Subaru Outback (2022 year). Manual in english

(70,1)

12. To remove the child restraint system,
press the release button on the seatbelt
buckle and allow the belt to retract
completely. The belt will return to the
ELR mode.

Remember that the head restraint is not
intended to be used at the lowest position
(retracted position). Therefore, when the
rear center seat is occupied (including
when a child restraint system is installed),
be sure to raise the head restraint to the
extended position.

NOTE

When the child restraint system is no
longer in use, remove it and restore the
ELR function of the retractor. That
function is restored by allowing the

seatbelt to retract fully.

Installing a Booster Seat or
Booster Cushion

Booster seat

Booster cushion

WARNING

Before installing a booster seat/
cushion, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.

1. Move the seatback back and forth to
confirm that it is securely locked into place.

– Check that the red colored unlock-
ing marker on the lock release button is
not visible. For details, refer to “Folding
Down the Rear Seatback”

P42.

2. Adjust the head restraint as follows.
For booster seat:

Raise the head restraint to the extended
position. If the booster seat still makes

Child Restraint Systems

(71,1)

contact, remove the head restraint. For
details, refer to “Head Restraint Adjust-
ment”

P44.

CAUTION

Store the head restraint that has
been removed in the trunk (Legacy)
or cargo area (Outback/Subaru
Outback Wilderness). Do not place
the head restraint in the passenger
compartment to prevent it from
being thrown around in the passen-
ger compartment in a sudden stop
or a sharp turn.

For booster cushion:
Raise the head restraint to the extended
position. Do not remove the head restraint.
3. F o r O u t b a c k / S u b a r u O u t b a c k
Wilderness models, adjust the seatback
to the upright position.

4. Place the booster seat/cushion in the
rear seating position and sit the child on it.
The child should sit well back on the
booster seat/cushion.
5. Run the lap and shoulder belt through
or around the booster seat/cushion and
the child following the instructions pro-
vided by its manufacturer. For booster
seat/cushion with a belt guide, use the
seatbelt through the belt guide.
6. Insert the tongue plate into the buckle
until you hear a click. Take care not to twist
the seatbelt.
Make sure the shoulder belt is positioned
across the center of child’s shoulder and
that the lap belt is positioned as low as
possible on the child’s hips.

7. To remove the booster seat/cushion,
press the release button on the seatbelt
buckle and allow the belt to retract.

WARNING

Never use a belt that is twisted or

reversed. In an accident, this can
increase the risk or severity of
injury to the child.

Never place the shoulder belt

under the child’s arm or behind
the child’s back. If an accident
occurs, this can increase the risk
or severity of injury to the child.

The seatbelt should fit snugly in

order to provide full restraint.
Loose fitting belts are not as

– CONTINUED –

Child Restraint Systems

Seat,

Seatbelt

and

SRS

Airbags

(72,1)

effective in preventing or redu-
cing injury.

Place the lap belt as low as

possible on the child’s hips. A
high-positioned lap belt will in-
crease the risk of sliding under
the lap belt and of the lap belt
sliding up over the abdomen, and
both can result in serious internal
injury or death.

Make sure the shoulder belt is

positioned across the center of
child’s shoulder. Placing the
shoulder belt over the neck may
result in neck injury during sud-
den braking or in a collision.

Installation of Child Restraint
Systems by Use of Lower and
Tether Anchorages (LATCH)

Lower and tether anchorages

Legacy

Outback/Subaru Outback Wilderness

WARNING

Attach the child restraint system

to the anchors properly. When
using the LATCH anchors, be
sure that there are no foreign
objects around the anchors.
Make sure the child restraint
system is securely attached.
Otherwise it may cause death or
serious injury to children or other
passengers in sudden braking,
swerving, or accidents.

When installing a child restraint

system using LATCH anchors
with the rear seatbelt fastened,
ensure that the rear seatbelt does

Child Restraint Systems

(73,1)

not become caught in the child
restraint system or the lower
LATCH anchorages.

NOTE

The seatbelt warning system of the rear
seats detects if any of the seats are
occupied by a passenger. Installing a
child restraint system in the rear seat-
ing area, using the LATCH anchors,
may result in the activation of the
passenger seatbelt warning light and
chime. Fastening the rear seatbelt prior
to installing the child restraint system
will avoid activating the passenger
seatbelt warning light and chime. For
details, refer to “Rear passenger’s
seats”

P181.

