GENERAL INFORMATION  0B-5

SSANGYONG  Y158

Lubricating Type

Oil Pump Type

Oil Filter Type

Oil Capacity (L) (Including Oil Filter)

Lubricating System

2.3L DOHC

7.5

3.2L DOHC

8.2

External Gear pump

Full Flow

Cooling Type

Coolant Capacity (L)

Radiator Type

Water Pump Type

Cooling System

2.3L DOHC

10.5

3.2L DOHC

11.3

Forced Circulation

Centrifugal

Application

Battery (MF)

Generator

Starter

Electric System

2.3L DOHC

115 A

1.2 kw

3.2L DOHC

115 A

1.7 kw

12V - 75 AH

0B-6  GENERAL INFORMATION

SSANGYONG  Y158

Application

Overall Length (mm)

Overall Width (mm)

Overall Height (mm)

Wheel Base (mm)

Tread : Front (mm)

Rear (mm)

VEHICLE DIMENSIONS AND WEIGHTS

Vehicle Dimensions

Application

Manual : Curb Weight (kg)

Gross Vehicle Weight (kg)

Automatic  : Curb Weight (kg)

Gross Vehicle Weight (kg)

Passenger Capacity

Vehicle Weights

Application

4656

1864

1735

2630

1510

1520

2.3L DOHC

1835

2520

1850

2520

5

3.2L DOHC

1910

2520

1930

2520

5

GENERAL INFORMATION  0B-7

SSANGYONG  Y158

STANDARD BOLTS SPECIFICATIONS

Bolt*

Torque (N

•

m / Ib-in)

Standard

Limit

4T

7T

9T

4T

7T

9T

M3

×

 0.5

M4

×

 0.7

M5

×

 0.8

M6

×

 1.0

M8

×

 1.25

M10

×

 1.25

M10

×

 1.5

M12

×

 1.25

M12

×

 1.75

M14

×

 1.5

M16

×

 1.5

M18

×

 1.5

M20

×

 1.5

M22

×

 0.5

M24

×

 1.5

M24

×

 2.0

0.5 N•m

 (4.5 lb-in)

1.2 N•m

 (11 lb-in)

2.4 N•m

 (22 lb-in)

4.0 N•m

 (36 lb-in)

8.6 N•m

 (77 lb-in)

18.6 N•m

 (14 lb-in)

18.6 N•m

 (14 lb-in)

34.3 N•m

 (25lb-in)

32.3 N•m

 (24 lb-in)

54.0 N•m

 (40 lb-in)

81.3 N•m

 (60 lb-in)

117.6 N•m

 (87 lb-in)

166.6 N•m

 (123 lb-in)

225.4 N•m

 (167 lb-in)

284.2 N•m

 (210 lb-in)

274.4 N•m

 (203 lb-in)

0.9 N•m

 (8 lb-in)

2.0 N•m

 (18 lb-in)

4.0 N•m

 (36 lb-in)

6.7 N•m

 (60 lb-in)

15.7 N•m

 (12 lb-in)

32.3 N•m

 (24 lb-in)

30.4 N•m

 (22 lb-in)

56.8 N•m

 (42 lb-in)

53.9 N•m

 (40 lb-in)

89.2 N•m

 (66 lb-in)

107.8 N•m

 (80 lb-in)

196.0 N•m

 (145 lb-in)

274.4 N•m

 (203 lb-in)

372.4 N•m

 (276 lb-in)

480.2 N•m

 (355 lb-in)

460.6 N•m

 (341 lb-in)

1.3 N•m

 (12 lb-in)

3.0 N•m

 (27 lb-in)

5.6 N•m

 (50 lb-in)

9.7 N•m

 (87 lb-in)

22.5 N•m

 (17 lb-in)

46.0 N•m

 (34 lb-in)

44.1 N•m

 (33 lb-in)

82.3 N•m

 (61 lb-in)

77.4 N•m

 (57 lb-in)

127.4 N•m

 (94 lb-in)

196.0 N•m

 (145 lb-in)

284.2 N•m

 (210 lb-in)

392.0N•m

 (290 lb-in)

529.2 N•m

 (392 lb-in)

686.0 N•m

 (508 lb-in)

666.4 N•m

 (493 lb-in)

1.2 N•m

 (11 lb-in)

2.6 N•m

 (23 lb-in)

5.2 N•m

 (47 lb-in)

9.0 N•m

 (81 lb-in)

20.6 N•m

 (15.2 lb-in)

42.1 N•m

 (31 lb-in)

41.2 N•m

 (30 lb-in)

75.5 N•m

 (56 lb-in)

