Subaru Impreza 3 / Impreza WRX / Impreza WRX STI. Manual - part 363
GD(H4DOTC)-204
Diagnostic Trouble Code (DTC) Detecting Criteria
GENERAL DESCRIPTION
DR:DTC P0852 NEUTRAL SWITCH INPUT CIRCUIT HIGH (MT MODEL)
1. OUTLINE OF DIAGNOSIS
Detect the open or short circuit of neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral
SW ON/OFF inversion from the vehicle speed and engine speed.)
2. ENABLE CONDITIONS
3. GENERAL DRIVING CYCLE
Perform the diagnosis continuously in 2 seconds after starting the engine.
4. DIAGNOSTIC METHOD
• Abnormality Judgment
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW
change.
Time Needed for Diagnosis: 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cy-
cles.
• Normality Judgment
Judge as OK and clear NG when there is change in the neutral SW.
Time Needed for Diagnosis: Less than 1 second
Secondary Parameters
Enable Conditions
Battery voltage
≥ 10.9 V
Starter relay
OFF
Judgment Value
Malfunction Criteria
Threshold Value
Neutral switch signal (while changing from a to b below)
HIGH (OFF) continues.
Driving condition change
From a) to b)
a) Engine speed 600 rpm — 900 rpm & Vehicle speed = 0 km/h (0 MPH)
b) Engine speed 1600 rpm — 2550 rpm & Vehicle speed ≥ 64 km/h (39.8 MPH)
Judgment Value
Malfunction Criteria
Threshold Value
Neutral switch signal (while changing from a to b below)
Changes to LOW (ON).
Driving condition change
From a) to b)
a) Engine speed 600 rpm — 900 rpm & Vehicle speed = 0 km/h (0 MPH)
b) Engine speed 1600 rpm — 2550 rpm & Vehicle speed ≥ 64 km/h (39.8 MPH)
