INSTRUMENTATION/DRIVER INFO

Combination Meter System

Step 3-1. Press the trip knob, and hold it: Check illumination

Keep the posi-
tion that speci-
fied at step 2-2.

Light OFF

Varying from the
highest bright-
ness (ILL6) to
the lowest lumi-
nescence (ILL1)
every second.
After reaching at
ILL1, repeat it
from ILL6.

Illumination
brightness is
displayed. (From
ILL6 to ILL1)

“

▼3” is dis-

played.

Varying from the
highest bright-
ness (ILL6) to
the lowest lumi-
nescence (ILL1)
every second.
After reaching at
ILL1, repeat it
from ILL6.

Not beep.

Step 3-2. Release the trip knob: Specifying the illumination brightness

Keep the posi-
tion that speci-
fied at step 2-2.

Light OFF

Keep the bright-
ness at the time
when the trip
knob is
released.

Display the
brightness at the
time when the
trip knob is
released.

“3” is displayed.

Keep the bright-
ness at the time
when the trip
knob is
released.

Not beep.

Step 4-1. Press the trip knob: Check the beeping of SPORT shift buzzer (AT model)

All meter indica-
tor needle
returns to lowest
position.

Light OFF

Light at the
highest bright-
ness. Keep the
position indi-
cated that set in
step 1-2.

Illumination
brightness is
displayed.

“

▲▼8” is dis-

played. Blinks
with buzzer.

Light at the
highest bright-
ness.

SPORT shift
buzzer beeps.

Step 4-2. Press the trip knob: Check the VDC indicator light (Model with VDC)

All meter indica-
tor needle
returns to lowest
position.

VDC warning
light and VDC
operation indica-
tor light blink.

Light at the
highest bright-
ness. Keep the
position indi-
cated that set in
step 1-2.

Illumination
brightness is
displayed.

“4” is displayed.

Light at the
highest bright-
ness.

Not beep.

Step 4-3. Press the trip knob: Check the speed warning buzzer (KS model)

Speedometer
indicates the
vehicle speed,
which was
detected when
the speed warn-
ing started.

Light OFF

Light at the
highest bright-
ness. Keep the
position indi-
cated that set in
step 1-2.

Illumination
brightness is
displayed.

“4” is displayed.

Light at the
highest bright-
ness.

Speed warning
buzzer beeps.

Step 5. Press the trip knob: Complete the self-diagnosis 1 cycle

All meter indicator needle returns to lowest position, and go back to step 1 after completion.

Speedometer,
tachometer, fuel
gauge, engine
coolant temper-
ature gauge

Microcomputer
running type
warning light,
indicator light

AT select lever
position indica-
tor light

Odo/Trip indica-
tor

SPORT shift
indicator

Illumination
(indicator nee-
dle, plate, ring,
LCD)

Buzzer (SPORT
shift buzzer,
speed warning
buzzer)

IDI-6

Vehicle-id:
SIE-id:S907607a10:B:INSPECTION
∼

INSTRUMENTATION/DRIVER INFO

Combination Meter System

• Illuminating order table

3. SYMPTOM CHART

CAUTION:
When measuring the voltage and resistance of each control module or sensor, use a tapered pin with
a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert the pin of more
than 2 mm (0.08 in) in diameter.

Illuminating
order

1

2

3

4

5

6

7

8

9

10

11

Go back

to 1 and

repeat

Trip  meter  A/B

AB

A

B

A

B

A

B

A

B

A

B

Odo/trip meter

8888.8

888888

00000

000000

1111.1

111111

22222

222222

3333.3

333333

44444

444444

5555.5

555555

66666

666666

7777.7

777777

88888

888888

9999.9

999999

SPORT shift
indicator

8

1

2

3

4

5

1

2

3

4

5

▲

▲

▲

▲

▲

▲

▲

▼

▼

▼

▼

▼

▼

▼

AT select lever
position indica-
tor

P

P

R

R

R

N

N

N

D

D

D

Display time
(sec.)

1

0.5

0.5

0.5

0.5

0.5

0.5

0.5

0.5

0.5

0.5

Symptom

Repair order

Reference

Combination meter assembly does not operate.

(1) Power supply
(2) Ground circuit
(3) Combination meter

<Ref. to IDI-7, CHECK
POWER SUPPLY AND
GROUND CIRCUIT,
INSPECTION, Combi-
nation Meter System.>

Speedometer does not operate.

(1) ABSCM or VDCCM
(2) Harness
(3) Combination meter

<Ref. to IDI-7, CHECK
ABSCM OR VDCCM,
INSPECTION, Combi-
nation Meter System.>

Tachometer does not operate.

(1) ECM
(2) Harness
(3) Combination meter

<Ref. to IDI-8, CHECK
ENGINE CONTROL
MODULE, INSPEC-
TION, Combination
Meter System.>

Fuel gauge does not operate.

(1) Communication circuit
(2) Fuel level sensor
(3) Harness
(4) Combination meter

<Ref. to IDI-8, CHECK
FUEL LEVEL SEN-
SOR., INSPECTION,
Combination Meter
System.>

Engine coolant temperature gauge does not oper-
ate.

(1) Communication circuit
(2) Engine coolant temperature sensor
(3) Harness
(4) Combination meter

<Ref. to IDI-10, CHECK
ENGINE COOLANT
TEMPERATURE SEN-
SOR., INSPECTION,
Combination Meter
System.>

Error display is shown on the odo/trip meter.

