RS-2
General Description
REAR SUSPENSION
1. General Description
A: SPECIFICATION
Refer to “FS” section for rear suspension specifica-
tions. <Ref. to FS-2, SPECIFICATION, General
Description.>
NOTE:
• Front and rear toe-in and front camber can be
adjusted. Adjust if the toe-in or camber tolerance
exceeds specifications.
• Other items indicated in the specifications table
cannot be adjusted. If other items exceed specifica-
tions, check the suspension parts and connections
for deformation, and replace with new parts as re-
quired.
(1) Front
A – B = Positive: Toe-in, Negative: Toe-out
D = Individual toe angles
B
A
(1)
FS-00269
