Subaru WRX (2021 year). Manual in english

A SUBARU dealer can change the setting adjustments of the following items to meet your personal requirements. Contact the nearest
SUBARU dealer for details.

Item

Function

Available settings

Factory default

setting

Page

Alarm system

Monitoring start delay time (after closure of doors) 0 seconds/30 seconds

30 seconds

2-25

Impact sensor operation (only models with shock
sensors (dealer option))

Operation/Non-operation

Non-operation

2-30

Passive arming (models without “keyless access
with push-button start system”)

Operation/Non-operation

Non-operation

2-29

Dome light and map lights (models with moonroof)
illumination

ON/OFF

OFF

2-24

Keyless access with push-button

Trunk open without key

ON/OFF

2-11

Remote trunk open function

Activation of trunk opening by remote transmitter/
access key fob

Operation/Non-operation

Operation

2-20

Key lock-in prevention

Operation/Non-operation

Operation

2-7

Battery drainage prevention function

Operation/Non-operation

Operation

2-5

Seatbelt warning

Sounds a chime while driving

Operation/Non-operation

Operation

3-14

Windshield wiper

Auto-on/off wiper linked headlights

Operation/Non-operation

Operation

3-66

(29,1)

Item

Function

Available settings

Factory default

setting

Page

Auto dimmer cancel

Sensitivity of the operation of the auto dimmer
cancel

OFF/Min/Low/Mid/Hi/Max Mid

3-73

High beam assist function (models
with the EyeSight system)

High beam assist function

Operation/Non-operation

Operation

3-67

One-touch lane changer

Operation of the one-touch lane changer

Operation/Non-operation

Operation

3-72

(31,1)

Front seats .............................................................. 1-2

Manual seat ........................................................... 1-4
Power seat (driver’s seat – if equipped).................. 1-5
Head restraint adjustment ...................................... 1-5

Seat heater (if equipped) ........................................ 1-7
Rear seats................................................................ 1-8

Head restraint adjustment ...................................... 1-8
Folding down the rear seatback ............................. 1-9
Armrest ................................................................ 1-11

Seatbelts ................................................................ 1-12

Seatbelt safety tips ............................................... 1-12
Emergency Locking Retractor (ELR)...................... 1-13
Automatic Locking Retractor/Emergency

Locking Retractor (ALR/ELR) .............................. 1-13

Seatbelt warning light and chime .......................... 1-13
Fastening the seatbelt........................................... 1-13
Seatbelt maintenance ............................................ 1-17

Front seatbelt pretensioners................................ 1-17

Driver’s seatbelt.................................................... 1-17
Front passenger’s seatbelt .................................... 1-18
Components that will operate with the seatbelt

pretensioner(s) simultaneously ........................... 1-19

Safety tips ............................................................ 1-20
System monitors................................................... 1-20
System servicing .................................................. 1-20
Precautions against vehicle modification............... 1-21

Child restraint systems ........................................ 1-21

Safety precautions................................................ 1-21
Safety tips for installing child restraint systems .... 1-22
Where to place a child restraint system ................ 1-23
Choosing a child restraint system......................... 1-25
Installing child restraint systems with ALR/ELR

seatbelt ............................................................. 1-25

Installing a booster seat or booster cushion ......... 1-30
Installation of child restraint systems by use of

lower and tether anchorages (LATCH) ................ 1-31

Top tether anchorages .......................................... 1-34

SRS airbag (Supplemental Restraint System

airbag) ................................................................ 1-35

General precautions regarding SRS airbag

system .............................................................. 1-36

General precautions regarding SRS airbag

system for accessories and any objects............. 1-38

General precautions regarding SRS airbag

system for children............................................ 1-40

Components ......................................................... 1-43
SUBARU advanced frontal airbag system.............. 1-45
SRS side airbag and SRS curtain airbag ............... 1-55
SRS airbag system monitors................................. 1-64
SRS airbag system servicing ................................ 1-65
Precautions against vehicle modification .............. 1-66
How to contact the vehicle manufacturer

concerning modifications for persons with
disabilities that may affect the advanced airbag
system .............................................................. 1-67

Seat, seatbelt and SRS airbags

(32,1)

Front seats

WARNING

Never adjust the seat while driv-

ing, as personal injury or loss of
vehicle control may occur.

