WI-12 Basic Diagnostic Procedure WIRING SYSTEM E: CONNECTOR SYMBOL IN WIRING HARNESS A number of connector symbols are used in each wiring diagram to easily identify the wiring harness con- WI-02756 Standard type: Female Standard type: Male Water proof type: Female Water proof type: Male Pole: From 1 to 8 Pole: From 9 to 20 Pole: More than 21 Pole: From 1 to 8 Pole: From 9 to 20 Pole: More than 21 |
