10-6

2) Accelerating with the Cruise Control System

(1) While the cruise control system is running

Push up the ACCEL switch of the cruise control lever and hold it until the desired speed is reached

without an accelerator pedal intervention.

When the desired speed is reached, release the lever.

1.

2.

(2) While the cruise control system is not running

Accelerate using the accelerator pedal over 36 km/h.

Push up the ACCEL switch of the cruise control lever and hold it.

And then release the accelerator pedal slowly.

When the desired speed is reached, release the lever.

1.

2.

3.

4.

(3) Tap-up while the cruise control system is running

Push up the ACCEL switch of the cruise control lever less than 0.5 second per one switching while

the cruise control system is running. This is a tap-up switching.

When you operate a tap-up switching, the vehicle is accelerated by 1.3 km/h over the previous set

speed.

If you want to accelerate to 13 km/h, operate the tap-up switching ten times without accelerating

with the cruise control system.

1.

2.

3.

10-7

8510-23

3) Decelerating with the Cruise Control System

(1) While the cruise control system is running

Push down the DECEL switch of the cruise control lever and hold it until the desired speed is

reached without a brake pedal intervention. But the cruise control system cannot maintain the

cruise function at less than 34 km/h.

When the desired speed is reached, release the lever.

1.

2.

(2) When the cruise control system is not running

Push down the DECEL switch of the cruise control lever and hold it.

And then release the accelerator pedal slowly.

When the desired speed is reached, release the lever. But the cruise control system cannot

maintain the cruise function at less than 34 km/h.

1.

2.

3.

(3) Tap-down while the cruise control system is running

Push down the DECEL switch of the cruise control lever less than 0.5 second per one switching

while the cruise control system is running. This is a tap-down switching.

When you operate a tap-down switching, the vehicle is decelerated by 1.0 km/h below the previous

set speed.

If you want to decelerate to 10 km/h, operate the tap-down switching ten times without the brake

pedal intervention.

1.

2.

3.

10-8

4) Recovery of Set Speed (RESUME)

Even if the cruise control is cancelled, the previous set cruise speed can be recovered by pushing

(Type A) or pulling (Type B) toward the cruise control lever when the current vehicle speed is over 36

km/h without an acceleration intervention. But if you turn off the ignition switch, the memorized set

speed is cleared and you cannot recover the previous set speed.

The resume position should only be used if the driver is fully aware of this speed and wishes to

resume this particular speed.

10-9

8510-23

5) Normal Cancellation of the Cruise Control

The cruise control system will be canceled when one or more items of the following conditions are

applied;

Keep the main cruise control switch in the neutral position when not using the cruise control.

When the brake pedal is depressed.

When the cruising speed is downed less than 38 km/h.

When the OFF switch is operated by pulling the cruise control lever (Type A) or by pushing the ON-

OFF switch of the cruise control lever (Type B).

When ESP is activated.

When applying the parking brake when driving.

When using the clutch in order to shift (M/T only).

And the cruise control system can be operated again in driving state.

1.

2.

3.

4.

5.

6.
