1B3 -- 2 OM600 ENGINE MECHANICAL
DAEWOO MY_2000
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Engine Assembly
Application
NSm
Lb--Ft
Lb--In
Skid Plate Bolt
28 -- 47
21 --35
--
Drain Plug Bolt
30
22
--
Coolong Fan Shroud Bolt
3 -- 7
--
27 -- 62
Control Linkage Nut
8 -- 18
6 -- 13
--
Clutch Linkage Cylinder Nut
20 -- 34
15 -- 25
--
Exhaust Manifold Bolt
30
22
--
Propeller Shaft Bolt & Nut
(Axle)
70 -- 80
52 -- 59
--
Propeller Shaft Bolt & Nut
(T/C)
81 -- 89
60 -- 66
--
Engine Mounting Nut
50 -- 75
37 -- 55
--
Crankshaft Assembly
Application
NSm
Lb--Ft
Lb--In
Cooling Fan Belt Pulley Bolt
10
--
89
Socket Bolt
23
17
--
Tighten The Bolt
200 / 90_
148 / 90_
--
End Cover Bolt
10
--
89
Crankshaft Bearing Cap Bolt
55 / 90_
41 / 90_
--
Ball Bearing
45 / 90_
33 / 90_
--
Camshaft Sprocket Bolt
25 / 90_
18 / 90_
--
Oil Pump Sprocket Bolt
25
18
--
Piston
Application
NSm
Lb--Ft
Lb--In
Connecting Rod Bolt
35 / 90_
26 / 90_
--
Flywheel
Application
NSm
Lb--Ft
Lb--In
12--Sided Stretch Bolt
45 / 90_
33 / 90_
--
