09-28

Front Brake Assembly

Front Wheel Speed Sensor (4WD)

HECU

2. SYSTEM LAYOUT

Master Cylinder and Booster

Brake Pedal

09-29

4850-01

Rear Wheel Speed Sensor (4WD)

Rear Brake Assembly

ABS/EBD Indicators

Parking Brake Lever

Parking Brake

09-30

3. PARKING BRAKE

Front Disc Brake

▶

Brake caliper

Brake hub

Brake disc

Air breather

Drive shaft

Lower arm ball joint

Brake pad

Upper arm connection

2-way piston

Brake caliper

Tie rod end connection

Knuckle

Backing plate

Lower arm connection

09-31

4850-01

Rear Disc Brake

▶

Brake caliper

Rear shock absorber

Brake disc

Air breather

Brake hub

Brake pad

Brake hose

one-way piston

Brake caliper

Air breather

Backing plate