Some types of child restraint systems can
be installed on the rear seat of your vehicle
without use of the seatbelts. Such child
restraint systems are secured to the
dedicated anchorages provided on the
vehicle body.
The lower and tether anchorages are
sometimes referred to as the LATCH
system (

ower

nchors and

ethers for

ildren).

Your vehicle is equipped with five lower
anchorages (bars) (U.S.-spec. models)
four lower anchorages (bars) (other mod-
els) and three upper anchorages (tether
anchorages) for accommodating such
child restraint systems.

Lower anchorages

U.S.-spec. models

WARNING

Do not connect two or more lower
hooks onto the same anchorage
(bar).

There are a total of 5 lower anchorages at
the rear seat. The rear anchorage from the
right side is used for both the right seat and
center seat. Each lower anchorage is
located where the seat cushion meets
the seatback.

– CONTINUED –

Child Restraint Systems

Seat,

Seatbelt

and

SRS

Airbags

(74,1)

Other models

WARNING

Do not connect two or more lower
hooks onto the same anchorage
(bar).

Two lower anchorages (bars) are provided
for installing a child restraint system on the
rear seat window-side seating positions.
Lower anchorages (bars) for window-side
seating positions may be used for a seat in
the center seating position if a child
restraint system manufacturer’s instruc-
tions permit and specify using anchors as
far apart as those in this vehicle. Each
lower anchorage is located where the seat
cushion meets the seatback.

Tether anchorages

Legacy

For right seat

For center seat

For left seat

Outback/Subaru Outback Wilderness

For left seat

For center seat

For right seat

The tether anchorages (upper an-
chorages) are provided at the locations
shown in the above illustration. For details,

Child Restraint Systems

(75,1)

refer to “Top Tether Anchorages”

P75.

To install a child restraint system
using lower and tether an-
chorages

WARNING

Before installing a child restraint
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.

1. Move the seatback back and forth to
confirm that it is securely locked into place.

– Check that the red colored unlock-
ing marker on the lock release button is
not visible. For details, refer to “Folding
Down the Rear Seatback”

P42.

For U.S.-spec. models

Other models

2. You will find “ ” marks at the bottoms
of the rear seatback. These marks indicate
the positions of the lower anchorages
(bars).

Each lower anchorage is located behind
the cover of seatback bottom.

CAUTION

When you install a child restraint
system, follow the manufacturer’s
instructions supplied with it. After
installing the child restraint system,
check to ensure that it is held
securely in position. If it is not held
tight and secure, the danger of your
child suffering personal injury in the
event of an accident may be in-
creased.

Peel off the anchorage cover completely
from the selected side of the rear seatback
to expose the anchorages (bars) to be
used for installation of the child restraint

– CONTINUED –

Child Restraint Systems

Seat,

Seatbelt

and

SRS

Airbags

(76,1)

system.
If it is hard to install the child restraint
system because the anchorage cover
returns to the original position, press the
anchorage cover to the seat cushion until it
is flat.

3. If the child restraint system makes
contact with the head restraint of the rear
seating position where the child restraint
system is to be installed, raise the head
restraint to the extended position. If the
child restraint system still makes contact,
remove the head restraint. For details,
refer to “Head Restraint Adjustment”

P44.

CAUTION

Store the head restraint that has
been removed in the trunk (Legacy)
or the cargo area (Outback/Subaru
Outback Wilderness). Do not place
the head restraint in the passenger
compartment to prevent it from
being thrown around in the passen-
ger compartment in a sudden stop
or a sharp turn.

4. F o r O u t b a c k / S u b a r u O u t b a c k
Wilderness models, adjust the seatback
to the upright position.
5. While following the instructions sup-
plied by the child restraint system manu-
facturer, connect the lower hooks onto the
lower anchorages located at “ ” marks on

the bottom of the rear seatback. When the
hooks are connected, make sure the
adjacent seatbelts are not caught.

6. If your child restraint system is a
flexible attachment type (which uses tether
belts), push the child restraint system into
the seat cushion and pull both left and right
lower tether belts up to secure the child
restraint system by taking up the slack in
the belt.
7. Latch the top tether hook onto the
tether anchorage that is located on the rear
shelf (Legacy)/behind the rear seat
(Outback/Subaru Outback Wilderness)
and tighten the top tether firmly. For
additional instructions, refer to “Top Tether
Anchorages”

P75.

