AUTOMATIC TRANSMISSION 5A-127 SSANGYONG MY2002 DTC P1739 Solenoid 7 Circuit Open Look for possible bent, backed out, deformed or • If diagnosing for a possible intermittent short or Test Description The number(s) below refer to the step number(s) on 3. Checks if the S7 circuit in the transmission is mal- functioning. 4. Check cable in the transmission for open / short. If the problem is found in the wiring harness from 7. Check resistance between S7 terminal A and B. Standard value is 22 - 30 Ω . 10. Check connections of other connectors. - Go to Step 12 Go to Step 7 1 Perform a Transmission Control Module (TCM) System setting this DTC as specified in the text. Does the scan tool display P1739? (additional DTCs will set) 3. Connect Solenoid/Thermistor Electrical Tester (STET) to the 10-way transmission connector of 4. Turn the mode knob of STET to 7 and push the red button. Does the bulb of open circuit on the solenoids side of this section. 2. Check the wiring harness from 10-way transmission connector to contact point attached onto the Is a repair necessary? Step Action Value(s) Yes No 2 3 - Go to Step 2 Go to “TCM Diagnostic System Check” - Go to Step 4 Go to Step 9 5 6 4 - Go to Step 12 Go to Step 5 - Go to Step 12 Go to Step 6 7 8 - Go to Step 12 - - Go to Step 3 Go to “Diagnostic Aids” 22 - 30 Ω Go to “Diagnostic Aids” Go to Step 8 |
