Subaru Outback (2019 year). Instruction

(136,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Cargo area light (Outback)

The notifications regarding the map
lights, dome light and cargo area light
(Outback) are deactivated as the fac-
tory setting. A SUBARU dealer can
activate the system. Contact your
SUBARU dealer for details.

Activating and deactivating
the alarm system

To change the setting of your vehicle’s
alarm system for activation or deactiva-
tion, do the following.
1. Disarm the alarm system. Refer to
“Disarming the system” F2-33.
2. Sit in the driver’s seat and shut all
doors (and the rear gate (Outback)).
3. Turn the ignition switch to the “ON”
position.
4. Hold down the REAR (UNLOCK) side
of the driver’s power door locking switch,
open the driver’s door within the following
1 second, and wait 10 seconds without
releasing the switch. The setting will then
be changed as follows:

If the system was previously activated:
The odometer screen displays “ALOF” and
the horn sounds twice, indicating that the
system is now deactivated.

If the system was previously deacti-
vated:
The odometer screen displays “ALON”
and the horn sounds once, indicating that
the system is now activated.

NOTE

You may have the above setting change
done by your SUBARU dealer.

If you have accidentally trig-
gered the alarm system

To stop the alarm

Perform any of the following operations.
.

Press any button on the access key fob/

remote transmitter.
.

Turn the ignition switch to the “ON”

position (models without “keyless access
with push-button start system”).
.

Turn the push-button ignition switch to

the “ACC” position (models with “keyless
access with push-button start system”).

NOTE

Only registered keys will stop the
alarm. If the key is not registered, the
alarm will not stop.

Arming the system

NOTE

The system can be armed even if the

windows and/or moonroof are open.
Always make sure that they are fully
closed before arming the system.
.

When arming the system, if any of

the doors or the rear gate/trunk lid is
not fully closed, an electronic chirp
sounds five times, the hazard warning
flashers flash five times to alert you that
the doors (or the rear gate/trunk lid) are
not properly closed. When you close
the door, doors will automatically lock
and the system will automatically arm
in 30 seconds. However, the system will
not arm if the engine hood is open.
.

The 30-second standby time can be

eliminated if you prefer. Have it per-
formed by your SUBARU dealer.
.

For Legacy, if you open the trunk

using the access key fob/remote trans-
mitter’s “

” button in the surveillance

state (or the standby state), the system
will be temporarily placed in a standby
state. The system will go back to the
surveillance state in 30 seconds upon
locking the trunk.
.

The system is in the standby state

for a 30-second period before arming
the system. The security indicator light
will flash at short intervals during this

Keys and doors/Alarm system

2-30

(137,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

period.
.

If any of the following actions is

done during the standby period, the
system will not switch to the surveil-
lance state.

– Doors (including the rear gate/
trunk lid) are unlocked using the
access key fob/remote transmitter.
– Doors (including the rear gate/
trunk lid) are unlocked using the
keyless access function (models
with “keyless access with push-
button start system”).
– Any door (including the rear gate)
is opened.
– The ignition switch is turned to
the “ON” position (models without
“keyless access with push-button
start system”).
– Push-button ignition switch is
turned to the “ACC” position (mod-
els with “keyless access with push-
button start system”).

To arm the system using the access
key fob/remote transmitter

1. Close all windows and the moonroof (if
equipped).
2. Remove the key from the ignition
switch (models without “keyless access
with push-button start system”)/turn the
push-button ignition switch to the “OFF”

position (models with “keyless access with
push-button start system”).
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood is
locked.
5. Close all doors and the rear gate/trunk
lid.

Access key fob
1)

Arm button: Press to arm the system

Disarm button: Press to disarm the
system

Transmitter
1)

Arm button: Press to arm the system

Disarm button: Press to disarm the
system

Security indicator light

6. Briefly press the arm button (for less

– CONTINUED –

Keys and doors/Alarm system

2-31

(138,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

than 2 seconds). All doors (and the rear
gate (Outback)) will lock, an electronic
chirp will sound once, the hazard warning
flashers will flash once, and the security
indicator light will start flashing rapidly.
After rapid flashing for 30 seconds (stand-
by time), the security indicator light will
then flash slowly (twice approximately
every 2 seconds), indicating that the
system has been armed for surveillance.

