SsangYong Rexton. Manual - part 569
MANUAL TRANSMISSION 5B-33
SSANGYONG Y200
YAD5B820
YAD5B830
YAD5B840
20. Place the detent spring and offset lever in the
extension housing and push the extension against
the case and shift cover.
21. Completely compress the detent spring.
22. To install the extension housing to the case, apply
sealer to the top two bolts and tighten them and
tighten the 6 bolts.
23. Apply sealer to the back-up lamp switch and drain
plug and tighten them.
24. Using a hammer, install the offset lever-to-shift
roll pin.
25. Turn the transmission case reversely and place a
dial indicator on the extension housing. Move the
input and main shift up and down and measure
end play. Select a shim which is the same
thickness as the measurement ( 0.001 inch). After
shim installation, the end play should be “0”.
26. Remove the input bearing retainer and do the
following :
•
Install the adjusting shim behind the input
bearing outer race in the retainer and if 2 shims
are used, install the thinner one in first.
•
Install the retainer to the case and tighten the
bolts.
•
If end play is not 0change the shim again.
•
Apply RTV sealant to the sealing surface of the
retainer.
•
Apply sealer to the 4 retainer bolts and tighten
them.