71.5 N•m

 (53 lb-in)

117.6 N•m

 (87 lb-in)

186.2 N•m

 (138 lb-in)

264.6 N•m

 (196 lb-in)

362.6 N•m

 (268 lb-in)

490.0 N•m

 (362 lb-in)

637.0 N•m

 (471 lb-in)

617.4 N•m

 (457 lb-in)

17 N•m

 (15 lb-in)

4.0 N•m

 (36 lb-in)

7.6 N•m

 (68 lb-in)

12.7 N•m

 (114 lb-in)

30.4 N•m

 (22 lb-in)

60.8 N•m

 (31 lb-in)

58.8 N•m

 (44 lb-in)

107.8 N•m

 (80 lb-in)

98.0 N•m

 (73 lb-in)

166.6 N•m

 (123 lb-in)

264.6 N•m

 (196 lb-in)

372.4 N•m

 (276 lb-in)

519.4 N•m

 (384  lb-in)

705.6 N•m

 (522 lb-in)

921.2 N•m

 (682 lb-in)

891.8 N•m

 (660 lb-in)

*Diameter

×

pitch in millimeters

YAA0B010

0.7 N•m

 (6.3 lb-in)

1.6 N•m

 (14 lb-in)

3.1 N•m

 (28 lb-in)

5.4 N•m

 (49 lb-in)

12.7 N•m

 (9 lb-in)

25.5 N•m

 (19 lb-in)

24.5 N•m

 (18 lb-in)

45.0 N•m

 (33 lb-in)

43.1 N•m

 (32 lb-in)

71.6 N•m

 (53 lb-in)

107.8 N•m

 (80 lb-in)

156.8 N•m

 (116 lb-in)

215.6 N•m

 (160 lb-in)

294.0 N•m

 (218 lb-in)

382.2 N•m

 (283 lb-in)

372.4 N•m

 (276 lb-in)

0B-8  GENERAL INFORMATION

SSANGYONG  Y158

MAINTENANCE AND REPAIR

Air Cleaner Element Replacement

Clean the air cleaner element every.

•••••

Gasoline Engine : 15,000 km (10,000 miles)

Replace the air cleaner element every .

•••••

Gasoline Engine : 60,000 km (36,000 miles)

Replace the air cleaner more often under dusty

conditions

Fuel Filter Replacement

Replace the engine fuel filter every.

•••••

Gasoline Engine : 60,000 km (36,000 miles)

Spark Plug Replacement

Replace spark plugs with same type.

•••••

Type : BOSCH : F8DC4

BERU : 14F-8DU4

Champion : C11YCC

•••••

Gap : 0.8

±

 0.1 mm

Spark Plug Wire Replacement

Clean wires and inspect them for burns, cracks or other
damage. Check the wire boot fit at the Distributor and
at the spark plugs. Replace the wires as needed.

Brake System Service

Check the disc brake pads or the drum brake linings.
Check the pad and the lining thickness carefully.

Tire and Wheel Inspection and Rotation

Check the tires for abnormal wear or damage. To equalize
wear and obtain maximum tire life, rotate the tires. If
irregular or premature wear exists, check the wheel
alignment and check for damaged wheels. While the
tires and wheels are removed, inspect the brakes.

MAINTENANCE AND

LUBRICATION

NORMAL VEHICLE USE

The maintenance instructions contained in the
maintenance schedule are based on the assumption that
the vehicle will be used for the following  reasons:

•••••

To carry passengers and cargo within the limitation
of the tire inflation prassure. Refer to “Tire and
Wheel” in section 2E.

•••••

To be driven on reasonable road surfaces and within
legal operating limits.

EXPLANATION OF SCHEDULED
MAINTENANCE SERVICES

The services listed in the maintenance schedule are
further explained below. When the following maintenance
services are performed, make sure all the parts are
replaced and all the necessary repairs are done before
driving the vehicle. Always use the proper fluid and
lubricants.

Engine Oil and Oil Filter Change

Always use above the API SH grade or recommended
engine oil.

Engine Oil Viscosity

Engine oil viscosity (thickness) has an effect on fuel
economy and cold weather operation. Lower viscosity
engine oils can provide better fuel economy and cold
weather performance; however, higher temperature
weather conditions require higher viscosity engine oils
for satisfactory lubrication. Using oils of any viscosity
other than those viscosities recommended could result
in engine damage.

Cooling System Service

Drain, flush and refill the system with new coolant. Refer
to “Recommended Fluids And Lubricants” in this
section.

Tire Rotation (Left-hand Drive Type)

KAA0B070
