9D-7 Wipers / Washers: Windshield Wiper Motor Inspection S6JB0B9406005 NOTE
1) Disconnect negative (–) cable at battery. referring to “Windshield Wiper Removal and 3) Remove cowl top garnish referring to “Cowl Top 4) Disconnect coupler from windshield wiper motor. details, refer to Step 4) of “Installation” in “Windshield 6) Check windshield wiper motor for operation as follows a. Connect battery positive (+) terminal to terminal “1” and its negative (–) terminal to b. Check if wiper arm reciprocation speed is as specification. If check result is not as Specification • For motor operation in high speed a. Connect battery positive (+) terminal to “2” and its negative (–) terminal to terminal “5”. b. Check if motor revolution speed is as specification. If check result is not as Specification [A]: Left-hand steering vehicle [B] [A] 1 5 1 5 I5JB0A940010-01 [A]: Left-hand steering vehicle [B] [A] 2 5 2 5 I5JB0A940011-01 |
