9E-9 Glass / Windows / Mirrors: 6) Cut adhesive all around rear quarter window (1) with piano string (2). When using tool, windshield knife NOTE
7) Using knife (1), smoothen adhesive (2) remaining on body side (3) so that it is 1 – 2 mm (0.039 – 0.078 NOTE
8) When reusing rear quarter window, remove the adhesive (1) from it, using care not to damage I3RH0A950006-01 I2RH01950042-01 I2RH01950043-01 |
