03-4
2. INPUT SIGNALS
NO
Input signal
Logic
1
IGN1
ON = Battery voltage (IGN ON or START)
2
IGN2
ON = Battery voltage (IGN ON)
3
Alternator
ON = Battery voltage (engine running)
4
Key reminder switch
IN = Battery voltage (key inserted)
5
Driver door LOCK detecting switch
LOCK = GND, UNLOCK = OPEN
6
Driver door UNLOCK detecting switch
LOCK = OPEN, UNLOCK = GND
7
Passenger door LOCK detecting switch
LOCK = GND, UNLOCK = OPEN
8
Passenger door UNLOCK detecting
switch
LOCK = OPEN, UNLOCK = GND
9
Rear door LOCK detecting switch
LOCK = OPEN, UNLOCK = GND
10
Puddle lamp
ON = (-) OUTPUT
11
Driver door open switch
OPEN = GND, CLOSE = OPEN
12
Passenger door open switch
OPEN = GND, CLOSE = OPEN
13
Rear LH door open switch
OPEN = GND, CLOSE = OPEN
14
Rear RH door open switch
OPEN = GND, CLOSE = OPEN
15
Tailgate switch
OPEN = GND, CLOSE = OPEN
16
Hood switch
OPEN = GND, CLOSE = OPEN
17
Sunroof switch
OPEN = GND, CLOSE = OPEN
18
headlamp switch
ON = GND, OFF = OPEN
19
Folding/unfolding switch
ON = GND, OFF = OPEN
20
Crash door LOCK/UNLOCK switch
ON = GND, OFF = OPEN
21
Crash sensor (air bag)
ON = 200 ms Low signal, OFF = OPEN
22
Front defogger (heated wire) switch
ON = GND, OFF = OPEN
23
Rear defogger (heated wire) switch
ON = GND, OFF = OPEN
24
Wiper switch 1
ON = GND, OFF = OPEN
25
Wiper switch 2
ON = GND, OFF = OPEN
26
Driver seat belt switch
Unbuckled = GND, Fastened = OPEN
27
Passenger seat belt switch (only EU)
Unbuckled = GND, Fastened = OPEN
28
Rain & AUTO light sensor
LIN communication