If any of the doors (rear gate or trunk lid) is
not fully closed, an electronic chirp sounds
five times, the hazard warning flashers
flash five times to alert you that the doors
(or the rear gate/trunk lid) are not properly
closed. When you close the door, the
system will automatically arm and doors
will automatically lock.

To arm the system using power door
locking switch

1. Close all windows and the moonroof (if
equipped).
2. Remove the key from the ignition
switch (models without keyless access
function)/make sure the push-button igni-
tion switch is turned off (models with
keyless access function).
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood (and
the trunk lid (Legacy)) are locked.

5. Close the doors (and the rear gate
(Outback)) but leave only the driver’s door
or the front passenger’s door open.

6. Press the front side (“LOCK” side) of
the power door locking switch to set the
door locks.
7. Close the door. An electronic chirp will
sound once, the hazard warning flashers
will flash once and the security indicator
light will start flashing rapidly. After rapid
flashing for 30 seconds (standby time), the
security indicator light will then flash slowly
(twice approximately every 2 seconds),
indicating that the system has been armed
for surveillance.

To arm the system using the keyless
access function (if equipped)

1. Close all windows and the moonroof (if
equipped)
2. Turn the push-button ignition switch to
the “OFF” position.
3. Open the doors and get out of the
vehicle.
4. Make sure that the engine hood is
locked.
5. Close all doors and the rear gate/trunk
lid.

Door lock sensor

Keys and doors/Alarm system

2-32

(139,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Security indicator light

6. Carry the access key fob and touch the
door lock sensor. All doors (for Outback,
including the rear gate) will lock, an
electronic chirp will sound once, the
hazard warning flashers will flash once,
and the security indicator light will start
flashing rapidly. After rapid flashing for 30
seconds (standby time), the security in-
dicator light will then flash slowly (twice
approximately every 2 seconds), indicat-
ing that the system has been armed for
surveillance.

If any of the doors or the rear gate is not
fully closed, an electronic chirp sounds five
times, the hazard warning flashers flash
five times to alert you that the doors (or the
rear gate/trunk lid) are not properly closed.
When you close the door, the system will

automatically arm and doors will automa-
tically lock.

Disarming the system

Perform either of the following procedures.
.

Briefly press the disarm button (for less

than 2 seconds) on the access key fob/
remote transmitter.
.

Carry the access key fob and perform

either of the following procedures (models
with “keyless access with push-button
start system”).

– Grip the front door handle.
– Press the rear gate opener button.

The flashing of the security indicator light
will then change slowly (once approxi-
mately every 3 seconds from twice ap-
proximately every 2 seconds), indicating
that the alarm system has been disarmed.

Emergency disarming

If you cannot disarm the system using the
transmitter (i.e. the transmitter is lost,
broken or the transmitter battery is too
weak), you can disarm the system without
using the transmitter.
The system can be disarmed if you turn the
ignition switch from the “LOCK”/“OFF” to
the “ON” position with a registered key/
access key fob.

NOTE

For models with “keyless access with
push-button start system”, if the ac-
cess key battery is discharged, perform
the procedure described in “Switching
power status” F9-20. In such a case,
replace the battery immediately. Refer
to “Replacing battery of access key
fob” F11-50.

Valet mode

When you choose the valet mode, the
alarm system does not operate. In valet
mode, the access key fob/remote trans-
mitter is used only for locking and unlock-
ing the doors and rear gate (Outback) and
panic activation.

To enter the valet mode, change the
setting of your vehicle’s alarm system for
deactivation mode. Refer to “Activating
and deactivating the alarm system” F2-
30. The security indicator light will continue
to flash once every 3 seconds indicating
that the system is in the valet mode.

