EN(H4SO 2.5)(diag)-73

ENGINE (DIAGNOSTICS)

List of Diagnostic Trouble Code (DTC)

P2011

Intake Manifold Runner Control Cir-
cuit / Open (Bank 2)

<Ref. to EN(H4SO 2.5)(diag)-210, DTC P2011 INTAKE MANIFOLD RUN-
NER CONTROL CIRCUIT / OPEN (BANK 2), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P2012

Intake Manifold Runner Control Cir-
cuit Low (Bank 2)

<Ref. to EN(H4SO 2.5)(diag)-212, DTC P2012 INTAKE MANIFOLD RUN-
NER CONTROL CIRCUIT LOW (BANK 2), Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>

P2016

Intake Manifold Runner Position Sen-
sor / Switch Circuit Low (Bank 1)

<Ref. to EN(H4SO 2.5)(diag)-214, DTC P2016 INTAKE MANIFOLD RUN-
NER POSITION SENSOR / SWITCH CIRCUIT LOW (BANK 1), Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2017

Intake Manifold Runner Position Sen-
sor / Switch Circuit High (Bank 1)

<Ref. to EN(H4SO 2.5)(diag)-217, DTC P2017 INTAKE MANIFOLD RUN-
NER POSITION SENSOR / SWITCH CIRCUIT HIGH (BANK 1), Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2021

Intake Manifold Runner Position Sen-
sor / Switch Circuit Low (Bank 2)

<Ref. to EN(H4SO 2.5)(diag)-219, DTC P2021 INTAKE MANIFOLD RUN-
NER POSITION SENSOR / SWITCH CIRCUIT LOW (BANK 2), Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2022

Intake Manifold Runner Position Sen-
sor / Switch Circuit High (Bank 2)

<Ref. to EN(H4SO 2.5)(diag)-222, DTC P2022 INTAKE MANIFOLD RUN-
NER POSITION SENSOR / SWITCH CIRCUIT HIGH (BANK 2), Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2101

Throttle Actuator Control Motor Cir-
cuit Range/Performance

<Ref. to EN(H4SO 2.5)(diag)-224, DTC P2101 THROTTLE ACTUATOR
CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE, Diagnostic Proce-
dure with Diagnostic Trouble Code (DTC).>

P2102

Throttle Actuator Control Motor Cir-
cuit Low

<Ref. to EN(H4SO 2.5)(diag)-230, DTC P2102 THROTTLE ACTUATOR
CONTROL MOTOR CIRCUIT LOW, Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P2103

Throttle Actuator Control Motor Cir-
cuit High

<Ref. to EN(H4SO 2.5)(diag)-233, DTC P2103 THROTTLE ACTUATOR
CONTROL MOTOR CIRCUIT HIGH, Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P2109

Throttle/Pedal Position Sensor “A”
Minimum Stop Performance

<Ref. to EN(H4SO 2.5)(diag)-234, DTC P2109 THROTTLE/PEDAL POSI-
TION SENSOR “A” MINIMUM STOP PERFORMANCE, Diagnostic Proce-
dure with Diagnostic Trouble Code (DTC).>

P2122

Throttle/Pedal Position Sensor/
Switch “D” Circuit Low Input

<Ref. to EN(H4SO 2.5)(diag)-235, DTC P2122 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “D” CIRCUIT LOW INPUT, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P2123

Throttle/Pedal Position Sensor/
Switch “D” Circuit High Input

<Ref. to EN(H4SO 2.5)(diag)-238, DTC P2123 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “D” CIRCUIT HIGH INPUT, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P2127

Throttle/Pedal Position Sensor/
Switch “E” Circuit Low Input

<Ref. to EN(H4SO 2.5)(diag)-241, DTC P2127 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “E” CIRCUIT LOW INPUT, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P2128

Throttle/Pedal Position Sensor/
Switch “E” Circuit High Input

<Ref. to EN(H4SO 2.5)(diag)-244, DTC P2128 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “E” CIRCUIT HIGH INPUT, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P2135

