SsangYong Rexton. Manual - part 283
ELECTRICAL WIRING DIAGRAMS 5-165
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (E) - Engine
Engine Room Fuse Box (J) - Engine
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (RH)
Main - Floor (RH)
Main - Floor (RH)
Floor - Driver Door
Floor - Co-Driver Door
Floor - RR Left Door
Floor - RR Right Door
Floor - Tail Gate
W/H Main
W/H Main
W/H Floor
C105 (22Pin, White)
C107 (14Pin, White)
C205 (11Pin, White)
C206 (20Pin, Black)
C214 (12Pin, Black)
C216 (18Pin, White)
C218 (22Pin, Yellow)
C351 (20Pin, White)
C361 (13Pin, White)
C371 (21Pin, White)
C381 (21Pin, White)
C392 (6Pin, White)
S207 (14Pin, Black)
G203
G304
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Under Left “B” Filler
Under Right “B” Filler
Inside the Left Side Cover the Tail Gate
Behind the Right FATC
Under the Seat Heating SW
Behind the Quarter Grass #1
Behinel Conn Holder
Behinel Conn Holder
Tail Lamp
W/H Air Bag
Remark
Connector Position
