02-16 5. AIR BAG WARNING LAMP OPERATIONAL CONDITIONS The air bag warning lamp on the instrument panel has a few operational conditions. The following are the conditions: When Turning the Ignition Switch to ON Position Initially ▶ The air bag unit performs a turn-on test when the ignition is turned on initially. The air bag unit flashes the air bag warning lamp 6 times at 1 Hz interval. After that, the air bag warning lamp will go off if no malfunction have been detected. When the Air Bag Unit Detects Any Malfunctions in Unit ▶ When the Air Bag Unit Detects Any Intermittent Failure ▶ When it is recorded as a system failure in the air bag unit, the air bag warning lamp on the instrument panel comes on for about 6 seconds and goes off for 1 second. Then the waning lamp stays on. When, due to an error from outside the system, the intermittent failure signal is received 5 times or less, the air bag warning lamp comes on for about 6 seconds and then, goes off. IGN KEY Air bag warning lamp IGN KEY Air bag warning lamp IGN KEY Air bag warning lamp ON OFF OFF ON OFF ON OFF ON OFF ON OFF 6sec. 6sec. ON |
