration and raise the jack by turning the
8-2
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Jump Starting Instructions: 7
EMERGENCY SERVICE
Changing Wheels
WARNING
To change a wheel, use the following pro-
Use the jack only to change wheels
cedure:
on level, hard ground.
Never jack up the vehicle on an
To remove the spare wheel:
inclined surface.
1) Remove the jack and tools from the
(2)
Never raise the vehicle with the
vehicle.
jack in a location other than the
designated jacking point near the
wheel to be changed.
(A)
Make sure that the jack is raised at
least
51 mm (2 inches) before it
(1)
contacts the flange. Use of the jack
when it is within 51 mm (2 inches)
78K151
of being fully collapsed may result
3)
Unhook the under claws (1) and the
in failure of the jack.
Never get under the vehicle when it
middle claws (2) one by one.
is supported by the jack.
Never run the engine when the
(3)
vehicle is supported by the jack
and never allow passengers to
remain in the vehicle.
78K150
2) Release the lock at the underneath of
the spare wheel full cover (A) as shown
in the illustration.
78K152
4) Unhook the upper claws
(3), and
remove the wheel full cover.
8-3
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Jump Starting Instructions: 7
Towing a Disabled Vehicle: 6
If the Starter Does Not Operate: 2, 9
EMERGENCY SERVICE
NOTE:
facing the wheel. Tighten each nut
Remove the full wheel cover from the bot-
snugly by hand until the wheel is
tom part to the upper part. Otherwise, the
(B)
securely seated on the hub.
claws may be broken.
(Half cover type)
78K153
(4)
5) Pull out the lock cover (B) fitted on the
EXAMPLE
(5)
lock nut of the spare wheel while insert-
81A057
ing the key full into the key hole of the
lock cover (B).
Tightening torque for wheel nut
78K060
6) Remove the lock nut and wheel nuts of
100 Nm (10.0 kg-m, 72.3 lb-ft)
the spare wheel, then remove the spare
NOTE:
6)
Lower the jack and fully tighten the nuts
wheel with both hands.
If your vehicle is equipped with the half
in a crisscross fashion with a wrench as
cover, remove the center bolt
(4), then
shown in the illustration.
To change the wheel:
remove the outer cover (5) of the spare
1) Loosen, but do not remove the wheel
wheel half cover.
nuts.
2) Jack up the vehicle (follow the jacking
instructions in this section)
3) Remove the wheel nuts and wheel.
4) Before installing the new wheel, clean
any mud or dirt off from the surface of
the wheel and hub with a clean cloth.
Clean the hub carefully; it may be hot
from driving.
5) Install the new wheel and replace the
wheel nuts with their cone shaped end
8-4
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the Engine is Flooded: 2, 9
If the Engine Overheats: 2, 9
EMERGENCY SERVICE
WARNING
Use genuine wheel nuts and tighten
them to the specified torque as soon
as possible after changing wheels.
Incorrect wheel nuts or improperly
tightened wheel nuts may come
(4)
(5)
loose or fall off, which can result in
an accident. If you do not have a
torque wrench, have the wheel nut
torque checked by an authorized
SUZUKI dealer.
To install the wheel:
78K155
78K063
2) Put the spare tire nut lock (4) on the
NOTE:
spare tire nut and push the lock in.
When you install the spare tire full cover,
(1)
3) Install the wheel cover in the reverse
make sure the position of the upper claws
order to removal.
marked on outside (5) and holes, then
hook them first.
(2)
(3)
78K154
1) Install the wheel with both hands to the
spare tire carrier (1) as shown in the
illustration.
Then tighten the wheel nuts (2) and
spare tire nut (3).
8-5
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the Engine Overheats: 2, 9
If You Cannot Shift Automatic Transmission Gearshift Le-
ver Out of “P” (PARK): 2, 9
EMERGENCY SERVICE
(3)
WARNING
WARNING
Vehicle equipped with P225/65R17
(Continued)
tires have a spare wheel and tire that
• Replace the spare tire with a new
are a different size than the wheels
one as soon as the tread wear indi-
and tires on the vehicle. The spare
cator appears.
wheel and tire on these vehicles are
• When replacing the spare tire, use
intended for temporary emergency
a replacement tire with the exact
(4)
use only. The wheel is painted yellow
same size and construction.
to remind you that the wheel and tire
are for temporary use only. Continu-
Snow Tires
ous use of this spare can result in tire
Your vehicle is equipped with all-season
failure and loss of control. Always
tires which are designed for use in summer
64J196
observe these precautions when
and most winter conditions. For improved
using this spare:
traction in severe winter conditions,
• Be aware that your vehicle will han-
SUZUKI recommends mounting radial
CAUTION
dle differently with this temporary
snow tires on all four wheels. Snow tires
To avoid the removal of the spare
spare.
must be the same size as the standard
wheel full cover while driving, be
• Do not exceed 80 km/h (50 mph)
tires. Also be sure to use the tires of the
sure to fit the claws (3) of the outer
speed.
same type and brand on all four wheels of
cover of the spare wheel full cover to
• Replace the temporary spare with a
your vehicle.
standard tire and wheel as soon as
each hole (4) of the inner cover of the
possible.
spare wheel full cover.
• Do not operate your vehicle in “4H
LOCK” or “4L LOCK” with this tem-
porary spare.
• Do not use tire chains on the spare
tire. If you must use tire chains,
rearrange the wheels so standard
tires and wheels are fitted to the
rear axle.
(Continued)
8-6
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

