SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 239
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
SWITCH
STAVIC - 2004.09
12
2E
Resuming the ESP function by using ESP
OFF
switch
The ESP function will be resumed if pressing the ESP
OFF
switch on the center switch panel again shortly when the ESP
function is cancelled (when the ESP warning light comes on). At this moment, the ESP warning light in the indicator
display goes off and the ESP function is resumed.
Connector Terminals and Circuit
Rated capacity: DC 12 V, 1 A
[Notice]
- The ESP system deactivates when stopping the engine. It will be resumed when the engine is started again.
- If the vehicle is controlled by ESP during driving, the ESP
OFF
switch will not work.
- If the ESP warning light comes on, the ESP related system is defective. At this moment, the ABS works in a basic way.
- If the ESP warning light and the ABS warning light come on simultaneously, both ESP and ABS system are not working.
- If the ESP warning light blinks and the alarm sounds, it means that the vehicle stability is controlled by the ESP function
when the vehicle stability is extremely unstable.
- If the ESP function operates while driving, the indicator lamp blinks and the alarm sounds with the interval of 0.1
second.
