R

Never run the fuel tank empty.

R

If the engine starts to misfire, bring the
vehicle to an immediate standstill
without endangering traffic.

R

If the engine fails to start the first time,
you should not try to start it any more
than three times in succession.

R

Do not try to start for more than four
seconds at a time.

Tires

G

Warning!

If you feel a sudden significant vibration
or ride disturbance, or you suspect that
possible damage to your vehicle has
occurred, you should turn on the hazard
warning flashers, carefully slow down, and
drive with caution to an area which is a safe
distance from the road.
Inspect the tires and the vehicle underbody
for possible damage. If the vehicle or tires
appear unsafe, have the vehicle towed to the
nearest smart center or tire dealer for
repairs.

Treadwear indicators (TWI) are required by
law. These indicators are located in six
places on the tread circumference and
become visible at a tread depth of
approximately

1

/

16

 in (1.6 mm), at which

point the tire is considered worn and
should be replaced.
The treadwear indicator appears as a solid
band across the tread.

G

Warning!

Although the applicable federal motor
vehicle safety laws consider a tire to be
worn when the treadwear indicators (TWI)
become visible at approximately

1

/

16

 in

(1.6 mm), we recommend that you do not allow
your tires to wear down to that level. As
tread depth approaches

1

/

8

 in (3 mm), the

adhesion properties on a wet road are
sharply reduced.
Depending upon the weather and/or road
surface (conditions), the tire traction
varies widely.

Specified tire inflation pressures must be
maintained. This applies particularly if
the tires are subject to high loads (e.g.
high speeds, heavy loads, high ambient
temperatures).

G

Warning!

Do not drive with a flat tire. A flat tire will
affect your ability to steer or brake and may
cause you to lose control of the vehicle.
Continued driving with a flat tire or
driving at high speed with a flat tire will
cause excessive heat build-up and possibly
a fire.

For more information, see “Tires and
wheels” (

Y

 page 118).

Hydroplaning

Depending on the depth of the water layer
on the road, hydroplaning may occur
resulting in a loss of control, even at low
speeds and with new tires. Reduce vehicle
speed, avoid track grooves in the road and
apply brakes cautiously when it is raining.

Tire traction

The safe speed on a wet, snow covered or icy
road is always lower than on a dry road.
You should pay particular attention to the
condition of the road whenever the outside
temperatures are close to the freezing
point.

G

Warning!

If ice has formed on the road, tire traction
will be substantially reduced. Under such
weather conditions, drive, steer and brake
with extreme caution.

Driving instructions

141

>> Operation.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

smart recommends winter tires
(

Y

 page 136) with a minimum tread depth of

approximately

1

/

6

 in (4 mm) on all four

wheels for the winter season to ensure
normal balanced handling characteristics.
On packed snow, they can reduce your
stopping distance compared to summer
tires.
Stopping distance, however, is still
considerably greater than when the road is
not covered with snow or ice. Exercise
appropriate caution.

Avoid spinning of a drive wheel for an

extended period when driving off on
slippery road surfaces. Otherwise, the
drivetrain could be damaged, which is
not covered by the smart Limited
Warranty.

Tire speed rating

Regardless of the tire speed rating, local
speed limits should be obeyed. Use prudent
driving speeds appropriate to prevailing
conditions.

G

Warning!

Even when permitted by law, never operate
a vehicle at speeds greater than the
maximum speed rating of the tires.
Exceeding the maximum speed for which
tires are rated can lead to sudden tire
failure, causing loss of vehicle control and
possibly resulting in an accident and/or
personal injury and possible death, for you
and for others.

An electronic speed limiter prevents your
vehicle from exceeding a speed of 90 mph
(145 km/h).
The factory equipped tires on your vehicle
may have a tire speed rating above the
maximum speed permitted by the
electronic speed limiter.
Make sure your tires have the required tire
speed rating as specified for your vehicle

in the “Technical data section”
(

Y

 page 206), for example when purchasing

new tires.
For information on how to identify the tire
speed rating on a tire’s sidewall, see “Tire
size designation, load and speed rating”
(

Y

 page 130).

