EX(H4SOw/oOBD)-14
EXHAUST
MUFFLER
5. Muffler
A: REMOVAL
1) Separate muffler from rear exhaust pipe.
CAUTION:
Be careful, exhaust pipe is hot.
2) Remove left and right rubber cushions.
CAUTION:
Be careful not to drop the muffler during remov-
al.
NOTE:
To facilitate removal, apply a coat of SUBARU
CRC to mating area of rubber cushions in advance.
SUBARU CRC (Part No. 004301003)
3) Remove front rubber cushion, and detach muf-
fler assembly.
NOTE:
To facilitate removal, apply a coat of SUBARU
CRC to mating area of rubber cushion in advance.
SUBARU CRC (Part No. 004301003)
B: INSTALLATION
1) Install in the reverse order of removal.
NOTE:
Replace gasket with a new one.
Tightening torque:
48 N·m (4.9 kgf-m, 35.4 ft-lb)
C: INSPECTIOIN
1) Make sure there are no exhaust leaks from con-
nections and welds.
2) Make sure there are no holes or rusting.
3) Make sure the cushion rubber is not worn or
cracked.
EX-00051
EX-00052
EX-00053
EX-00051