Throttle/Pedal Position Sensor/
Switch “A”/“B” Voltage Correlation

<Ref. to EN(H4SO 2.5)(diag)-246, DTC P2135 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “A” / “B” VOLTAGE CORRELATION, Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2138

Throttle/Pedal Position Sensor/
Switch “D”/“E” Voltage Correlation

<Ref. to EN(H4SO 2.5)(diag)-251, DTC P2138 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “D” / “E” VOLTAGE CORRELATION, Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P2503

Charging System Voltage Low

<Ref. to EN(H4SO 2.5)(diag)-254, DTC P2503 CHARGING SYSTEM VOLT-
AGE LOW, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P2504

Charging System Voltage High

<Ref. to EN(H4SO 2.5)(diag)-255, DTC P2504 CHARGING SYSTEM VOLT-
AGE HIGH, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

DTC

Item

Reference

EN(H4SO 2.5)(diag)-74

ENGINE (DIAGNOSTICS)

List of Diagnostic Trouble Code (DTC)

2. KA AND KS MODEL

DTC

Item

Reference

P0030

HO2S Heater Control Circuit (Bank 1
Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-69, DTC P0030 HO2S HEATER CONTROL
CIRCUIT (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trou-
ble Code (DTC).>

P0031

HO2S Heater Control Circuit Low
(Bank 1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-71, DTC P0031 HO2S HEATER CONTROL
CIRCUIT LOW (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P0032

HO2S Heater Control Circuit High
(Bank 1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-74, DTC P0032 HO2S HEATER CONTROL
CIRCUIT HIGH (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P0037

HO2S Heater Control Circuit Low
(Bank 1 Sensor 2)

<Ref. to EN(H4SO 2.0)(diag)-76, DTC P0037 HO2S HEATER CONTROL
CIRCUIT LOW (BANK 1 SENSOR 2), Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P0038

HO2S Heater Control Circuit High
(Bank 1 Sensor 2)

<Ref. to EN(H4SO 2.0)(diag)-79, DTC P0038 HO2S HEATER CONTROL
CIRCUIT HIGH (BANK 1 SENSOR 2), Diagnostic Procedure with Diagnostic
Trouble Code (DTC).>

P0107

Manifold Absolute Pressure/Baro-
metric Pressure Circuit Low Input

<Ref. to EN(H4SO 2.0)(diag)-81, DTC P0107 MANIFOLD ABSOLUTE
PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT, Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P0108

Manifold Absolute Pressure/Baro-
metric Pressure Circuit High Input

<Ref. to EN(H4SO 2.0)(diag)-84, DTC P0108 MANIFOLD ABSOLUTE
PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT, Diagnostic
Procedure with Diagnostic Trouble Code (DTC).>

P0112

Intake Air Temperature Sensor 1 Cir-
cuit Low Input

<Ref. to EN(H4SO 2.0)(diag)-87, DTC P0112 INTAKE AIR TEMPERATURE
SENSOR 1 CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>

P0113

Intake Air Temperature Sensor 1 Cir-
cuit High Input

<Ref. to EN(H4SO 2.0)(diag)-89, DTC P0113 INTAKE AIR TEMPERATURE
SENSOR 1 CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>

P0117

Engine Coolant Temperature Circuit
Low

<Ref. to EN(H4SO 2.0)(diag)-92, DTC P0117 ENGINE COOLANT TEM-
PERATURE CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>

P0118

Engine Coolant Temperature Circuit
High

<Ref. to EN(H4SO 2.0)(diag)-94, DTC P0118 ENGINE COOLANT TEM-
PERATURE CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>

P0122

Throttle/Pedal Position Sensor/
Switch “A” Circuit Low

<Ref. to EN(H4SO 2.0)(diag)-96, DTC P0122 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “A” CIRCUIT LOW, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0123