EMERGENCY SERVICE
Jump Starting Instructions
2) Turn off all vehicle accessories, except
CAUTION
those necessary for safety reasons (for
example, headlights or hazard lights).
WARNING
Your vehicle should not be started by
pushing or towing. This starting
Never attempt to jump start your
EXAMPLE
Engine Hook
method could result in permanent
vehicle if the battery appears to be
damage to the catalytic converter.
frozen. Batteries in this condition
Use jumper cables to start a vehicle
may explode or rupture if jump
with a weak or run-down battery.
starting is attempted.
When making jumper cable con-
Discharged
When jump starting your vehicle, use
nections, be certain that your
Battery
the following procedure:
hands and the jumper cables
remain clear from pulleys, belts or
fans.
12V BATTERY
Batteries
produce flammable
hydrogen gas. Keep flames and
Charged Battery
sparks away from the battery or an
explosion may occur. Never smoke
60A270
when working near the battery.
If the booster battery you use for
jump starting is installed in another
vehicle, make sure the two vehicles
are not touching each other.
If your battery discharges repeat-
edly, for no apparent reason, have
your vehicle inspected by an autho-
60A269
rized SUZUKI dealer.
To avoid harm to yourself or dam-
1) Use only a 12-volt battery to jump start
age to your vehicle or battery, fol-
your vehicle. Position the good 12-volt
low the jump starting instructions
battery close to your vehicle so that the
below precisely and in order. If you
jumper cables will reach both batteries.
are in doubt, call for qualified road
When using a battery installed on
EXAMPLE
service.
another vehicle, DO NOT LET THE
52D129
VEHICLES TOUCH. Set the parking
brakes fully on both vehicles.
8-7
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

EMERGENCY SERVICE
3) Make jumper cable connections as fol-
Towing a Disabled Vehicle
If the Starter Does Not
lows:
Operate
1. Connect one end of the first jumper
Emergency Towing
cable to the positive (+) terminal of
If your vehicle is disabled, it may be towed
1)
Try turning the ignition switch to the
the discharged battery (1).
by a tow truck using one of the following
“START” position with the headlights
2. Connect the other end to the positive
methods:
turned on to determine the battery con-
(+) terminal of the booster battery
1) Tow the vehicle with two wheels lifted
dition. If the headlights go excessively
(2).
by the tow truck and the other two
dim or go off, it usually means that
3. Connect one end of the second
wheels on a towing dolly.
either the battery has run down or bat-
jumper cable to the negative (-) ter-
2) Use the appropriate towing method
tery terminal contact is poor. Recharge
minal of the booster battery (2).
specified for your vehicle in the “Towing
the battery or correct battery terminal
4. Make the final connection to an
Your Vehicle (recreational towing)” sec-
contact if necessary.
unpainted, heavy metal part
(i.e.
tion, but with the wheels lifted by the
2)
If the headlights remain bright, check
engine hook (3)) of the engine of the
tow truck instead of on a towing dolly.
the fuses. If the reason for failure of the
vehicle with the discharged battery
Be sure to carefully follow the specific
starter is not obvious, there may be a
(1).
instructions provided in the
“Towing
major electrical problem. Have the vehi-
Your Vehicle (recreational towing)” sec-
cle inspected by your authorized
WARNING
tion.
SUZUKI dealer.
Never connect the jumper cable
CAUTION
directly to the negative (-) terminal of
the discharged battery, or an explo-
If vehicle damage (such as steering
sion may occur.
or drivetrain damage, inability to
operate free axle mechanism, etc.)
4) If the booster battery you are using is
prevent normal use of the towing pro-
installed on another vehicle, start the
cedures for your vehicle described in
engine of the vehicle with the booster
the
“Towing Your Vehicle
(recre-
battery. Run the engine at moderate
ational towing)” section, have your
speed.
vehicle towed with two wheels lifted
5) Start the engine of the vehicle with the
by the tow truck and the other two
discharged battery.
wheels on a towing dolly.
6) Remove the jumper cables in the exact
reverse order in which you connected
them.
8-8
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