If you are uncertain about the correct
reading of the information given on a
tire’s sidewall, any authorized smart
center will be glad to assist you.

i

For information on speed ratings for

winter tires, see “All-season and winter
tires” (

Y

 page 131).

Winter driving instructions

The most important rule for slippery or icy
roads is to drive sensibly and to avoid
abrupt acceleration, braking and steering
maneuvers.
When the vehicle is in danger of skidding,
move gear selector lever to neutral
position N. Try to keep the vehicle under
control by corrective steering action.
For information on driving with snow
chains*, see “Snow chains*” (

Y

 page 137).

G

Warning!

On slippery road surfaces, never downshift
in order to obtain braking action. This
could result in drive wheel slip and
reduced vehicle control. Your vehicle’s ABS
will not prevent this type of loss of control.

Road salts and chemicals can adversely
affect braking efficiency. Increased pedal
force may become necessary to produce the
normal braking effect.
Depressing the brake pedal periodically
when traveling at length on salt-strewn
roads can bring road-salt-impaired
braking efficiency back to normal.
If the vehicle is parked after being driven
on salt-treated roads, the braking

142

Driving instructions

>> Operation.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

efficiency should be tested as soon as
possible after driving is resumed.

G

Warning!

Make sure not to endanger any other road
users when carrying out these braking
maneuvers.

G

Warning!

If the vehicle becomes stuck in snow, make
sure snow is kept clear of the exhaust pipe
and from around the vehicle with the engine
running. Otherwise, deadly carbon
monoxide (CO) gases may enter vehicle
interior resulting in unconsciousness and
death.
To assure sufficient fresh air ventilation,
open a window slightly on the side of the
vehicle not facing the wind.

G

Warning!

The outside temperature display is not
designed to serve as an ice-warning device
and is therefore unsuitable for that
purpose. Indicated temperatures just
above the freezing point do not guarantee
that the road surface is free of ice.

For more information, see “Winter driving”
(

Y

 page 136).

Standing water

Do not drive through flooded areas or

water of unknown depth. Before driving
through water, determine its depth.
Never accelerate before driving into
water. The bow wave could force water
into the engine and auxiliary
equipment, thus damaging them.

If you must drive through standing water,
drive slowly to prevent water from entering
the passenger compartment, the front
compartment, or the engine compartment.
Water in these areas could cause damage to
electrical components or wiring of the

engine or transmission, or could result in
water being ingested by the engine through
the air intake, causing severe internal
engine damage.
Any such damage is not covered by the smart
Limited Warranty.

Passenger compartment

G

Warning!

Always fasten items being carried as
securely as possible.
In an accident, during hard braking or
sudden maneuvers, loose items thrown
around inside the vehicle may injure
vehicle occupants.
The cargo compartment is the preferred
place to carry objects.

Control and operation of radio
transmitters

Radio and telephone

G

Warning!

Please do not forget that your primary
responsibility is to drive the vehicle
safely. Only operate the radio or telephone

16

 if road, weather and traffic conditions

permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.

Telephones and two-way radios

G

Warning!

Never operate radio transmitters equipped
with a built-in or attached antenna (i.e.
without being connected to an external
antenna) from inside the vehicle while the
engine is running. Doing so could lead to a

16

Observe all legal requirements.

Driving instructions

143

>> Operation.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

malfunction of the vehicle’s electronic
system, possibly resulting in an accident
and/or serious personal injury.

Radio transmitters, such as a mobile phone
or a citizens band unit should only be used
inside the vehicle if they are connected to
an antenna that is installed on the outside
of the vehicle.
Refer to the radio transmitter operation
instructions regarding use of an external
antenna.

Emission control

Certain engine systems serve to keep the
toxic components of the exhaust gases
within permissible legal limits.
These systems, of course, will function
properly only when maintained strictly
according to factory specifications.
Any adjustments to the engine should
therefore be carried out only by qualified
smart center authorized technicians.
Engine adjustments should not be altered
in any way. Moreover, the specified service
jobs must be carried out regularly
according to smart servicing
requirements. For details refer to the
Maintenance Booklet.

G

Warning!

Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains
carbon monoxide (CO), and inhaling it can
cause unconsciousness and lead to death.
Do not run the engine in confined areas
(such as a garage) which are not properly
ventilated. If you think that exhaust gas
fumes are entering the vehicle while
driving, have the cause determined and
corrected immediately. If you must drive
under these conditions, drive only with at
least one window fully open at all times.

Coolant temperature

During severe operating conditions and
stop-and-go city traffic, the coolant
temperature may rise close to
approximately 248

¦ (120¥).

The engine should not be operated with the
coolant temperature over 248

¦ (120¥).

Doing so may cause serious engine damage
which is not covered by the smart Limited
Warranty.

G

Warning!

R

Driving when your engine is overheated
can cause some fluids, which may have
leaked into the engine compartment, to
catch fire. You could be seriously
burned.

R

Steam from an overheated engine can
cause serious burns which can occur just
by opening the front compartment cover.
Stay also away from the engine if you see
or hear steam coming from it.

Turn off the engine, get out of the vehicle
and do not stand near the vehicle until the
engine has cooled down.

Driving abroad

Abroad, there is an extensive smart service
network at your disposal. If you plan to
drive into areas which are not listed in the
index of your smart center directory, you
should request pertinent information from
an authorized smart center.

Symmetrical low beams

i

If you drive in countries where

vehicles drive on the other side of the
road than the country in which the
vehicle is registered, you must have the
headlamps modified for symmetrical low

144

Driving abroad

>> Operation.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

beams. Relevant information can be
obtained at any authorized smart center.

Vehicle care

Care tips

Regular and proper care will help to
maintain the value of your vehicle. The
best way to protect your vehicle from
harmful environmental influences is to
wash it and use protective treatments
regularly.
smart recommends that you care for the
paintwork at least twice a year (e.g. in the
spring and autumn).

G

Warning!

Many cleaning products can be hazardous.
Some are poisonous, others are flammable.
Always follow the instructions on the
particular container. Always open your
vehicle’s doors or windows when cleaning
the inside.
Never use fluids or solvents that are not
designed for cleaning your vehicle.
Always lock away cleaning products and
keep them out of reach of children.

Follow the care tips. Wash your vehicle

preferably by hand.

While in operation, even while parked,
your vehicle is subjected to varying
external influences which, if gone
unchecked, can attack the paintwork as well
as the vehicle underbody and cause lasting
damage.
Such damage is caused not only by extreme
and varying climatic conditions, but also
by:

R

Air pollution

R

Road salt

R

Tar

R

Gravel and stone chipping

To avoid paint damage, you should
immediately remove:

R

Insects

R

Bird droppings

R

Tree sap, etc.

R

Grease and oil

R

Brake fluid

R

Coolant

R

Fuel

R

Tar spots

Failure to remove such dirt

immediately can cause damage to the
paint or the soft top fabric*.
Environmental influences are not
covered by the smart Limited Warranty.

Frequent washing reduces and/or
eliminates the aggressiveness and potency
of the above adverse influences.
More frequent washings are necessary to
deal with unfavorable conditions:

R

near the ocean

R

in industrial areas (smoke, exhaust
emissions)

R

during winter operation

You should check your vehicle from time to
time for stone chipping or other damage.
Any damage should be repaired as soon as
possible to prevent corrosion.
In doing so, do not neglect the underbody
of the vehicle. A prerequisite for a
thorough check is a washing of the
underbody followed by a thorough
inspection. Damaged areas need to be re-
undercoated.
Your vehicle has been treated at the factory
with a wax-base rustproofing in the body
cavities which will last for the lifetime of
the vehicle. Post-production treatment is
neither necessary nor recommended by
smart because of the possibility of
incompatibility between materials used in

Vehicle care

145

>> Operation.

* optional

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

the production process and others applied
later.
We have selected vehicle-care products
and compiled recommendations which are
specially matched to our vehicles and
which always reflect the latest technology.
You can obtain smart approved vehicle-
care products at an authorized smart
center.
Scratches, corrosive deposits, corrosion
or damage due to negligent or incorrect
care cannot always be removed or repaired
with the vehicle-care products
recommended here. In such cases it is best
to seek aid at an authorized smart center.
The following topics deal with the cleaning
and care of your vehicle and give important

“how-to” information as well as references
to smart approved vehicle-care products.

