EN(H4DOTC)(diag)-88
List of Diagnostic Trouble Code (DTC)
ENGINE (DIAGNOSTICS)
P0068
MAP/MAF - Throttle Position
Correlation
<Ref. to EN(H4DOTC)(diag)-119, DTC P0068 MAP/MAF - THROTTLE POSITION
CORRELATION, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0101
Mass or Volume Air Flow Circuit
Range/Performance
<Ref. to EN(H4DOTC)(diag)-120, DTC P0101 MASS OR VOLUME AIR FLOW CIR-
CUIT RANGE/PERFORMANCE, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>
P0102
Mass or Volume Air Flow Circuit
Low Input
<Ref. to EN(H4DOTC)(diag)-121, DTC P0102 MASS OR VOLUME AIR FLOW CIR-
CUIT LOW INPUT, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0103
Mass or Volume Air Flow Circuit
High Input
<Ref. to EN(H4DOTC)(diag)-124, DTC P0103 MASS OR VOLUME AIR FLOW CIR-
CUIT HIGH INPUT, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0107
Manifold Absolute Pressure/
Barometric Pressure Circuit
Low Input
<Ref. to EN(H4DOTC)(diag)-126, DTC P0107 MANIFOLD ABSOLUTE PRESSURE/
BAROMETRIC PRESSURE CIRCUIT LOW INPUT, Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>
P0108
Manifold Absolute Pressure/
Barometric Pressure Circuit
High Input
<Ref. to EN(H4DOTC)(diag)-129, DTC P0108 MANIFOLD ABSOLUTE PRESSURE/
BAROMETRIC PRESSURE CIRCUIT HIGH INPUT, Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>
P0111
Intake Air Temperature Sensor
Range/Performance Problem
<Ref. to EN(H4DOTC)(diag)-132, DTC P0111 INTAKE AIR TEMPERATURE SEN-
SOR RANGE/PERFORMANCE PROBLEM, Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>
P0112
Intake Air Temperature Sensor
1 Circuit Low
<Ref. to EN(H4DOTC)(diag)-133, DTC P0112 INTAKE AIR TEMPERATURE SEN-
SOR 1 CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0113
Intake Air Temperature Sensor
1 Circuit High
<Ref. to EN(H4DOTC)(diag)-135, DTC P0113 INTAKE AIR TEMPERATURE SEN-
SOR 1 CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0116
Engine Coolant Temp. Sensor
Circuit Range/Performance
<Ref. to EN(H4DOTC)(diag)-137, DTC P0116 ENGINE COOLANT TEMPERATURE
SENSOR 1 CIRCUIT RANGE/PERFORMANCE, Diagnostic Procedure with Diagnos-
tic Trouble Code (DTC).>
P0117
Engine Coolant Temperature
Circuit Low
<Ref. to EN(H4DOTC)(diag)-138, DTC P0117 ENGINE COOLANT TEMPERATURE
CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0118
Engine Coolant Temperature
Circuit High
<Ref. to EN(H4DOTC)(diag)-140, DTC P0118 ENGINE COOLANT TEMPERATURE
CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0122
Throttle/Pedal Position Sensor/
Switch “A” Circuit Low
<Ref. to EN(H4DOTC)(diag)-142, DTC P0122 THROTTLE/PEDAL POSITION SEN-
SOR/SWITCH “A” CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>
P0123
Throttle/Pedal Position Sensor/
Switch “A” Circuit High
<Ref. to EN(H4DOTC)(diag)-145, DTC P0123 THROTTLE/PEDAL POSITION SEN-
SOR/SWITCH “A” CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>
P0125
Insufficient Coolant Tempera-
ture for Closed Loop Fuel Con-
trol
<Ref. to EN(H4DOTC)(diag)-148, DTC P0125 INSUFFICIENT COOLANT TEMPER-
ATURE FOR CLOSED LOOP FUEL CONTROL, Diagnostic Procedure with Diagnos-
tic Trouble Code (DTC).>
P0128
Coolant Thermostat (Engine
Coolant Temperature Below
Thermostat Regulating Temper-
ature)
<Ref. to EN(H4DOTC)(diag)-149, DTC P0128 COOLANT THERMOSTAT (ENGINE
COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERA-
TURE), Diagnostic Procedure with Diagnostic Trouble Code (DTC).>
P0131
O2 Sensor Circuit Low Voltage
(Bank 1 Sensor 1)
<Ref. to EN(H4DOTC)(diag)-150, DTC P0131 O2 SENSOR CIRCUIT LOW VOLT-
AGE (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>
P0132
O2 Sensor Circuit High Voltage
(Bank 1 Sensor 1)
<Ref. to EN(H4DOTC)(diag)-153, DTC P0132 O2 SENSOR CIRCUIT HIGH VOLT-
AGE (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>
P0134
O2 Sensor Circuit No Activity
Detected (Bank 1 Sensor 1)
<Ref. to EN(H4DOTC)(diag)-155, DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY
DETECTED (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>
P0137
O2 Sensor Circuit Low Voltage
(Bank 1 Sensor 2)
<Ref. to EN(H4DOTC)(diag)-158, DTC P0137 O2 SENSOR CIRCUIT LOW VOLT-
AGE (BANK 1 SENSOR 2), Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>
DTC
Item
Note
