FU(H6DO)-67 Fuel Delivery and Evaporation Lines FUEL INJECTION (FUEL SYSTEMS) 2. CONNECTING THE FUEL DELIVERY Connect the fuel delivery hose to the pipe with an L1: 2.5 r 1.5 mm (0.098 r 0.059 in) L2: 22.5 r 2.5 mm (0.886 r 0.098 in) CAUTION: 3. CONNECTING THE EVAPORATION HOSE Connect the evaporation hose to the pipe with an L = 17.5 r 2.5 mm (0.689 r 0.098 in) C: INSPECTION 1) Make sure that there are no cracks on the fuel (A) Connector (B) Retainer (C) Pipe (1) Type A (2) Type B (3) Pipe (4) Clamp (5) Hose FU-00127 ( A ) ( B ) ( C ) FU-03390 (3) (4) (5) L2 (1) (2) L1 L1 (1) Hose (2) Clip (3) Pipe FU-00129 (1) (2) L/2 L (3) |