Vehicle care

Contact an authorized smart center for
recommended and approved care products.

i

Advice on caring for the soft top

system, see (

Y

 page 149).

G

Warning!

After washing the vehicle, the brakes may
still be wet and thus their functionality
impaired. Therefore, when you start off,
brake lightly several times without
endangering traffic.

To avoid damage to interior equipment and materials: Never rub roughly or use

cleaning spirits on the cloth upholstery, never use strong agents, stain remover etc.
on the leather upholstery. Never scour ore use solvent on plastic parts. Never use strong
and aggressive agents on windows, do not touch the inside of the windows with hard
objects such as an ice scraper or ring, doing so may damage the windows.

Interior

Special
considerations

Light soiling

Heavy soiling

Cloth upholstery

Use a clean, lint-
free cloth

Light soap suds

Stain remover (test
on an inconspicuous
place first)

Plastic parts

Use a color-fast
cloth

Damp, clean cloth,
cockpit spray

Damp, clean cloth,
cockpit spray

Leather upholstery

Use a clean, color-
fast cloth

Clean cloth with
lukewarm water,
leather care
product

Leather care
product

Windows

Damp, clean cloth,
microfiber cloth,
glass cleaner

Microfiber cloth,
glass cleaner

146

Vehicle care

>> Operation.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To avoid damage to exterior surfaces never do the following: Use aggressive paint

cleaner, machine polish, abrasive cleanser, acidic, highly alkaline agents, abrasive
sponges, high-pressure or hot water cleaning equipment.

Exterior

Special
considerations

Lightly soiled
Hand-/Automatic
car washes

Heavily soiled
Hand-/Automatic
car washes

tridion safety cell,
black

Powder coated
single-coat paint
finish

Car shampoo
concentrate, insect
remover for insect
remains, polish

Car shampoo
concentrate, hard
wax, insect remover
for insect remains,
polish

tridion safety cell,
silver

Powder coated
single-coat paint
finish and
clearcoat

Highly polished
plastic parts (body
panels)

Body panels with
base coat and
clearcoat or
clearcoat only

Wheels and wheel
covers

Two-layer metallic
paint (high-gloss)

Car shampoo
concentrate, rim
care

Car shampoo
concentrate, rim
care

Retractable soft top PAC fabric

Car shampoo
concentrate, soft
top cleaner,
impregnation spray

Car shampoo
concentrate, soft
top cleaner,
impregnation spray

Removing insects

Remove insect remains before you start to
wash the vehicle.

X

Spray insect remover on.

X

Allow insect remover to work in briefly.

X

Rub in gently with a soft cloth or sponge.

X

Rinse with plenty of water.

X

Treat the cleaned surface with hard wax.

Removing tar

Remove any tar marks before washing the
vehicle.

X

Apply tar remover with a soft cloth.

X

Allow tar remover to work in briefly.

X

Rub in gently.

X

Rinse with plenty of water.

X

Treat the cleaned surface with hard wax.

Vehicle washing

In the winter, thoroughly remove all traces
of road salt as soon as possible.
When washing the vehicle underbody, do not
forget to clean the inner sides of the
wheels.

Washing your vehicle by hand

X

Wash the vehicle using car shampoo
concentrate and a sponge.

X

Rinse with clean water.

X

Towel dry the vehicle.

Vehicle care

147

>> Operation.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Do not wash the vehicle in direct

sunlight. The body panel surfaces and
paint finish may be damaged.

Washing your vehicle in an automatic car
wash

i

When running your vehicle through an

automatic car wash, water droplets can
run down the inside of the side windows.

Unscrew your vehicle’s antenna before
driving into an automatic car wash.

X

Removing: Unscrew antenna :
counterclockwise.

X

Fitting: Screw antenna : in clockwise.

Power washer

Never use a round nozzle to powerwash

tires. The intense jet of water can result
in damage to the tires.
Always replace a damaged tire.
Do not aim directly at electrical parts,
electrical connectors, seals, or other
rubber parts. The distance should be at
least 3.9 in (10 cm) and the water
temperature must not exceed 140

¦

(60

¥). Follow the instructions provided

by the power washer manufacturer on
maintaining a distance between the
vehicle and the nozzle of the power
washer.
Always keep the jet of water moving
across the surface.