Before adjusting the seat, ensure

nothing is blocking the adjusting
mechanism.

After adjusting the seat, move it

back and forth to ensure the seat
is securely locked. If it is not, it
may move suddenly or the seat-
belt may not operate properly.

Do not put objects under the front

seats. They may interfere with
front seat locking mechanism
and cause an accident.

Seatbelts provide maximum re-

straint when the occupant sits
back and upright in the seat. To
reduce the risk of sliding under
the seatbelt in a collision, the
front seatbacks should always
be used in the upright position
while the vehicle is running. If the
front seatbacks are not in the
upright position and a collision
occurs, the risk of sliding under
the lap belt and of the lap belt

sliding up over the abdomen will
increase, and both can result in
serious injury or death.

The SRS airbags deploy with

considerable speed and force.
Occupants who are not sitting
back and upright when the SRS
airbag deploys could suffer ser-
ious injury. Because the SRS
airbag needs enough space for
deployment, the driver should
always sit upright and well back
in the seat as far from the steer-
ing wheel as practical while still
maintaining full vehicle control,
and the front passenger should
move the seat as far back as
possible and sit upright and well
back in the seat.

WARNING

Place children in the rear seat prop-
erly restrained at all times. The SRS
airbag deploys with considerable
speed and force and can injure or
even kill children, especially if they
are not restrained or improperly
restrained. Because children are
lighter and weaker than adults, their
risk of being injured from deploy-
ment is greater. For that reason, we
strongly recommend that ALL chil-
dren (including those in child seats
and those that have outgrown child
restraint devices) sit in the REAR
seat properly restrained at all times
in a child restraint device or in a
seatbelt, whichever is appropriate

Seat, seatbelt and SRS airbags/Front seats

1-2

(33,1)

for the child’s age, height and
weight. Secure ALL types of child
restraint devices (including forward
facing child seat) in the REAR seats
at all times.

NEVER INSTALL A CHILD SEAT IN
THE FRONT SEAT. DOING SO RISKS
SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE
CHILD’S HEAD TOO CLOSE TO
THE SRS AIRBAG.

According to accident statistics,
children are safer when properly
restrained in the rear seating posi-
tions than in the front seating posi-
tions. For instructions and precau-
tions concerning child restraint sys-
tems, refer to “Child restraint sys-
tems”

1-21.

WARNING

To prevent the passenger from slid-
ing under the seatbelt in the event of
a collision, observe the following
precautions:

Keep the seatback in the upright

position while the vehicle is in
motion.

Do not place objects such as

cushions between the passenger
and the seatback.

Otherwise, the risk of sliding under
the lap belt and of the lap belt sliding
up over the abdomen will increase,
and both can result in serious injury
or death.

WARNING

Do not let rear passengers rest their
feet between the front seatback and
seat cushion. Doing so may lead to
improper operation of the following
systems and could result in serious
injury.

Occupant detection system

SRS side airbag

Seat heater (if equipped)

Power seat (if equipped)

– CONTINUED –

Seat, seatbelt and SRS airbags/Front seats

1-3

(34,1)

Manual seat

Forward and backward adjustment

1. Sit in the seat to adjust.
2. Pull the lever upward, slide the seat to
the desired position, and then release the
lever.
3. Try to move the seat back and forth to
make sure that it is securely locked into
place.

Reclining the seatback

1. Pull up the reclining lever, adjust the
seatback to the desired position, and then
release the lever.
2. Make sure the seatback is securely
locked into place.

The seatback placed in a reclined position
can spring back upward with force when
pulling the lever. While operating the lever
to return the seatback, hold the seatback
lightly so that it may be raised back
gradually.

Seat cushion height adjustment
(driver’s seat)

When the lever is pushed down, the seat
is lowered.

When the lever is pulled up, the seat
rises.

Move the seat cushion adjustment lever up
or down to adjust the seat cushion height.

Seat, seatbelt and SRS airbags/Front seats

1-4

(35,1)

Power seat (driver’s seat – if
equipped)

Seat position forward/backward con-
trol switch

To adjust the seat forward or backward,
move the control switch forward or
backward. During forward/backward ad-

justment of the seat, you cannot adjust
the seat cushion angle or seat cushion
height.

