Subaru Legacy (2005 year). Manual - part 363

FU(H6DO)-5

FUEL INJECTION (FUEL SYSTEMS)

General Description

3. AIR INTAKE SYSTEM

(1)

O-ring

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Throttle body

T: 8 (0.8, 5.9)

FU-02109

(1)

(2)

T

FU(H6DO)-6

FUEL INJECTION (FUEL SYSTEMS)

General Description

4. CRANKSHAFT POSITION, CAMSHAFT POSITION AND KNOCK SENSORS

(1)

Crankshaft position sensor

(6)

Variable valve lift diagnosis oil
pressure switch RH

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Knock sensor RH

T1: 6.4 (0.65, 4.7)

(3)

Knock sensor LH

(7)

Variable valve lift diagnosis oil
pressure switch LH

T2: 17 (1.7, 12.5)

(4)

Camshaft position sensor RH

T3: 18 (1.8, 13)

(5)

Camshaft position sensor LH

(8)

Oil temperature sensor

T4: 25 (2.5, 18)

FU-02110

(6)

(4)

T2

T1

(3)

T4

(1)

(8)

T1

T3

(5)

T1

(2)

T4

(7)

T2

FU(H6DO)-7

FUEL INJECTION (FUEL SYSTEMS)

General Description

5. FUEL TANK

FU-01080

T4

T1

T4

T3

T3

T3

T2

T3

T3

T4

T1

(16)

(14)

(15)

(15)

(17)

(18)

(19)

(17)

(6)

(22)

(5)

(4)

(3)

(23)

(24)

(25)

(2)

(20)

(21)

(11)

(12)

(13)

(8)

(7)

(10)

(9)

(1)

T2

T3

(22)

FU(H6DO)-8

FUEL INJECTION (FUEL SYSTEMS)

General Description

(1)

Fuel tank

(12)

Fuel sub level sensor upper plate

(23)

Heat shield cover

(2)

Fuel tank band RH

(13)

Fuel sub level sensor gasket

(24)

Fuel tank protector RH (Front)

(3)

Fuel tank band LH

(14)

Fuel filler hose

(25)

Fuel tank protector LH (Front)

(4)

Delivery tube

(15)

Clamp

(5)

Return tube

(16)

Vent hose

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(6)

Jet pump tube

(17)

Clip

T1: 4.4 (0.45, 3.2)

(7)

Fuel pump ASSY

(18)

Fuel tank protector RH (Rear)

T2: 9 (0.9, 6.6)

(8)

Fuel pump upper plate

(19)

Fuel tank protector LH (Rear)

T3: 17.5 (1.78, 12.9)

(9)

Fuel pump gasket

(20)

Stopper RH

T4: 33 (3.4, 24.3)

(10)

Fuel level sensor

(21)

Stopper LH

(11)

Fuel sub level sensor

(22)

Retainer