Wheel cover*

X

Wash the wheel cover with shampoo and a
soft brush or in the car wash.

Decorative foils

Decorative foils are permanently

adhered to the painted parts of the
vehicle and cannot be removed.

Do not expose the foils to solvents,

gasoline or diesel.

i

When cleaning with a power washer, note

the following guideline values:

R

Water temperature max. 176

¦ (80¥)

R

Minimum distance 11.8 in (30 cm)

R

Jet of water strike at a right angle

Paintwork care

The frequency with which you care for your
paintwork is dependent on

R

how much the vehicle is used

R

where you normally park the vehicle (e.g.
in a garage or under a tree)

R

the season

R

weather and environmental influences

Rectifying paintwork damage

You can use a touch-up paint pen to repair
minimal stone chip damage and scratches.
Recommended touch-up paint pens can be
obtained in a smart center.

i

For any major paintwork damage, please

contact a smart center.

148

Vehicle care

>> Operation.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Exterior

Repair options

Plastic parts (body
panels) with
clearcoat

Clearcoat touch-up
paint pen

Body panels with
base coat and
clearcoat

recommended
touch-up paint pen
set in the relevant
color

tridion safety cell recommended

touch-up paint pen
set in the relevant
color

Soft top system (cabriolet only)

Regular care will protect the retractable
soft top and the rear soft top against
external influences, helping to preserve
its value. Use only an approved soft top
cleaner when removing dirt from the soft
top.

Never clean the soft top using a power

washer, as water could get into the inside
of the vehicle.

Cleaning the soft top fabric

Only clean the retractable soft top and

the rear soft top when they are closed.

Dry cleaning

X

Brush the soft top fabric with a soft
brush, always working in the same
direction, i.e. from front to back.

Wet cleaning
smart recommends that you use an approved
car shampoo concentrate and soft top
cleaner.

X

“Dry clean” the vehicle first.

X

Wash the soft top off using a soft brush or
sponge and plenty of lukewarm water.

X

Then rinse thoroughly with clear water.

i

If you have the vehicle cleaned in a car

wash, you may find that some water gets
into the interior.

Vehicle care

149

>> Operation.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

150

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Where will I find ...?

Tire repair kit

The tire repair kit is located in the
passenger footwell under the carpet.

X

Insert a suitable object such as a coin
into the slot of carpet holder :.

X

Turn carpet holder : counterclockwise.

X

Lift the carpet.

;

Tire repair kit

The following is included:

R

Tire sealant container

R

Electric air pump with filler hose

R

Sticker

R

Operating instructions label (on the
inside of the tire repair kit lid)

i

The tire sealant container is located

below the tire repair kit.

G

Warning!

The tire repair kit is a limited repair
device. In case of a breakdown caused by a
flat tire, read through the section flat tire
carefully. When using the tire repair kit
follow the instructions in this section.
Failure to follow these instructions can
result in severe injury or death.

First-aid kit*

The first-aid kit is located on the driver’s
side in the cargo compartment.

:

First-aid kit

i

Check expiration dates and contents for

completeness at least once a year and
replace missing/expired items.

Display messages

The following display messages appear in
the multifunction display (

Y

 page 88).

152

Display messages

>> Practical hints

.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Display messages

Possible causes/consequences and

X Solutions

The electronic immobilizer is not working.

X

Have the system checked at an authorized smart center.

There is a malfunction in the shifting system.

X

Have the system checked at an authorized smart center.

The transmission is taught-in (

Y

 page 87).

X

Have the system checked at an authorized smart center.

What to do if ...

Warning and indicator lamps in the
instrument cluster

General information

If any of the following lamps in the
instrument cluster fails to come on during

the bulb self-check when switching on
ignition (

Y

 page 59), have the respective

bulb checked and replaced if necessary.

Brake

Problem

Possible causes/consequences and

X Solutions

¬ (USA only)
! (Canada only)
The ABS indicator
lamp illuminates
while the engine is
running.

There is a malfunction in the ABS system.

X

Have the ABS system checked at an authorized smart center
immediately.