Child Restraint Systems

(77,1)

8. Before seating a child in the child
restraint system, try to move it back and
forth and left and right to verify that it is
firmly secured in the center of the seat.
9. To remove the child restraint system,
follow the reverse procedures of installa-
tion.

If you have any question concerning this
type of child restraint system, ask your
SUBARU dealer.

Top Tether Anchorages

Your vehicle is equipped with three top
tether anchorages so that a child restraint
system having a top tether can be installed
in the rear seat. When installing a child
restraint system using top tether, proceed
as follows, while observing the instructions
by the child restraint system manufacturer.

Since a top tether can provide additional
stability by offering another connection
between a child restraint system and the
vehicle, we recommend that you use a top
tether whenever one is required or avail-
able.

Tether anchorage location

Legacy

For right seat

For center seat

For left seat

– CONTINUED –

Child Restraint Systems

Seat,

Seatbelt

and

SRS

Airbags

(78,1)

Three tether anchorages are installed on
the rear shelf behind the rear seat head
restraint. Open the cover flap to use each
anchorage.

O u t b a c k / S u b a r u O u t b a c k
Wilderness

For left seat

For center seat

For right seat

Three tether anchorages, i.e., ones for the

right, center and left positions, are already
installed on the back side of the rear
seatback.

To hook the top tether

CAUTION

Always raise the head restraint

when mounting a child restraint
system with a top tether. Failure
to do so may prevent the top
tether from being fastened
tightly.

If the head restraint is removed,

store the head restraint in the
trunk (Legacy) or the cargo area
( O u t b a c k / S u b a r u O u t b a c k
Wilderness).

Do not place the head restraint in

the passenger compartment to
prevent it from being thrown
around in the passenger com-
partment in a sudden stop or a
sharp turn.

Child Restraint Systems

(79,1)

Legacy

When installing on the window-side
seating position

When installing on the rear center seating
position

1. Raise the head restraint at the seating
position where the child restraint system is
to be installed with the seatbelt or lower
anchorages.

2. Open the cover flaps to use the
anchorages.
3. Pass the top tether between the head
restraint and seatback.

4. Fasten the top tether hook of the child
restraint system to the appropriate upper

anchorage.
5. Tighten the top tether securely. Con-
tact your SUBARU dealer if you have any
questions regarding the installation of a
child restraint system.

O u t b a c k / S u b a r u O u t b a c k
Wilderness

When installing on the window-side
seating position

When installing on the rear center seating
position

1. Raise the head restraint at the seating
position where the child restraint system is
to be installed with the seatbelt or lower
anchorages.
2. Adjust the seatback to the upright
position.
3. Pass the top tether between the head

– CONTINUED –

Child Restraint Systems

Seat,

Seatbelt

and

SRS

Airbags

(80,1)

restraint and seatback.

4. Attach the top tether hook to the
appropriate upper anchorage.
5. Tighten the top tether securely. Con-
tact your SUBARU dealer if you have any
questions regarding the installation of a
child restraint system.

1-9. SRS Airbag (Supplemen-
tal Restraint System Airbag)

Supplemental Restraint System (SRS)
name is used because the airbag system
supplements the vehicle’s seatbelts.

This vehicle is equipped with a supple-
mental restraint system which consists of
eight airbags.
The configurations are as follows.

Driver’s and front passenger’s

frontal

airbags

Driver’s and front passenger’s

side

airbags

Front passenger’s

seat cushion air-

bags

Curtain airbags

(for driver, front pas-

senger, and window-side rear passen-
gers)

Knee airbag

for driver

These SRS airbags are designed only
to be a supplement to the primary
protection provided by the seatbelt.

The system also controls front seatbelt
pretensioners. For operation instructions
and precautions concerning the seatbelt
pretensioner, refer to “Seatbelt Preten-
sioners”

P55.

General Precautions regard-
ing SRS Airbag System

WARNING

To obtain maximum protection in

the event of an accident, the
driver and all passengers must
always wear seatbelts when in
the vehicle. The SRS airbag is
designed only to be a supplement
to the primary protection pro-
vided by the seatbelt. It does not
eliminate the need to fasten seat-
belts. In combination with the
seatbelts, it offers the best pro-
tection in case of a serious acci-
dent.

