ELECTRICAL WIRING DIAGRAMS 5-53
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (F) - Engine
Engine - Engine Control
Engine - Engine Control
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Main - Diagnosis Connector
Main - Floor (RH)
Engine - Main (RH)
Floor - T/M
Floor - T/M
W/H Main
W/H Main
W/H Main
W/H Main
W/H Floor
C106 (18Pin, White)
C113 (12Pin, Black)
C113 (16Pin, Black)
C204 (12Pin, Black)
C207 (15Pin, Blue)
C208 (20Pin, Black)
C211 (14Pin, White)
C218 (22Pin, Yellow)
C219 (13Pin, Green)
C901 (16Pin, White)
C901 (2Pin, White)
S202 (14Pin, Black)
S208 (14Pin, Black)
G201
G203
G301
Connecting Wiring
Harness
Engine Room Fuse Box
Right Engine Room Dash PNL
Right Engine Room Dash PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Upper the Diagnosis
Inside Co-Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Left the T/C (Under the Floor)
Left the T/C (Under the Floor)
Upper the I/P Realy Box
Behind the Right the FATC
Inside Driver Side Cowl PNL
Under the Seat Heating SW
Under Driver Seatz
DSL
DSL (EU)
A/T
A/T
M/T
W/H Air Bag
ECU GND
Remark
Connector Position
