Subaru Legacy (2005 year). Manual - part 186
EN(H4SO 2.5)(diag)-29
ENGINE (DIAGNOSTICS)
Subaru Select Monitor
6. READ FREEZE FRAME DATA FOR ENGINE (OBD MODE)
1) On the «Main Menu» display screen, select the {Each System Check} and press the [YES] key.
2) On the «System Selection Menu» display screen, select the {Engine} and press the [YES] key.
3) Press the [YES] key after the information of engine type has been displayed.
4) On the «Engine Diagnosis» display screen, select the {OBD System} and press the [YES] key.
5) On the «OBD Menu» display screen, select the {Freeze Frame Data} and press the [YES] key.
• A list of the support data is shown in the following table.
NOTE:
For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.
Description
Display
Unit of measure
DTC for freeze frame data
Freeze frame data
DTC
Air fuel ratio control system for bank 1
Fuel system for Bank1
ON or OFF
Engine load data
Engine Load
%
Engine coolant temperature signal
Coolant Temp.
°C or °F
Short term fuel trim by front oxygen (A/F) sensor
Short term fuel trim B1
%
Long term fuel trim by front oxygen (A/F) sensor
Long term fuel trim B1
%
Intake manifold absolute pressure signal
Mani. Absolute Pressure
mmHg, kPa, inHg or psig
Engine speed signal
Engine Speed
rpm
Vehicle speed signal
Vehicle Speed
km/h or MPH
Ignition timing signal
Ignition Timing
°
Amount of intake air
Mass Air Flow
g/s or lb/m
Intake air temperature signal
Intake Air Temp
°C
Throttle position signal
Throttle Opening Angle
%