Throttle/Pedal Position Sensor/
Switch “A” Circuit High

<Ref. to EN(H4SO 2.0)(diag)-99, DTC P0123 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “A” CIRCUIT HIGH, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0125

Insufficient Coolant Temperature for
Closed Loop Fuel Control

<Ref. to EN(H4SO 2.0)(diag)-102, DTC P0125 INSUFFICIENT COOLANT
TEMPERATURE FOR CLOSED LOOP FUEL CONTROL, Diagnostic Proce-
dure with Diagnostic Trouble Code (DTC).>

P0130

O2 Sensor Circuit Low Voltage (Bank
1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-104, DTC P0130 O2 SENSOR CIRCUIT
(BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P0131

O2 Sensor Circuit Low Voltage (Bank
1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-107, DTC P0131 O2 SENSOR CIRCUIT LOW
VOLTAGE (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trou-
ble Code (DTC).>

P0132

O2 Sensor Circuit High Voltage
(Bank 1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-109, DTC P0132 O2 SENSOR CIRCUIT HIGH
VOLTAGE (BANK 1 SENSOR 1), Diagnostic Procedure with Diagnostic Trou-
ble Code (DTC).>

P0133

O2 Sensor Circuit Slow Response
(Bank 1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-111, DTC P0133 O2 SENSOR CIRCUIT
SLOW RESPONSE (BANK 1 SENSOR 1), Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>

EN(H4SO 2.5)(diag)-75

ENGINE (DIAGNOSTICS)

List of Diagnostic Trouble Code (DTC)

P0134

O2 Sensor Circuit No Activity
Detected (Bank 1 Sensor 1)

<Ref. to EN(H4SO 2.0)(diag)-113, DTC P0134 O2 SENSOR CIRCUIT NO
ACTIVITY DETECTED (BANK 1 SENSOR 1), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0137

O2 Sensor Circuit Low Voltage (Bank
1 Sensor 2)

<Ref. to EN(H4SO 2.0)(diag)-115, DTC P0137 O2 SENSOR CIRCUIT LOW
VOLTAGE (BANK 1 SENSOR 2), Diagnostic Procedure with Diagnostic Trou-
ble Code (DTC).>

P0138

O2 Sensor Circuit High Voltage
(Bank 1 Sensor 2)

<Ref. to EN(H4SO 2.0)(diag)-118, DTC P0138 O2 SENSOR CIRCUIT HIGH
VOLTAGE (BANK 1 SENSOR 2), Diagnostic Procedure with Diagnostic Trou-
ble Code (DTC).>

P0139

O2 Sensor Circuit Slow Response
(Bank 1 Sensor 2)

<Ref. to EN(H4SO 2.0)(diag)-121, DTC P0139 O2 SENSOR CIRCUIT
SLOW RESPONSE (BANK 1 SENSOR 2), Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>

P0171

System Too Lean (Bank 1)

<Ref. to EN(H4SO 2.0)(diag)-123, DTC P0171 SYSTEM TOO LEAN (BANK
1), Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0172

System Too Rich (Bank 1)

<Ref. to EN(H4SO 2.0)(diag)-123, DTC P0172 SYSTEM TOO RICH (BANK
1), Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0222

Throttle/Pedal Position Sensor/
Switch “B” Circuit Low

<Ref. to EN(H4SO 2.0)(diag)-125, DTC P0222 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “B” CIRCUIT LOW, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0223

Throttle/Pedal Position Sensor/
Switch “B” Circuit High

<Ref. to EN(H4SO 2.0)(diag)-128, DTC P0223 THROTTLE/PEDAL POSI-
TION SENSOR/SWITCH “B” CIRCUIT HIGH, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0301

Cylinder 1 Misfire Detected

<Ref. to EN(H4SO 2.0)(diag)-131, DTC P0301 CYLINDER 1 MISFIRE
DETECTED, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0302

Cylinder 2 Misfire Detected

<Ref. to EN(H4SO 2.0)(diag)-131, DTC P0302 CYLINDER 2 MISFIRE
DETECTED, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0303

