CC(diag)-9
CRUISE CONTROL SYSTEM (DIAGNOSTICS)
Subaru Select Monitor
9) If the cruise speed is canceled by itself (without
doing any cancel operations), DTC will display on
the screen when selecting the {Check Cancel
Code} and pressing the [YES] key on the engine
malfunction diagnosis display screen.
CAUTION:
• When performing diagnostics, observe the
legal speed of the road.
• DTC will also displayed when cruise control
cancel is effected by driver. Do not confuse.
• Put a co-worker in the vehicle to assist the di-
agnosis during driving.
NOTE:
DTC will be cleared by turning ignition switch or
cruise control main switch to OFF.
3. REAL-TIME DIAGNOSIS
1) Connect the Subaru Select Monitor.
2) Turn the ignition switch and cruise control main
switch to ON.
3) Turn the Subaru Select Monitor power switch to
ON.
4) On the « Main Menu» display screen, select the
{Each System Check} and press the [YES] key.
5) On the «System Selection Menu» display
screen, select the {Engine} and press the [YES]
key.
6) Press the [YES] key after the information of en-
gine type is displayed.
7) On the «Cruise Control Diagnosis» display
screen, select the {Current Data Display/Save},
and then press the [YES] key.
8) Make sure that normal indication is displayed
when operated as follows:
• Depress/release the brake pedal. (Stop light
switch and brake switch turn ON.)
• Turn the main switch to ON.
• Turn the “CANCEL” switch to ON.
• Turn ON the “SET/COAST” switch.
• Turn ON the “RESUME/ACCEL” switch.
• Depress or release the clutch pedal.
• Place the shift lever in any position except neu-
tral.
NOTE:
• For details concerning operation procedure, re-
fer to the SUBARU SELECT MONITOR OPERA-
TION MANUAL.
• For DTC, refer to “List of Diagnostic Trouble
Code (DTC)”. <Ref. to CC(diag)-12, List of Diag-
nostic Trouble Code (DTC).>
