General Description

OCCUPANT DETECTION SYSTEM (DIAGNOSTICS)

C: PREPARATION TOOL

CAUTION:
To measure the voltage and resistance of airbag system and occupant detection system compo-
nents, be sure to use the specified test harness.

1. SPECIAL TOOL

• TEST HARNESS D

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

1B022XU0

SUBARU SELECT
MONITOR III KIT

Used for troubleshooting the electrical system.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299AG060

TEST HARNESS D

Used when measuring voltage and resistance of
the front seat belt buckle switch.

ST1B022XU0

3D

2D

1D

ST98299AG060

AB-01068

5

1

2

2

1

6

3

4

1

2

1

2

3D

3D

2D

1D

1D

2D

1
3 4 5 6

2

OD(diag)-6

General Description

OCCUPANT DETECTION SYSTEM (DIAGNOSTICS)

• TEST HARNESS Y

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299AG040

TEST HARNESS Y

Used for troubleshooting seat belt buckle switch.

ST98299AG040

2Y

1Y

1Y

1Y

2Y

2Y

AB-01069

1

2

1

2

1

2

1

2

OD(diag)-7

General Description

OCCUPANT DETECTION SYSTEM (DIAGNOSTICS)

• TEST HARNESS AB

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299XA000

TEST HARNESS
AB

Used when measuring voltage and resistance of
occupant detection system.

ST98299XA000

OD-00029

1AB

2AB

4

3

2

1

6

5

4

3

2

1

6

5

6

5

3

2

4

1

4

5

1

2

6

3

OD(diag)-8

General Description

OCCUPANT DETECTION SYSTEM (DIAGNOSTICS)

• TEST HARNESS AE

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299XA030

TEST HARNESS
AE

Test harness Y adapter harness
Used for troubleshooting seat belt buckle switch.

ST98299XA030

OD-00026

1AE

2AE

2

1

1

2

2

1

1

2