To exit valet mode, change the setting of
your vehicle’s alarm system for activation
mode. Refer to “Activating and deactivat-
ing the alarm system” F2-30.

– CONTINUED –

Keys and doors/Alarm system

2-33

(140,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Tripped sensor identification

The security indicator light flashes when
the alarm system has been triggered. Also,
the number of flashes indicates the loca-
tion of unauthorized intrusion or the
severity of impact on the vehicle.
When the ignition switch is turned to the
“ON” position, the indicator light will
illuminate for 1 second and then flash as
follows:
.

When a door or rear gate (Outback)

was opened: 5 times
.

When the trunk (Legacy) was opened:

4 times
.

When the engine hood was opened: 3

times
.

When a strong impact or multiple

impacts were sensed: twice (only models
with shock sensors (dealer option))
.

When a light impact was sensed: once

(only models with shock sensors (dealer
option))

Shock sensors (dealer op-
tion)

The shock sensors trigger the alarm
system when they sense impacts applied
to the vehicle and when any of their electric
wires is cut. The alarm system causes the
horn to sound and the hazard warning
flashers to flash for a short time when the

sensed impact is weak, but it warns of a
strong impact or multiple impacts by
sounding the horn and flashing the hazard
warning flashers, both lasting approxi-
mately 30 seconds.
If you desire, your SUBARU dealer can
connect them and set them for activation
or deactivation.

NOTE

The shock sensors are not always

able to sense impacts caused by break-
ing in, and cannot sense an impact that
does not cause vibration (such as
breaking the glass using a rescue
hammer).
.

The shock sensors may sense vibra-

tion like those shown in the following
examples and trigger the alarm system.
Select the settings of the alarm system
and shock sensors appropriately de-
pending on where you usually park
your vehicle.
Examples:

– Vibration from construction site
– Vibration in multistory car park
– Vibration from trains

You can have the sensitivity of the

shock sensors adjusted to your pre-
ference by your SUBARU dealer.

Child safety locks

WARNING

Always turn the child safety locks to
the “LOCK” position when children
sit on the rear seat. Serious injury
could result if a child accidentally
opens the door and falls out.

Each rear door has a child safety lock.
When the child safety lock lever is in the
“LOCK” position, the door cannot be
opened from inside. The door can only
be opened from the outside.

Keys and doors/Child safety locks

2-34

(141,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Windows

WARNING

To avoid serious personal injury
caused by entrapment, always con-
form to the following instructions
without exception.

When operating the power win-

dows, be extremely careful to
prevent anyone’s fingers, arms,
neck, head or other objects from
being caught in the window.

Always lock the passengers’ win-

dows using the lock switch when
children are riding in the vehicle.

For safety reasons, always carry

the key with you when leaving the
vehicle and never allow an un-
attended child to remain in the
vehicle. Failure to follow this
procedure could result in injury
to a child operating the power
window.

The power windows operate only when the
ignition switch is in the “ON” position.

Power window operation

Power window switches

Driver’s side power window switches:

Lock switch

For driver’s window

For front passenger’s window

For rear left passenger’s window

For rear right passenger’s window

All door windows can be controlled by the
power window switch cluster at the driver
side door.

Passenger ’s side power window
switches:

Each passenger’s window can be con-
trolled by the power window switch located
on the door.

– CONTINUED –

Keys and doors/Windows

2-35

(142,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Operating the window

With one-touch auto up and down
feature:

Automatically close*

Open

Automatically open*

*: To stop the window halfway, operate the

switch to opposite side.

NOTE

If you continue to hold the AUTO

switch in the down position after the
window has been fully opened, the
circuit breaker may activate for a short
time and the window may not operate.
Allow several seconds for the system
to reset without touching the switch,
and the window will begin to operate
normally on its own.
.