Not wearing a seatbelt increases
the chance of severe injury or
death in a crash even when the
vehicle has the SRS airbag.

For instructions and precautions
concerning the seatbelt system,
refer to “Seatbelts”

P46.

The SRS side airbags and SRS

curtain airbags are designed only
to be a supplement to the primary
protection provided by the seat-
belt. They do not eliminate the
need to fasten seatbelts. It is also
important to wear a seatbelt to

SRS Airbag (Supplemental Restraint System Airbag)

(81,1)

help avoid injuries that can result
when an occupant is not seated
in a proper upright position.

WARNING

The SRS airbags deploy with con-
siderable speed and force. Occu-
pants who are not seated in proper
upright position when the SRS air-
bag deploys could suffer serious
injury. Because the SRS airbag
needs enough space for deploy-
ment, the driver should always sit
upright and back in the seat as far
from the steering wheel as practical
while still maintaining full vehicle
control, and the front passenger
should move the seat as far back

as possible and sit upright and well
back in the seat.

WARNING

Do not sit or lean close to either

front door. The SRS side airbags
are stored in both front seat
seatbacks next to the door, and
they provide protection by de-
ploying rapidly in the event of a
side impact collision. However,
the force of SRS side airbag
deployment can injure an occu-
pant whose body is too close to
an SRS airbag.

Since your vehicle is equipped

with SRS curtain airbags, do not

sit or lean close to the front or
rear door on either side. Do not
put body parts out of the window.
The SRS curtain airbags on both
sides of the cabin are stored in
the roof side (between the front
pillar and a point behind the rear
quarter glass), and they provide
protection by deploying rapidly
in the event of a side impact,
rollover or an offset frontal colli-
sion. However, the force of its
deployment can injure an occu-
pant whose body is too close to
an SRS airbag.

Do not sit or lean unnecessarily

close to the SRS airbag. Because
the SRS airbag deploys with
considerable speed and force to
protect in high speed collisions,
the force of an airbag can injure
an occupant whose body is too
close to SRS airbag.

It is also important to wear seat-
belts to help avoid injuries that
can result when the SRS airbag
contacts an occupant not in their
proper position.

Even when properly positioned,
there remains a possibility that
an occupant may suffer minor
injury, such as abrasions and

– CONTINUED –

SRS Airbag (Supplemental Restraint System Airbag)

Seat,

Seatbelt

and

SRS

Airbags

(82,1)

bruises to the face or arms,
because of the SRS airbag de-
ployment force.

WARNING

Keep arms away from either front

door or its internal trim. They
could be injured in the event of
SRS side airbag deployment.

Do not place any objects over or

near the SRS airbag cover or
between you and the SRS airbag.
If the SRS airbag deploys, these
objects could interfere with its
proper operation and could be
propelled inside the vehicle,
causing injury.

CAUTION

When the SRS airbag deploys,

some smoke will be released.
This smoke could cause breath-
ing problems for people with a
history of asthma or other breath-
ing trouble. If you or your pas-
sengers have breathing pro-
blems after SRS airbag deploys,
get fresh air promptly.

A deploying SRS airbag releases

hot gas. Occupants could get
burned if they come into direct
contact with the hot gas.

NOTE

When you sell your vehicle, we urge

you to inform the buyer that the vehicle
is equipped with SRS airbags. Also,
notify the buyer of the applicable sec-
tion in this Owner’s Manual.

If the SRS airbag deploys, fuel

supply will be cut off to reduce the risk
of fire caused by leaking fuel. For
details about restarting of the engine,
refer to “If Your Vehicle Is Involved in an
Accident”

P480.

General Precautions regard-
ing SRS Airbag System for
Accessories and Any Objects

SRS Airbag (Supplemental Restraint System Airbag)

(83,1)

WARNING

Do not put any objects (including

straps or cord) over the steering
wheel pad, column cover, or
dashboard.

– These objects could be en-

tangled with the steering
wheel, preventing the SRS
frontal airbag, etc. from oper-
ating properly.

– If the SRS frontal airbag de-

ploys, these objects could be
propelled inside the vehicle,
causing injury.

