M161 ENGINE MECHANICAL 1B2-103 OIL PRESSURE RELIEF VALVE Preceding Work : Removal of oil pan 1 Screw Plug ................................................ 50 Nm Removal & Installation Procedure 1. Remove the screw plug (1). Installation Notice 2. Remove the spring (2), guide pin (3) and the piston (4). 3. Installation should follow the removal procedure in the reverse order. Notice Don’t use the seal for the screw plug. 3 Guide Pin Tightening Torque 50 Nm |