Cylinder 3 Misfire Detected

<Ref. to EN(H4SO 2.0)(diag)-131, DTC P0303 CYLINDER 3 MISFIRE
DETECTED, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0304

Cylinder 4 Misfire Detected

<Ref. to EN(H4SO 2.0)(diag)-132, DTC P0304 CYLINDER 4 MISFIRE
DETECTED, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0327

Knock Sensor 1 Circuit Low (Bank 1
or Single Sensor)

<Ref. to EN(H4SO 2.0)(diag)-139, DTC P0327 KNOCK SENSOR 1 CIR-
CUIT LOW (BANK 1 OR SINGLE SENSOR), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0328

Knock Sensor 1 Circuit High (Bank 1
or Single Sensor)

<Ref. to EN(H4SO 2.0)(diag)-141, DTC P0328 KNOCK SENSOR 1 CIR-
CUIT HIGH (BANK 1 OR SINGLE SENSOR), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0335

Crankshaft Position Sensor “A” Cir-
cuit

<Ref. to EN(H4SO 2.0)(diag)-143, DTC P0335 CRANKSHAFT POSITION
SENSOR “A” CIRCUIT, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P0340

Camshaft Position Sensor “A” Circuit
(Bank 1 or Single Sensor)

<Ref. to EN(H4SO 2.0)(diag)-145, DTC P0340 CAMSHAFT POSITION
SENSOR “A” CIRCUIT (BANK 1 OR SINGLE SENSOR), Diagnostic Proce-
dure with Diagnostic Trouble Code (DTC).>

P0420

Catalyst System Efficiency Below
Threshold (Bank 1)

<Ref. to EN(H4SO 2.0)(diag)-150, DTC P0420 CATALYST SYSTEM EFFI-
CIENCY BELOW THRESHOLD (BANK1), Diagnostic Procedure with Diag-
nostic Trouble Code (DTC).>

P0458

Evaporative Emission System Purge
Control Valve Circuit Low

<Ref. to EN(H4SO 2.0)(diag)-152, DTC P0458 EVAPORATIVE EMISSION
SYSTEM PURGE CONTROL VALVE CIRCUIT LOW, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P0459

Evaporative Emission System Purge
Control Valve Circuit High

<Ref. to EN(H4SO 2.0)(diag)-154, DTC P0459 EVAPORATIVE EMISSION
SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P0462

Fuel Level Sensor “A” Circuit Low
Input

<Ref. to EN(H4SO 2.0)(diag)-156, DTC P0462 FUEL LEVEL SENSOR “A”
CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0463

Fuel Level Sensor “A” Circuit High
Input

<Ref. to EN(H4SO 2.0)(diag)-156, DTC P0463 FUEL LEVEL SENSOR “A”
CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

DTC

Item

Reference

EN(H4SO 2.5)(diag)-76

ENGINE (DIAGNOSTICS)

List of Diagnostic Trouble Code (DTC)

P0500

Vehicle Speed Sensor “A”

<Ref. to EN(H4SO 2.0)(diag)-156, DTC P0500 VEHICLE SPEED SENSOR
“A”, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0512

Starter Request Circuit

<Ref. to EN(H4SO 2.0)(diag)-157, DTC P0512 STARTER REQUEST CIR-
CUIT, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0513

Incorrect Immobilizer Key

<Ref. to IM(diag)-17, DTC P0513 INCORRECT IMMOBILIZER KEY, Diag-
nostic Procedure with Diagnostic Trouble Code (DTC).>

P0519

Idle Air Control System Performance

<Ref. to EN(H4SO 2.0)(diag)-159, DTC P0519 IDLE AIR CONTROL SYS-
TEM PERFORMANCE, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P0600

Serial Communication Link

<Ref. to EN(H4SO 2.0)(diag)-159, DTC P0600 SERIAL COMMUNICATION
LINK, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0604

