SsangYong Rexton. Manual - part 94

DI09-3

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRIC DEVICES AND SENSORS

DI ENG SM - 2004.4

ELECTRIC DEVICES AND SENSORS

Y220_09001

SENSORS IN ENGINE COMPARTMENT

Fuel pressure sensor

Camshaft position

sensor

Coolant temperature

sensor

Fuel temperature

sensor

Knock sensor

Crankshaft position

sensor

Booster pressure

sensor

Oil pressure switch

DI09-4

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

 ELECTRIC DEVICES AND SENSORS

DI ENG SM - 2004.4

ELECTRIC DEVICES IN ENGINE COMPARTMENT

Y220_09002

Alternator

Glow plug

Air conditioner compressor

Starter

Capacity

PTC equipped vehicle

: 12V - 140A

FFH equipped vehicle

: 12V - 115A

DI09-5

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRIC DEVICES AND SENSORS

DI ENG SM - 2004.4

Type

Output power

No load test @ 12 volts

Drive pinion speed at no load

Drive pinion speed at load

Brush length

Armature diameter

Armature run-out

Segment groove depth

Type

Output voltage / current

Regulator type

Regulating voltage

Brush

Type

Capacity

Rupture capatity

Type

Rated voltage

Circuit connection

Preheating time

SPECIFICATIONS

Starter

Alternator

Battery

Glow plug

WP220

2.2

160

4500

1700/430

18

55

0.1

21.7

CS128D

PTC equipped vehicle: 12V-140A

FFH equipped vehicle: 12V-115A

←

14.6

12.5

2

7

M F

12V - 90AH

160

Seized type

11.5

Parallel

Max. 60 ~ 90

Description

Specification

Length

Quantity

Wear limit

-

Kw

A

rpm

rpm/A

mm

mm

mm

mm

-

V/A

-

V

mm

-

mm

-

AH

RC

-

-

-

sec

Unit