Communication circuit

<Ref. to IDI-10, COM-
MUNICATION ERROR
DISPLAY, INSPEC-
TION, Combination
Meter System.>

IDI-7

INSTRUMENTATION/DRIVER INFO

Combination Meter System

4. CHECK POWER SUPPLY AND GROUND CIRCUIT

5. CHECK ABSCM OR VDCCM

Step

Check

Yes

No

1

CHECK POWER SUPPLY FOR COMBINA-
TION METER.
1) Remove the combination meter. <Ref. to
IDI-15, REMOVAL, Combination Meter.>
2) Disconnect the combination meter harness
connector.
3) Turn the ignition switch to ON.
4) Measure the voltage between combination
meter connector and chassis ground.

Connector & terminal

(i10) No. 3, No. 4 (+) — Chassis ground (

−

):

Is the voltage more than 10 V? Go to step 2.

Check the harness
for open or short
between the igni-
tion switch and
combination
meter.

2

CHECK POWER SUPPLY FOR COMBINA-
TION METER.
Measure the voltage between combination
meter connector and chassis ground.

Connector & terminal

(i10) No. 1, No. 2 (+) — Chassis ground (

−

):

Is the voltage more than 10 V? Go to step 3.

Check the harness
for open or short
between the fuse
and combination
meter.

3

CHECK GROUND CIRCUIT OF COMBINA-
TION METER.
1) Turn the ignition switch to OFF.
2) Measure the resistance of harness
between combination meter connector and
chassis ground.

Connector & terminal

(i10) No. 11, No. 12 — Chassis ground:

Is the resistance less than 10
Ω?

Replace the meter
case assembly.

Repair the wiring
harness.

Step

Check

Yes

No

1

CHECK VEHICLE SPEED SIGNAL.
1) Lift up the vehicle and support it with rigid
racks.
2) Drive the vehicle faster than 10 km/h (6
MPH).

Warning:

Be careful not to get caught in the running
wheels.

3) Measure the voltage between combination
meter connector and chassis ground.

Connector & terminal

(i10) No. 19 (+) — Chassis ground (

−

):

Is the voltage less than 1 V
←→ 5 V or more?

Replace the meter
case assembly.

Go to step 2.

2

CHECK HARNESS BETWEEN ABSCM OR
VDCCM AND COMBINATION METER.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ABSCM or
VDCCM and combination meter.
3) Measure the resistance between ABSCM
or VDCCM harness connector and combina-
tion meter harness connector.

Connector & terminal

Model without VDC

(B301) No. 23 — (i10) No. 19:

Model with VDC

(B310) No. 36 — (i10) No. 19:

Is the resistance less than 10
Ω?

Model without
VDC: Check the
ABSCM. <Ref. to
ABS(diag)-2,
Basic Diagnostic
Procedure.>
Model with VDC:
Check the
VDCCM. <Ref. to
VDC(diag)-2,
Basic Diagnostic
Procedure.>

Repair the wiring
harness.

IDI-8

Vehicle-id:
SIE-id:S907607a10:B:INSPECTION
∼

INSTRUMENTATION/DRIVER INFO

Combination Meter System

6. CHECK ENGINE CONTROL MODULE

7. CHECK FUEL LEVEL SENSOR.

Step

Check

Yes

No

1

CHECK ECM SIGNAL.
1) Start the engine.
2) Measure the voltage between ECM con-
nector and chassis ground.

Connector & terminal

2.0 L non-turbo model and 2.5 L KS, KA
model

(B135) No. 27 (+) — Chassis ground (

−

):

2.0 L turbo model, 3.0 L model and 2.5 L
EC, K4, EK model

(B134) No. 23 (+) — Chassis ground (

−

):

Is the voltage more than 0

←→

14 V?

Go to step 2.

Check the ECM.
<Ref. to EN(H4SO
2.0)(diag)-2, Basic
Diagnostic Proce-
dure.> <Ref. to
EN(H4SO
2.5)(diag)-2, Basic
Diagnostic Proce-
dure.> <Ref. to
EN(H4DOTC)(diag
)-2, Basic Diag-
nostic Proce-
dure.> <Ref. to
EN(H6DO)(diag)-
2, Basic Diagnos-
tic Procedure.>

2

CHECK HARNESS BETWEEN COMBINA-
TION METER AND ECM.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM and
combination meter.
3) Measure the resistance between ECM har-
ness connector and combination meter har-
ness connector.

Connector & terminal

2.0 L non-turbo model and 2.5 L KS, KA
model

(B135) No. 27 — (i10) No. 20:

2.0 L turbo model, 3.0 L model and 2.5 L
EC, K4, EK model

(B134) No. 23 — (i10) No. 20:

Is the resistance less than 10
Ω?

Replace the meter
case assembly.

Repair the wiring
harness.

Step

Check

Yes

No

1

CHECK COMMUNICATION ERROR DIS-
PLAY.
1) Set the ignition switch to ON.
2) Check that the error code is displayed in
odo/trip meter.

Is the error code “Er xx” dis-
played in odo/trip meter?

Check the commu-
nication circuit.
<Ref. to IDI-10,
COMMUNICA-
TION ERROR
DISPLAY,
INSPECTION,
Combination
Meter System.>

Go to step 2.

2

CHECK FUEL LEVEL SENSOR.
1) Remove the fuel level sensor. <Ref. to
FU(H4SO 2.0)-49, REMOVAL, Fuel Level Sen-
sor.> <Ref. to FU(H4SO 2.5)-52, REMOVAL,
Fuel Level Sensor.> <Ref. to FU(H4DOTC)-50,
REMOVAL, Fuel Level Sensor.> <Ref. to
FU(H6DO)-50, REMOVAL, Fuel Level Sen-
sor.>
2) Measure the resistance between fuel level
sensor terminals when the float is in FULL or
EMPTY position.

Terminals

No. 1 — No. 4:

Is the resistance 1.0 — 3.0

Ω

(FULL) or 31 — 33

Ω

(EMPTY)?

Go to step 3.

Replace the fuel
level sensor.
