SPC-45

SPECIFICATIONS

LEGACY

★1

: For option code, refer to ID section. <Ref. to ID-5, MODEL NUMBER PLATE, IDENTIFICATION, Identification.>

Option code

★1

KA

Model

2.5 L SOHC

3.0 L DOHC

AWD

OUTBACK

2.5 i

OUTBACK 3.0 R

4AT

5AT

Curb weight
(C.W.)

Front

kg (lb)

810 (1,785)

885 (1,951)

900 (1,984)

Rear

kg (lb)

670 (1,477)

660 (1,455)

685 (1,510)

Total

kg (lb) 1,480 (3,263) 1,545 (3,407) 1,585 (3,494)

Unladen
Mass (U.M.)

Front

kg (lb) 1,040 (2,293) 1,040 (2,293) 1,040 (2,293)

Rear

kg (lb) 1,060 (2,336) 1,060 (2,336) 1,060 (2,336)

Gross vehi-
cle Mass
(G.V.M.)

Total

kg (lb) 1,970 (4,343) 2,060 (4,542) 2,060 (4,542)

Option

Vehicle Dynamics
Control

—

—

❍

Cruise control

❍

❍

❍

McIntosh audio

—

—

—

Leather interior

❍

—

❍

Winter pack

—

—

—

15-inch tire

—

—

—

17-inch tire

—

—

—

A/C

❍

❍

❍

Side airbag

❍

❍

❍

Curtain airbag

❍

—

❍

Sunroof

❍

—

❍

Navigation system

—

—

—

Self levelizer

❍

❍

❍

Grade up

❍

—

—

SPC-46

SPECIFICATIONS

LEGACY

PRECAUTION

PC

Page

1.

Precaution ...................................................................................................2

PC-2

PRECAUTION

Precaution

1. Precaution

A: CAUTION

The following precautions must be understood and
strictly adhered to avoid minor or serious injury to
the person doing the work or people in the area,
and to make an effort for environmental protection.

1. ABS

Handle the ABS as a total system. Do not disas-
semble or attempt to repair parts which are not in-
structed in this manual. Follow the instructions in
this manual during performing the maintenance of
ABSCM&H/U. To disassemble parts without in-
structions could prevent the ABS system from op-
erating when needed or cause it to operate
incorrectly and result in injury.

2. VEHICLE DYNAMICS CONTROL (VDC)

Handle the VDC as a total system. Do not disas-
semble or attempt to repair individual parts. Doing
so could prevent the ABS system from operating
when needed or cause it to operate incorrectly and
result in injury.

3. BRAKE FLUID

If brake fluid gets in your eyes or on your skin, do
the following:
• Wash out your eyes and receive medical treat-
ment from an eye doctor.
• Wash your skin with soap and then rinse thor-
oughly with water.

4. RADIATOR FAN

The radiator fan may rotate without warning, even
when the engine is not ON. Do not place your hand,
cloth, tools or other items near the fan at any time.

5. ROAD TEST

Always conduct road tests in accordance with traf-
fic rules and regulations to avoid bodily injury and
interrupting traffic.

6. AIRBAG

To prevent bodily injury from unexpected deploy-
ment of airbags and unnecessary maintenance, fol-
low the instructions in this manual when performing
maintenance on the airbag components or nearby,
around front of the vehicle (radiator panel, front
wheel apron, front side frame, front bumper, front
hood panel, front fender panel), around side of the
vehicle (front door panel, rear door panel, center
pillar, rear fender panel, side sill, rear wheel apron),
and the airbag wiring harnesses or nearby.
To prevent unexpected deployment, turn the igni-
tion switch to OFF and disconnect the ground cable
from battery, then wait at least 20 seconds to dis-
charge electricity before starting work.

7. AIRBAG MODULE AND SEAT BELT
PRETENSIONER DISPOSAL

To prevent bodily injury from unexpected airbag
deployment, do not dispose airbag modules in the
same way as other refuse. Follow the special in-
structions for disposal in this manual. Follow all
government regulations concerning disposal of
refuse.

8. AIRBAG MODULE

Adhere to the following when handling and storing
the airbag module to prevent bodily injury from un-
expected deployment:
• Do not hold the harnesses or connectors to carry
the module.
• Do not face the airbag in the direction that it
opens towards yourself or other people.
• Do not face the airbag in the direction that it
opens towards floor or walls.

9. AIRBAG SPECIAL TOOL

To prevent unexpected deployment, only use spe-
cial tools.

10.WINDOW

Always wear safety glasses when working around
any glass to prevent glass fragments from damag-
ing your eyes.

11.WINDOW ADHESIVE

Always use the recommended or equivalent adhe-
sive when attaching glass to prevent it from coming
off and being removed, resulting in accidents and
injury.
