GD(H4SO)-182 Diagnostic Trouble Code (DTC) Detecting Criteria GENERAL DESCRIPTION DI: DTC P2101 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/ PERFORMANCE 1. OUTLINE OF DIAGNOSIS Judge as NG when the motor current becomes large or drive circuit is heated. 2. COMPONENT DESCRIPTION 3. ENABLE CONDITION 4. GENERAL DRIVING CYCLE Always perform the diagnosis continuously. 5. DIAGNOSTIC METHOD Judge as OK and clear the NG when the malfunction criteria below are met. Time Needed for Diagnosis: (1) Engine control module (ECM) (4) Drive circuit (6) Electronic throttle control relay (2) Detecting circuit (5) Temperature detection circuit (7) Motor (3) Overcurrent detection circuit
Secondary Parameters Enable Conditions Under control of electronic throttle control ON Judgement Value Malfunction Criteria Threshold Value Motor current d 8 A Drive circuit inner temperature d 175°C (347°F) EN-01867 (3) (2) (5) (2) (4) (1) (6) (7) 12V 12V |