EMERGENCY SERVICE
If the Engine is Flooded
If the Engine Overheats
If the temperature indication does not
come down to within the normal, accept-
If the engine is flooded with gasoline, it
The engine could overheat temporarily
able range:
may be hard to start. If this happens, press
under severe driving conditions. If the
the accelerator pedal all the way to the
engine coolant temperature gauge indi-
1)
Turn off the engine and check that the
floor and hold it there while cranking the
cates overheating during driving:
water pump belt and pulleys are not
engine. (Do not operate the starter motor
damaged or slipping. If any abnormality
1) Turn off the air conditioner, if equipped.
for more than 15 seconds).
is found, correct it.
2) Take the vehicle to a safe place and
2)
Check the coolant level in the reservoir.
park.
If it is found to be lower than the “LOW”
3) Let the engine run at normal idle speed
line, look for leaks at the radiator, water
for a few minutes until the indicator is
pump and radiator and heater hoses. If
within the normal, acceptable tempera-
you locate any leaks that may have
ture range shown by the white band
caused the overheating, do not run the
between “H” and “C”.
engine until these problems have been
corrected.
WARNING
3)
If you do not find a leak, carefully add
If you see or hear escaping steam,
coolant to the reservoir and then the
stop the vehicle in a safe place and
radiator, if necessary. (Refer to “Engine
immediately turn off the engine to let
Coolant” in the
“INSPECTION AND
it cool. Do not open the hood when
MAINTENANCE” section.)
steam is present. When the steam
can no longer be seen or heard, open
the hood to see if the coolant is still
boiling. If it is, you must wait until it
stops boiling before you proceed.
Also, be careful not to touch hot
engine parts (radiator, water hoses,
engine etc.).
8-9
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

EMERGENCY SERVICE
66J191
WARNING
• It is hazardous to remove the radia-
tor cap when the water temperature
is high, because scalding fluid and
steam may be blown out under
pressure. The cap should only be
taken off when the coolant temper-
ature has lowered.
• To prevent personal injury, keep
hands, tools and clothing away
from the engine cooling fan and air-
conditioner fan (if equipped). These
electric fans can automatically turn
on without warning.
8-10
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

APPEARANCE CARE
APPEARANCE CARE
Corrosion Prevention
9-1
Vehicle Cleaning
9-3
60G412
9
79K21-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Corrosion Prevention: 5
APPEARANCE CARE
Corrosion Prevention
vehicle which are not well ventilated to
If you frequently drive on salted roads, your
permit quick drying.
vehicle should be washed at least once a
It is important to take good care of your
month during the winter. If you live near the
vehicle to protect it from corrosion.
ocean, your vehicle should be washed at
Listed below are instructions for how to
least once a month throughout the year.
maintain your vehicle to prevent corrosion.
Wash your vehicle immediately after using
Please read and follow these instructions
it off-road. For washing instructions, refer
carefully.
to the “Vehicle Cleaning” section.
Important Information About Corro-
Remove foreign material deposits
sion
Foreign material such as salts, chemicals,
Common causes of corrosion
road oil or tar, tree sap, bird droppings and
1) Accumulation of road salt, dirt, moisture
industrial fall-out may damage the finish of
or chemicals in hard-to-reach areas of
your vehicle if it is left on painted surfaces.
the vehicle underbody or frame.
Remove these types of deposits as quickly
2) Chipping, scratches and any damage to
as possible. If these deposits are difficult to
52D151
treated or painted metal surfaces
wash off, an additional cleaner may be
resulting from minor accidents or
This information illustrates the necessity of
required. Be sure that any cleaner you use
keeping your vehicle
(particularly the
impact from stones and gravel.
is not harmful to painted surfaces and is
underbody) as clean and dry as possible. It
specifically intended for your purposes.
Environmental conditions which accel-
is equally important to repair any damage
Follow the manufacturer’s directions when
erate corrosion
to the paint or protective coatings as soon
using these special cleaners.
as possible.
1) Road salt, dust control chemicals, sea
air or industrial pollution will all acceler-
WARNING
How to Help Prevent Corrosion
ate the corrosion of metal.
Foreign material can lodge between
2) High humidity will increase the rate of
Wash your vehicle frequently
the fuel tank of your vehicle and the
corrosion particularly when the temper-
The best way to preserve the finish on your
skid plate which covers it. You should
ature range is just above the freezing
vehicle and to help avoid corrosion is to
periodically clean out any foreign
point.
keep it clean with frequent washing.
material which has accumulated in
3) Moisture in certain areas of a vehicle
this area, since it could create a fire
for an extended period of time may pro-
Wash your vehicle at least once during the
hazard.
mote corrosion even though other body
winter and once immediately after the win-
sections may be completely dry.
ter. Keep your vehicle, particularly the
4) High temperatures will cause an accel-
underside, as clean and dry as possible.
erated rate of corrosion to parts of the
9-1
79K21-03E















Content      ..     16      17      18      19     ..