If you continue to hold the AUTO

switch in the up position after the
window has fully closed, the circuit
breaker may open and the system may
not operate. After several seconds, the
window will be able to be opened by
holding the switch down until it is fully
opened. The AUTO function will not
operate. The window can be raised by
pulling up on the switch several times
until the window is fully closed.
To reset to normal operation, initialize
the power window to reactivate the one-
touch auto up/down function. Refer to
“Initialization of power window (win-
dows with one-touch auto up/down
function)” F2-38.
.

If the vehicle’s battery is discon-

nected due to situations such as bat-
tery or fuse replacement, the one-touch
auto up/down function will be deacti-
vated. Initialize the power window to

reactivate the one-touch auto up/down
function. Refer to “Initialization of
power window (windows with one-
touch auto up/down function)” F2-38.

Without one-touch auto up and down
feature:

Open

To open:
Press the appropriate switch down and
hold it until the window reaches the desired
position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.

Keys and doors/Windows

2-36

(143,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Anti-entrapment function (win-
dows with one-touch auto up/
down function)

CAUTION

Never attempt to test this func-

tion using fingers, hands or other
parts of your body.

The anti-entrapment function

may not operate properly if some
object gets trapped just before
the window fully closes.

NOTE

If a window detects an impact similar

to that caused by trapping an object (for
example, when the vehicle encounters
a deep pothole), the anti-entrapment
function may operate.
.

The window cannot be operated for a

few seconds after the anti-entrapment
function operates.
.

If the vehicle’s battery is discon-

nected due to situations such as bat-
tery or fuse replacement, the anti-
entrapment function will be deacti-
vated. Initialize the power window to
reactivate the anti-entrapment func-
tion. Refer to “Initialization of power
window (windows with one-touch auto

up/down function)” F2-38.

While closing with the one-touch auto up
function, if the window senses a substan-
tial enough object trapped between the
window and the window frame, it auto-
matically moves down slightly and stops.

Off delay function (windows with
one-touch auto up/down function)

The windows can be operated for approxi-
mately 42 seconds even after the ignition
switch is turned to the “ACC” or “OFF”
position. If a front door is opened within 42
seconds, the off delay function is can-
celed.

Locking the passengers’ windows

Lock

Unlock

To lock:
Press the lock switch. When the lock
switch is in the lock position, the rear
passenger’s window switches at the driver
side door and the passengers’ window
switches cannot be operated.
To unlock:
Press the lock switch again.

– CONTINUED –

Keys and doors/Windows

2-37

(144,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Initialization of power window
(windows with one-touch
auto up/down function)

If the vehicle’s battery is disconnected due
to situations such as battery or fuse
replacement, the following functions are
deactivated.
.

One-touch auto up/down function

Anti-entrapment function

Operate each window according to the
following procedure in order to initialize the
power window system.
1. Close the driver’s door.
2. Turn the ignition switch to the “ON”
position.
3. Open the driver’s side window halfway
by pushing down the power window
switch.
4. Pull up the power window switch and
close the window completely. Continue
pulling up the switch for approximately 1
second after the window is closed com-
pletely.

Trunk lid (Legacy)

WARNING

To prevent dangerous exhaust

gas from entering the vehicle,
always keep the trunk lid closed
while the engine is running.

Help prevent children, adults or

animals from locking themselves
in the trunk. On hot or sunny
days, the temperature in the trunk
could quickly become high en-
ough to cause death or serious
heat-related injuries including
brain damage to anyone locked
inside, particularly for small chil-
dren.

When leaving the vehicle, close

all windows and lock all doors.
Also make certain that the trunk
is closed.

To open and close the trunk
lid from outside

The trunk lid can be opened using the
keyless access function or remote keyless
entry system. For details, refer to the
following section.
.

For models with “keyless access with

push-button start system”, refer to “Open-
ing trunk (Legacy)” F2-17, “Opening the
trunk lid (Legacy)” F2-26 or “Opening the
trunk lid (Legacy)” F2-27.
.

For models without “keyless access

with push-button start system”, refer to
“Opening the trunk lid (Legacy)” F2-26 or
“Opening the trunk lid (Legacy)” F2-27.

