Subaru Legacy IV (2008 year). Manual - part 1087

BS-36

Anticorrosion Wax

BODY STRUCTURE

6. Anticorrosion Wax

A: SPECIFICATION

Used material:

Rust-stop aerosol (K0877YA015)

• Front hood

• Door (front, rear)

(a)

Application thickness = 50 μm or
more

(b)

Application area

(c)

Non-application area (only for
OUTBACK model)

(1)

Wax application work openings

(2)

10 mm (0.39 in)

(3)

60 mm (2.36 in)

(a)

Wax filling part

(b)

Application area

(1)

Wax application work openings

(3)

50 mm (1.97 in)

(4)

90 mm (3.54 in)

(2)

10 mm (0.39 in)

BS-03622

(1)

(2)

(3)

A-A

:(b)

:(a)

(c)

BS-02098

(1)

(2)

(3)

B-B

:(b)

:(a)

(4)

BS-37

Anticorrosion Wax

BODY STRUCTURE

• Rear gate

• Trunk

(a)

Wax filling part

(b)

Application area

(1)

Wax application work openings

(2)

10 mm (0.39 in)

(3)

40 mm (1.57 in)

(a)

Wax filling part

(b)

Application area

(1)

Wax application work openings

(2)

10 mm (0.39 in)

(3)

100 mm (3.94 in)

:(b)

:(a)

(1)

(3)

(2)

C-C

(2)

BS-03630

BS-02100

:(b)

:(a)

(1)

D-D

(2)

(3)

BS-38

Anticorrosion Wax

BODY STRUCTURE

• Front hood hinge
Apply around the installation outer circumference
(indicated range) at two locations on the left and
right.

• Door hinge
Apply to the installation outer circumference at two
locations at the top and bottom (all eight locations).

• Rear gate hinge
Apply around the installation outer circumference
(plate edges) at two locations on the left and right.

(a) Application thickness = 15 μm or

:(a)

BS-03623

BS-02101

:(a)

BS-02102

:(a)

BS-39

Anticorrosion Wax

BODY STRUCTURE

• Overall view

(A)

View A

(B)

View B

(C)

Section C — C

(1)

Apply to the contact surface
between the front suspension
bracket and duct. (15 μm or more)

(2)

Closing plate

(4)

Reinforcement

(3)

Front side frame front

(5)

10 mm (0.39 in)

BS-01426

(A)

(B)

(C)

(5)

(1)

(2)

(3)

(4)