Seat cushion angle control switch

To adjust the seat cushion angle, pull up
or push down the front end of the control
switch.

Seat height control switch

To adjust the seat height, pull up or push
down the rear end of the control switch.

Seatback angle (reclining) control
switch

To adjust the angle of the seatback, move
the control switch.

Lumbar support control switch (dri-
ver’s seat only)

To increase lower back support, push the
front side of the switch. To decrease
lower back support, push the rear side of
the switch.

Head restraint adjustment

WARNING

Never drive the vehicle with the

head restraints removed because
they are designed to reduce the
risk of serious neck injury in the
event that the vehicle is struck
from the rear. Also, never install
the head restraints the opposite
way round. Doing so will prevent
the head restraints from function-

ing as intended. Therefore, when
you remove the head restraints,
you must reinstall all head re-
straints correctly to protect vehi-
cle occupants.

All occupants, including the dri-

ver, should not operate a vehicle
or sit in a vehicle’s seat until the
head restraints are placed in their
proper positions in order to mini-
mize the risk of neck injury in the
event of a crash.

The front seat head restraints are

designed to be installed into the
front seats only. The rear seat
head restraints are designed to
be installed into the rear seats
only. Do not attempt to install the
front seat head restraints into the
rear seats, or the rear seat head
restraints into the front seats.

NOTE

It is possible to adjust the angle of the
front seat head restraints only. When
installing the front seat head restraints,
make sure that the angle of the head
restraints can be adjusted.

Both the driver’s seat and front passen-
ger’s seat are equipped with head re-
straints. Both head restraints are adjusta-

– CONTINUED –

Seat, seatbelt and SRS airbags/Front seats

1-5

(36,1)

ble in the following ways.

Head restraint height adjustment

Head restraint

Release button

To raise:

Pull the head restraint up.

To lower:

Push the head restraint down while press-
ing the release button on the top of the
seatback.

To remove:

While pressing the release button, pull out
the head restraint.

To install:

Install the head restraint into the holes that
are located on the top of the seatback until
the head restraint locks. Press and hold

the release button to lower the head
restraint.

Adjust each head restraint so that the
center of the head restraint is closest to the
top of the occupant’s ears.

NOTE

When the head restraint will not move
in or out due to insufficient clearance
between the head restraint and the roof,
tilt the seat and then perform the
installation and removal tasks.

Head restraint angle adjustment

It is possible to adjust the angle of the head
restraint in several steps. While maintain-
ing a suitable driving posture, adjust the
head restraint to a position where the back
of your head is as close to the head
restraint as possible.

To tilt:

Tilt the head restraint by hand to the
preferred position. A click will be audible
when the head restraint is locked.

To return:

Tilt the head restraint once as far forward
as it can go. The head restraint will
automatically return to the fully upright
position. Then, adjust the head restraint
again to the preferred angle.

Seat, seatbelt and SRS airbags/Front seats

1-6

(37,1)

Seat heater (if equipped)

The front seats are equipped with a seat
heater.

The seat heater operates when the ignition
switch is either in the “ACC” or “ON”
position.

CAUTION

People with delicate skin may

suffer slight burns even at low
temperatures if they use the seat
heater for a long period of time.
When using the heater, always be
sure to warn the persons con-
cerned.

Do not put anything on the seat

which insulates against heat,
such as a blanket, cushion, or
similar items. This may cause the
seat heater to overheat.

When the seat is warmed enough

or before you leave the vehicle,
be sure to turn off the seat heater.

NOTE

Use of the seat heater for a long period
of time while the engine is not running
can cause battery discharge.

Type A

Type B

HIGH (HI)

– Rapid heating

LOW (LO)

– Normal heating

Off

Left-hand side

Right-hand side

To turn on the seat heater, push the “LOW”
(“LO”) or “HIGH” (“HI”) position on the
switch, as desired, depending on the
temperature.
Selecting the “HIGH” (“HI”) position will
cause the seat to heat up quicker.

To turn off the seat heater, lightly press the
opposite side of the current position.

The indicator located on the switch illumi-
nates when the seat heater is in operation.
When the seat is warmed enough or
before you leave the vehicle, be sure to
turn the switch off.

Seat, seatbelt and SRS airbags/Seat heater

1-7

Subaru WRX (2021 year). Manual in english - page 2