To close the trunk lid, lightly press the trunk
lid down until the latch engages.

NOTE

The trunk lid can also be opened

using the key. Refer to “Trunk lid
(Legacy) – if the trunk lid cannot be
opened” F9-21.
.

Do not leave your valuables in the

trunk when you leave your vehicle.
.

Even when the trunk lid cannot be

opened using the remote keyless entry
system, you can open the trunk lid by
using the key. Refer to “Trunk lid
(Legacy) – if the trunk lid cannot be
opened” F9-21.

Keys and doors/Trunk lid (Legacy)

2-38

(145,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Under the following conditions, the

trunk can be opened without the access
key fob.

– The trunk lock/unlock setting is
set to on.
– All doors are unlocked.

The trunk lock/unlock setting can be
changed by a SUBARU dealer. Contact
your SUBARU dealer to change the
setting.

To open the trunk lid from
inside

Press and hold the trunk lid opener switch
for more than 1 second.

Internal trunk lid release
handle

The internal trunk lid release handle is a
device designed to open the trunk lid from
inside the trunk. In the event children or
adults become locked inside the trunk, the
handle allows them to open the lid. The
handle is located on the inside of the trunk
lid.

To open the trunk lid from inside the trunk,
pull the yellow handle as indicated by the
arrow on the handle. This operation
unlocks the trunk lid. Then, push up the lid.
The handle is made of material that
remains luminescent for approximately
an hour in the dark trunk space after it is
exposed to ambient light even for a short
time.

WARNING

Never allow any child to get in the
trunk and play with the release
handle. If the driver starts the vehi-
cle without knowing that a child is
inside the trunk and the child opens
the lid using the release handle, the
child could fall out and be killed or
seriously injured.

CAUTION

Do not close the lid while gripping

the release handle. The handle
may be damaged.

Do not use the handle as a hook

to fasten straps or ropes to
secure your cargo in the trunk.
Such use may result in damage of
the handle.

Load the trunk so that cargo

cannot strike the release handle.
If the cargo hits the handle while
the vehicle is being driven, the
handle may be pulled and the
trunk lid may open. That may
cause cargo to fall out of the
trunk, which could create a traffic
safety hazard.

– CONTINUED –

Keys and doors/Trunk lid (Legacy)

2-39

(146,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Inspection

Perform the following steps at least twice a
year to check the release handle for
correct operation.
1. Open the trunk lid.

2. Use a flat-head screwdriver with a thin
blade. Slide the flat-head screwdriver
blade from the slit aperture of the lock
assembly fully to the end until you hear a
click.

This places the latch in the locked position.

3. Move the release handle, from outside
the vehicle, in the direction of the arrow to
check if the latch is released.

If the latch is not released, contact your

SUBARU dealer.
In that case, use the key to release the
latch, then close the trunk lid.
Also, if the movement of the release
handle feels restricted or not entirely
smooth during operation, or the handle
and/or handle base is cracked, contact
your SUBARU dealer.

Keys and doors/Trunk lid (Legacy)

2-40

(147,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Rear gate (Outback)

Manual rear gate

The rear gate can be locked and unlocked
using any of the following systems.
.

Power door locking switch: Refer to

“Power door locking switches” F2-9.
.

Keyless access with the push-button

start system (if equipped): Refer to “Key-
less access with push-button start system”
F2-10.
.

Remote keyless entry system: Refer to

“Remote keyless entry system” F2-25.

To open:

Rear gate opener button

1. Unlock the rear gate.
2. Press and hold the rear gate opener

button. The rear gate will open slightly.
3. Hold the rear gate and lift it up slowly.

NOTE

If the rear gate cannot be opened due to
a discharged vehicle battery, a mal-
function in the door locking/unlocking
system or other causes, you can unlock
it by manually operating the rear gate
lock release lever. For the procedure,
refer to “Rear gate (Outback) – if the
rear gate cannot be opened” F9-21.