Do not put any objects under the

driver’s side of the instrument
panel. If the SRS knee airbag
deploys, those objects could in-
terfere with its proper operation
and could be propelled inside the
vehicle, causing injury.

The key must not be attached to

heavy, sharp or hard acces-
sories, or another key. If the SRS
knee airbag deploys, those ob-
jects could interfere with its
proper operation and could be
propelled inside the vehicle and
cause injury.

WARNING

Do not attach accessories to the
windshield, or fit an extra-wide mir-
ror over the inside rear view mirror. If
the SRS airbag deploys, those ob-
jects could become projectiles that
could seriously injure vehicle occu-
pants.

WARNING

Do not attach accessories to the

door trim or near either SRS side
airbags and do not place objects
near the SRS side airbags. In the
event of SRS side airbag deploy-
ment, they could be propelled
dangerously toward the vehicle’s
occupants and cause injuries.

Do not attach a hands-free micro-

phone or any other accessory to
a front pillar, a center pillar, a rear
pillar, the windshield, a side win-
dow, an assist grip, or any other
cabin surface that would be near
a deploying SRS curtain airbag. A
hands-free microphone or other

– CONTINUED –

SRS Airbag (Supplemental Restraint System Airbag)

Seat,

Seatbelt

and

SRS

Airbags

(84,1)

accessory in such a location
could be propelled through the
cabin with great force by the
curtain airbag, or it could prevent
correct deployment of the curtain
airbag. In either case, the result
could be serious injuries.

WARNING

Do not hang coat hangers or other
hard or pointed objects on the coat
hook. If such items were hanging on
the coat hooks during deployment
of the SRS curtain airbags, they
could cause serious injuries by
coming off the coat hooks and being
thrown through the cabin or by
preventing deployment of the cur-

tain airbags.

Before hanging clothing on the coat
hooks, make sure there are no sharp
objects in the pockets. Hang cloth-
ing directly on the coat hooks with-
out using hangers.

WARNING

Do not put any kind of clothes or

other objects over the driver’s
seat and front passenger’s seat-
back and do not attach labels or
stickers to the driver’s seat and
front passenger’s seat surface on
or near the SRS side airbag. They
could prevent proper deployment
of the SRS side airbag, reducing

protection available to the dri-
ver’s seat and front passenger’s
seat’s occupant.

Do not install a seat cover unless

it is a genuine SUBARU seat
cover exclusively designed for
use with the SRS airbag. Even
when using a genuine SUBARU
seat cover, the SRS side airbag
system may not function nor-
mally if the seat cover is not
installed correctly.

General Precautions regard-
ing SRS Airbag System and
Children

SRS Airbag (Supplemental Restraint System Airbag)

(85,1)

WARNING

Seat children in the rear seat prop-
erly restrained at all times. The SRS
airbag deploys with considerable
speed and force and can injure or
even kill children, especially if they
are not restrained or improperly
restrained. Because children are
lighter and weaker than adults, their
risk of being injured from deploy-
ment is greater.

For that reason, we strongly recom-
mend that ALL children (including
those in child restraint systems) sit
in the REAR seat properly restrained
at all times in a child restraint device
or in a seatbelt, whichever is appro-
priate for the child’s age, height and
weight.

Secure ALL types of child restraint
systems (including forward facing
child restraint system) in the REAR
seats at all times.

According to accident statistics,
children are safer when properly
restrained in the rear seating posi-
tions than in the front seating posi-
tions.

For instructions and precautions
concerning the child restraint sys-

tem, refer to “Child Restraint Sys-
tems”

P58.

WARNING

NEVER INSTALL A CHILD RE-
STRAINT SYSTEM IN THE FRONT
PASSENGER’S SEAT. DOING SO
RISKS SERIOUS INJURY OR DEATH
TO THE CHILD BY PLACING THE
CHILD’S HEAD TOO CLOSE TO THE
SRS AIRBAG.

WARNING

Never allow a child to stand up or
kneel on the front passenger’s seat.
The SRS airbag deploys with con-
siderable force and can injure or
even kill the child.

– CONTINUED –

SRS Airbag (Supplemental Restraint System Airbag)

Seat,

Seatbelt

and

SRS

Airbags

Subaru Outback (2022 year). Manual in english - page 5
