DI09-18
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
ELECTRIC DEVICES AND SENSORS
DI ENG SM - 2004.4
1. Turn the ignition switch to “OFF” position and disconnect
the negative battery cable.
2. Set aside the harnesses on the cylinder head.
3. Disconnect the glow plug connectors and loosen the glow
plugs.
Installation Notice
4. Remove the glow plugs from the cylinder head with a
special tool. Plug the openings of the glow plugs with
sealing caps.
Tightening torque
Y220_09015
Y220_09016
Y220_09017
Removal and Installation