To close:

Lower the rear gate slowly and push down
firmly until the latch engages.
The rear gate can be lowered easily if you
pull it down holding the handle.

WARNING

To prevent dangerous exhaust

gas from entering the vehicle,
always keep the rear gate closed
while the engine is running.

Do not attempt to shut the rear

gate while holding the recessed
grip. Also do not close the rear
gate by pulling the handle from
inside the cargo space. There is a
danger of your hand being
caught and injured.

CAUTION

Do not jam a plastic bag in or

place cellophane tape on the rear
gate stays or scratch the stays
while loading or unloading cargo.
That could cause leakage of gas
from the stays, which may result
in their inability to hold the rear
gate open.

Be careful not to hit your head or

face on the rear gate when open-
ing or closing the rear gate and
when loading or unloading cargo.

– CONTINUED –

Keys and doors/Rear gate (Outback)

2-41

(148,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Power rear gate (if equipped)

WARNING

When operating the power rear

gate, observe the following pre-
cautions. Ignoring the precau-
tions may result in an injury (e.
g., anyone’s body is hit against
the rear gate or is caught in the
rear gate, etc.)

– Make sure there are no people

around the rear gate.

– Never let anyone get close to

the rear gate.

When closing the rear gate, be

extremely careful to prevent any-
one’s fingers, arms, neck, head
or other objects from being
caught in the rear gate. Other-
wise, serious personal injury may
be caused by entrapment.

After opening the rear gate on a

slope by using the power rear
gate feature, the rear gate may
close. Make sure that the rear
gate has stopped completely
after opening it.

When leaving the vehicle, always

carry the key for safety and never
allow an unattended child to

remain in the vehicle. Failure to
follow this procedure could re-
sult in injury to a child operating
the power rear gate.

The driver should be aware of and

pay careful attention to his/her
responsibilities.

Use the power rear gate only

when the area around the rear
gate is clearly visible and when
you have checked that there is no
danger of people being caught in
the gate.

CAUTION

When closing the rear gate after

opening it, make sure to use the
power rear gate. If you close the
rear gate manually with extra
force, the power rear gate may
be damaged.

Do not install any accessories

other than genuine SUBARU
parts on the rear gate. If the
weight of rear gate increases
excessively, the rear gate stay
cannot support the rear gate
sufficiently when opening the
rear gate. Also, the power rear
gate may not function properly or

may malfunction.

Do not touch the driving rod.

Doing so may result in injury or
damage.

The power rear gate operates only when
all of the following conditions are satisfied.
.

The vehicle is stopped completely.

The outside temperature is within a

range from −228F to 1408F (from −308C to
608C).
.

The ignition switch is in the “LOCK”/

“OFF” or “ACC” position. Or, the ignition
switch is in the “ON” position and the select
lever is in the “P” position.

We recommend using the power rear gate
function in most circumstances instead of
manual operation.

NOTE

Do not press the power rear gate

button repeatedly while the power rear
gate is operating. Otherwise, the sys-
tem may ignore the button operation in
order to avoid being damaged.
.

It is not possible to stop the rear gate

temporarily while opening between the
completely closed position and ap-
proximately 2 in (5 cm) open. If you
press one of the power rear gate
buttons briefly during this range, the

Keys and doors/Rear gate (Outback)

2-42

(149,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

rear gate will be closed.
.

If the vehicle starts to move while the

power rear gate is operating, the sys-
tem sounds a buzzer and closes the
rear gate automatically. At this time, if
the system detects jamming, it will
deactivate the power rear gate and the
rear gate will not be closed. If this
occurs, close the rear gate manually.
For details, refer to “Manual rear gate”
F2-41.
.

If you try to open the rear gate using

the power rear gate function immedi-
ately after closing the rear gate using
the power rear gate function, an elec-
tronic chirp will sound and the rear gate
will not open. Wait for a while before
trying to open the rear gate via the
power rear gate function.
.

