CL-43 CLUTCH SYSTEM Clutch Switch 11.Clutch Switch A: REMOVAL 1) Disconnect the ground cable from battery. B: INSTALLATION 1) Install the clutch switch so that the clearance Tightening torque: 8 N ⋅ m (0.8 kgf-m, 5.8 ft-lb) 2) Measure the stroke of clutch pedal. Specified clutch pedal full stroke A: Non-turbo model 130 — 135 mm (5.12 — 5.31 in) Turbo model 135 — 140 mm (5.31 — 5.51 in) 3) If the clutch pedal stroke is out of specification, C: INSPECTION Check the clutch switch continuity. If the continuity D: ADJUSTMENT Refer to “ADJUSTMENT” for clutch pedal. <Ref. to (A) Clutch switch (B) Stopper (C) 0 mm (0 in) (A) Clutch pedal (at full stroke condition) (B) Scale (C) Seat CL-00133 (A) (B) (C) CL-00078 (A) (B) (C) A Condition Terminal No. Specified resis- tance When clutch pedal No. 1 — No. 2 More than 1 M Ω When clutch pedal No. 1 — No. 2 Less than 1 Ω CL-00084 2 1 |
