M162 ENGINE MECHANICAL  1B1-95

ENGINE OIL AND OIL FILTER ELEMENT

4. Remove the drain plug (arrow) and drain the engine oil.

Notice

Leave the oil filler cap open to ease the engine oil discharge.

5. Tighten the engine oil drain plug after cleaning it.

Installation Notice

Tools Required

103 589 02 09 00 Oil Filter Socket Wrench

Replacement Procedure

1. Install the socket wrench”7” (special tool : 103 589 02 09

00) on the oil filter cover (2).

Notice

Make the screw cover removable by tightening the bolt at
the side of the socket wrench (special tool).

2. Install the wrench to the upper bolt in the socket wrench

and remove the oil cover by turning it.

3. Remove the oil filter element.

Notice

Work with a cloth under the vehicle when removing the oil
filter element to not drain the oil.

Replace the seal washer with new one.

6. Replace the O-ring(5) in the oil filter cover with new one.

Notice

Apply the engine oil to the O-ring.

7. Insert new oil filter element into the oil filter housing.

Tightening Torque

25 Nm

8. Temporarily tighten the oil filter cover (2). Install the socket

wrench “7” (special tool : 103 589 02 09 00), and then
completely tighten it.

Installation Notice

2 Oil  Filter  Cover
5 O-ring
6 Oil  Filter  Element
7 Special  Tool (Socket Wrench)

Tightening Torque

25 Nm

1B1-96  M162 ENGINE MECHANICAL

3  Oil  Filler  Cap
4  Dipstick  Gauge

9. Fill up engine oil through the engine oil filler opening (3).

10. Check for oil leaks at normal engine temperature after

starting the engine.

11. Stop the engine and wait 5 minutes.

Check the oil level and fill up as specified if necessary.

M162 ENGINE MECHANICAL  1B1-97

OIL FILTER

Preceding Work : Removal of starter motor

Removal of upper intake manifold

1 Coolant Line
2 O-ring .................................................... Replace
3 Clip
4 Hose

5 Bolt ........................................................... 23 Nm
6 Oil Filter
7 Gasket ................................................... Replace

1B1-98  M162 ENGINE MECHANICAL

Tightening Torque

23 Nm

Notice

Replace the oil filter gasket.

4. Installation should follow the removal procedure in the

reverse order.

5. Check engine oil level.

6. Run the engine at idle and check the engine for leaks.

3. Remove the oil filter bolt and then remove the oil filter.

Installation Notice

Removal & Installation Procedure

1. Drain the coolant from the crank case.

2. Remove the each coolant line and hose.