If either of the operating conditions

has not been satisfied while operating
the power rear gate, an electronic chirp
will sound and the power rear gate will
be deactivated. In this case, the rear
gate may stop opening or closing
suddenly.

Operation

NOTE

The rear gate will remain unlocked

even after closing it. Always lock the
rear gate when leaving the vehicle.
.

If you cannot open/close the rear

gate by performing the operation de-
scribed here, a short electronic chirp
will sound three times (beep, beep,
beep).

By the power rear gate button
(other than the buttons on the
rear gate)

Power rear gate button on the instrument
panel

Power rear gate button on the access key
fob

Power rear gate button on the transmitter

To open the rear gate:
Press and hold the power rear gate button
when the rear gate is closed. The rear gate

– CONTINUED –

Keys and doors/Rear gate (Outback)

2-43

(150,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

will open automatically. Then an electronic
chirp and the hazard warning flashers will
operate as follows:
.

When operating the power rear gate

button on the instrument panel/transmitter:
sounds and flashes twice.
.

When operating the power rear gate

button on the access key fob: sounds and
flashes four times.

NOTE

While the rear gate is locked, you

cannot open the rear gate by operating
the power rear gate button on the
instrument panel. In such a case,
unlock the rear gate before operating
the power rear gate button.
.

You can disable the “

” button on

the access key fob/transmitter. We
recommend that you contact your
SUBARU dealer to change the setting.

To stop the rear gate midway:
Briefly press the power rear gate button
while the rear gate is being opened. Then
an electronic chirp will sound twice and the
hazard warning flashers will flash twice.
If you press the power rear gate button
again, the rear gate will close.
You can open the rear gate by pressing the
power rear gate button briefly while the
rear gate is being closed.

To close the rear gate:
Press and hold the power rear gate button.
Then an electronic chirp will sound twice
and the hazard warning flashers will flash
twice. If you briefly press the power rear
gate button again, the rear gate will open.

By the buttons on the rear gate

NOTE

After performing the following proce-
dures, an electronic chirp will sound
twice and the hazard warning flashers
will flash twice.

Rear gate opener button

Power rear gate button on the inside edge
of the rear gate

To open the rear gate:
1. For models with “keyless access with
push-button start system”, carry the ac-
cess key fob. For models without “keyless
access with push-button start system”,
unlock the rear gate.
2. Briefly press the rear gate opener
button when the rear gate is closed.

The rear gate will open automatically.

To stop the rear gate midway:
Briefly press either of the following buttons
while the rear gate is being opened.
.

rear gate opener button

power rear gate button on the inside

edge of the rear gate

Keys and doors/Rear gate (Outback)

2-44

(151,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

If you press the power rear gate button
again, the rear gate will close. You can
open the rear gate by pressing the power
rear gate button briefly while the rear gate
is being closed.

To close the rear gate:
Briefly press either of the following but-
tons.
.

rear gate opener button

power rear gate button on the inside

edge of the rear gate

If you press the power rear gate button
again, the rear gate will open.

Manual operation

NOTE

Using the power rear gate operation is
recommended. Manual operation will
require physical effort.

The power rear gate can be closed
manually. Refer to “Manual rear gate”
F2-41.

Memory function

Memory switch

Memory switch status
1)

ON status

OFF status

Your desired rear gate height can be

registered.
Registration of the rear gate height:
To register the rear gate height, perform
the following procedures while the ignition
switch is in the “LOCK”/“OFF” position.
1. Open the rear gate by using the power
rear gate function.
2. With the rear gate at the desired
height, stop it by using the power rear gate
function.
3. Press the memory switch to select the
“ON” status.

Power rear gate button on the inside edge
of the rear gate

4. With the rear gate at the desired
height, press and hold the power rear gate
button on the inside edge of the rear gate
until an electronic chirp is heard and the

– CONTINUED –

Keys and doors/Rear gate (Outback)

2-45

Subaru Outback (2019 year). Instruction - part 9
