EI-26
EXTERIOR/INTERIOR TRIM
PROTECTOR
B: INSTALLATION
1) Apply primer to original side protector (if used),
and attach two-sided tape to side protectors as
shown.
Two-sided tape:
Thickness; 1.2 mm (0.047 in)
Width; 5 mm (0.20 in)
Recommended primer:
SUMITOMO 3MK-500 or equivalent
Recommended two-sided tape:
SUMITOMO 3M5305 or equivalent
2) Using an infrared lamp, heat body panel to 40 to
60
°
C (104 to 140
°
F) and rear surface of side pro-
tector to 20 to 30
°
C (68 to 86
°
F).
3) Remove tack paper from two-sided paper. While
aligning clips with holes in body panel, attach two-
sided tape to side protector and body panel with a
force of more than 49 N (5 kgf, 11 lb) with roller. Do
not allow air to enter mating surface of the two.
CAUTION:
• To maintain adhesive power, do not wash the
vehicle for 24 hours after tape application.
• Push clip in securely using hands.
(To prevent deformation, do not use excessive
force.)
(1) Front door part
(2) Rear door part
EI-00157
( 1 )
( 2 )
