SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 236

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

RAIN SENSING WIPER

STAVIC - 2004.09

11

2D

5. The wiper responses are too fast or slow.

Check whether the variable resistance knob on the wiper switch is set in “FAST” or “SLOW”.

Notify that the customer can select the sensitivity by selecting the variable resistance value. And, select a proper
stage.

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

RAIN SENSING WIPER

STAVIC - 2004.09

12

2D

8. REMOVAL AND INSTALLATION OF RAIN SENSOR

1. Pry off the rain sensor cover by inserting a small flat-blade screwdriver into service holes at both sides.

 [Notice]

Otherwise, the cover or rain sensor components could be damaged.

2. Pull of the rain sensor unit from the windshield glass and disconnect the rain sensor connector.

Service hole

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

SWITCH

STAVIC - 2004.09

2

2E

INTERIOR SWITCHES

4WD switch and rear

washer/wiper switch

Outside rearview mirror control

and folding switch

Window switch

Audio remote control switch

Audio power button

Mode button

SEEK button – Up

SEEK button - Down

Mute button

Volume button - Up

Volume button - Down

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

SWITCH

STAVIC - 2004.09

3

2E

Multifunction switch

Room lamp and sun roof switch

(multi-meter integrated type)

Sun roof switch

Front room lamp

operation

Multi-meter

Front room lamp

operation

Driver’s seat warmer switch

Hazard warning flasher switch

Window switch

Front fog lamp switch

Rear fog lamp switch

Defogger switch

ESP

OFF

 switch

Passenger’s seat

warmer switch
