HOW TO USE ELECTRICAL WIRING DIAGRAM  1-5

SSANGYONG  REXTON XDi(RHD)

5. HOW TO CHECK TERMINAL NUMBER OF CONNECTOR

- Terminal number is given based on Female Terminal Connector

ex) Terminal Number 4 of C901 connection

Locking

Terminal Number 4

of total 6 pins

Male Connector

(W/H Fuel Tank)

4

C901

Female Connector

(W/H Floor)

C901

W/H Floor

1

3

2

4

6

5

SSANGYONG   REXTON XDi(RHD)

1-6  HOW TO USE ELECTRICAL WIRING DIAGRAM

1

1

2

9

9

9

3

3

2

6. PART LOCATION ACCORDING TO PART NUMBER

Ex.)  C  1  0  2

• C : Symbol character for connector

Part Number

Engine compartment

Instrument panel

Passenger compartment, Tailgate

Underbody

…1……

…2……

…3……

…9……

Location

• 1 : Part location number

Symbol Character

Connector(Connecting part that connects two wiring harness)

Diode

Ground

Splice pack(Joint connector that connects various wiring harness)

C

D

G

S

Description

• Part number according to locating section

• In the locating section, the assignment for part number starts from

left bottom and proceeds clockwise.

• In the fuse and relay box or the instrument panel, the part number is

assigned from left top to light bottom.

• 02 : Part number

HOW TO USE ELECTRICAL WIRING DIAGRAM  1-7

SSANGYONG  REXTON XDi(RHD)

7. ELECTRIC SYMBOLS

Items

Symbols

Items

Symbols

Resistance

Rheostat

Coil, Inductance

Condenser, Capacitor

Ground, Earth

Diode

Zener Diode

Photo Diode

Light Emitting Diode

Battery

Disconnected Wire

Fuse

Motor

Speaker

Lamp

Single Bulb

Double Bulb

Transistor : PNP type

Transistor : NPN type

~Meter, ~Gauge

Voltmeter

Amperemeter

Switch

Thermistor

Junction Point

Fusible Link

Connector

Horn

M

V

SSANGYONG   REXTON XDi(RHD)

1-8  HOW TO USE ELECTRICAL WIRING DIAGRAM

Abbreviations

Air Bag

Air Conditioner

Air Duct

Auto Transmission

Automatic Brake Differential

Anti-lock Braking System

Alternating Current

Accessory

Accelerator

Auto Cruise System

Actuator

Alternator

Ampere

Antenna

Air Quality System

Anti Slip Regulator

Assembly

Automatic Temperature Controller

After Top Dead Center

Auxiliary

Automatic Voltage Regulator

Battery

Back Up

Back Door

Back Window

Bottom Dead Center

Body in White

Before Top Dead Center

Central Comport Control System

Compressor

Condenser Fan

Connector

Cigar Lighter

Cruise

Crash Pad

Canister

Contact Breaker

Cable

A

B

C

A/BAG

A/CON(A/C)

A/DUCT

A/T

ABD

ABS

AC

ACC

ACCEL

ACS

ACTR(ACT)

ALT

AMP

ANT

AQS

ASR

ASSY

ATC

ATDC

AUX

AVR

BATT

B/UP

B/DR

B/WDW

BDC

BIW

BTDC

CCCS

COMP

C/FAN

CONN

C/LIGHTER

CRU

C/PAD

CANI

CB

CBL

8. ABBREVIATIONS

Classification

Full words