Internal Control Module Random
Access Memory (RAM) Error

<Ref. to EN(H4SO 2.0)(diag)-160, DTC P0604 INTERNAL CONTROL MOD-
ULE RANDOM ACCESS MEMORY (RAM) ERROR, Diagnostic Procedure
with Diagnostic Trouble Code (DTC).>

P0605

Internal Control Module Read Only
Memory (ROM) Error

<Ref. to EN(H4SO 2.0)(diag)-161, DTC P0605 INTERNAL CONTROL MOD-
ULE READ ONLY MEMORY (ROM) ERROR, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0607

Control Module Performance

<Ref. to EN(H4SO 2.0)(diag)-162, DTC P0607 CONTROL MODULE PER-
FORMANCE, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0638

Throttle Actuator Control Range/Per-
formance (Bank 1)

<Ref. to EN(H4SO 2.0)(diag)-163, DTC P0638 THROTTLE ACTUATOR
CONTROL RANGE/PERFORMANCE (BANK 1), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P0691

Fan 1 Control Circuit Low

<Ref. to EN(H4SO 2.0)(diag)-164, DTC P0691 FAN 1 CONTROL CIRCUIT
LOW, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0692

Fan 1 Control Circuit High

<Ref. to EN(H4SO 2.0)(diag)-164, DTC P0692 FAN 1 CONTROL CIRCUIT
HIGH, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P0700

Transmission Control System (MIL
Request)

<Ref. to EN(H4SO 2.0)(diag)-164, DTC P0700 TRANSMISSION CONTROL
SYSTEM (MIL REQUEST), Diagnostic Procedure with Diagnostic Trouble
Code (DTC).>

P0851

Park/Neutral Position Switch Input
Circuit Low

<Ref. to EN(H4SO 2.0)(diag)-165, DTC P0851 PARK/NEUTRAL SWITCH
INPUT CIRCUIT LOW, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P0852

Park/Neutral Position Switch Input
Circuit High

<Ref. to EN(H4SO 2.0)(diag)-170, DTC P0852 PARK/NEUTRAL SWITCH
INPUT CIRCUIT HIGH, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P1134

A/F Sensor Micro-Computer Problem <Ref. to EN(H4SO 2.0)(diag)-175, DTC P1134 A/F SENSOR MICRO-COM-

PUTER PROBLEM, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P1137

O2 Sensor Circuit (Bank1 Sensor1)

<Ref. to EN(H4SO 2.0)(diag)-177, DTC P1137 O2 SENSOR CIRCUIT
(BANK1 SENSOR1), Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P1160

Return Spring Failure

<Ref. to EN(H4SO 2.0)(diag)-180, DTC P1160 RETURN SPRING FAILURE,
Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P1518

Starter Switch Circuit Low Input

<Ref. to EN(H4SO 2.0)(diag)-184, DTC P1518 STARTER SWITCH CIRCUIT
LOW INPUT, Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

P1521

Brake Switch Circuit Range/Perfor-
mance Problem (High Input)

<Ref. to EN(H4SO 2.0)(diag)-187, DTC P1521 BRAKE CIRCUIT RANGE/
PERFORMANCE PROBLEM(HIGH INPUT), Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P1560

Back-up Voltage Circuit Malfunction

<Ref. to EN(H4SO 2.0)(diag)-189, DTC P1560 BACK-UP VOLTAGE CIR-
CUIT MALFUNCTION, Diagnostic Procedure with Diagnostic Trouble Code
(DTC).>

P1570

Antenna

<Ref. to IM(diag)-18, DTC P1570 ANTENNA, Diagnostic Procedure with
Diagnostic Trouble Code (DTC).>

P1571

Reference Code Incompatibility

<Ref. to IM(diag)-20, DTC P1571 REFERENCE CODE INCOMPATIBILITY,
Diagnostic Procedure with Diagnostic Trouble Code (DTC).>

DTC

Item

Reference
