7D-2 FATC-HAVC
Application
Size (WxHxT)
Capacity
Type
Description
650x339.2x22.0
11,000 Kcal/h
Parallel Flow
Condenser
Application
Material
Capacity
Desiccant
Description
Aluminum
250cc
XH-9 or equivalent 35g
Receiver Drier
Application
Motor Type
Motor Size
Description
Magnetic
φ
70 x 145
Blower Unit
Application
Replacement
Description
Every 10,000 km (replace earlier if air pollution is heavy)
Air Filter
Application
Model
Type
Displacement (cc/rev.)
Pulley
Oil
Description
FK-II(DKV 14C)
Vane rotary
140.5
φ
143.0
ZXL 200 PG (PAG Oil)
Compressor
Application
Heater Core Type
Heating Capacity
Heater Core Size (LxWxT)
Description
2 - ROW
4,600 Kcal/h (AT 300CMH)
219.5 X 151.8 X 52
Heater Unit
Application
Type
High (OFF)
Low (ON)
Description
Direct
OFF : 27±2Kgf/cm
2
, DIFF : 6±2Kgf/cm
2
OFF : 1.8±2Kgf/cm
2
, ON : 1.9±0.3Kgf/cm
2
Pressure Switch