¬ (USA only)
! (Canada only)
The ABS indicator
lamp illuminates
together with the
brake warning lamp
while the engine is
running.

The ABS system fails.

X

Stop the vehicle immediately in a safe location.

X

Do not continue to drive.

X

Turn off the engine.

X

Engage the parking brake when leaving the vehicle.

X

Contact Roadside Assistance or an authorized smart center.

What to do if ...

153

>> Practical hints

.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

G

Warning!

When the ABS system is malfunctioning, the wheels may lock during hard braking, reducing
steering capability and extending the braking distance.

When the ABS is switched off due to a malfunction, the ESP

®

 is also switched off. The basic

driving and braking functions are still available.
The risk of your vehicle skidding is then increased in certain situations. You should
therefore always adapt your speed and driving style to the prevailing road and weather
conditions.

Problem

Possible causes/consequences and

X Solutions

$ (USA only)
J (Canada only)
The brake warning
lamp illuminates
while the engine is
running.

You are driving with the parking brake engaged.

X

Release the parking brake.

The brake circuit fails or the brake fluid level in the brake
fluid reservoir is too low.

X

Stop the vehicle immediately in a safe location.

X

Do not continue to drive.

X

Turn off the engine.

X

Do not add brake fluid as this will not solve the problem.

X

Engage the parking brake when leaving the vehicle.

X

Contact Roadside Assistance or an authorized smart center.

$ (USA only)
J (Canada only)
The brake warning
lamp illuminates
together with the ABS
indicator lamp while
the engine is running.

The ABS system fails.

X

Stop the vehicle immediately in a safe location.

X

Do not continue to drive.

X

Turn off the engine.

X

Engage the parking brake when leaving the vehicle.

X

Contact Roadside Assistance or an authorized smart center.

G

Warning!

Driving with the brake warning lamp illuminated can result in an accident. Have your brake
system checked immediately if the brake warning lamp stays on.
Do not add brake fluid before checking the brake system.

If you find that the brake fluid in the brake fluid reservoir has fallen to the minimum

mark or below, have the brake system checked for brake pad thickness and leaks
immediately. Contact an authorized smart center immediately. Do not add brake fluid
as this will not solve the problem.

154

What to do if ...

>> Practical hints

.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety systems

Problem

Possible causes/consequences and

X Solutions

7 The seat belt

telltale
illuminates
constantly for a
maximum of
6 seconds after
starting the
engine.

Regardless of whether the seat belt is fastened or not, the seat
belt telltale always comes on and remains lit for 6 seconds
after starting the engine.

X

Fasten your seat belts.

7 The seat belt

telltale
illuminates
constantly. An
additional
warning chime
sounds for a
maximum of
6 seconds after
starting the
engine.

The driver’s seat belt is unfastened.

X

Fasten your seat belts.

7 The seat belt

telltale flashes
with
increasing
frequency of a
warning chime
for a maximum
of 60 seconds.

The vehicle speed once exceeds 15 mph (25 km/h), and both the
driver’s and passenger seat belt are unfastened.

X

Fasten your seat belts.

If the driver’s or the passenger seat belt remains unfastened
after 60 seconds, the warning chime stops sounding. The seat
belt telltale stops flashing but continues to be illuminated.
The seat belt telltale will only go out if both the driver’s and
the passenger seat belt (with the passenger seat occupied) are
fastened, or the vehicle is standing still and a door is opened.

6 Scenario 1:

The SRS
indicator lamp
illuminates
when the
ignition is
switched on and
goes out after a
maximum of
4 seconds.

The subsequent self check of the safety systems detected no
malfunction. The supplemental restraint system is
operational.

What to do if ...

155

>> Practical hints

.

Z

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Problem

Possible causes/consequences and

X Solutions

6 Scenario 2:

The SRS
indicator lamp
illuminates
when the
ignition is
switched on and
goes out after a
maximum of
4 seconds for
approximately
1 second, then it
comes on again
and stays on.

There is a malfunction in the supplemental restraint systems.
The air bags or Emergency Tensioning Devices could deploy
unexpectedly or fail to deploy in an accident.

X

Do not sit on the passenger seat; this applies particularly
to children.

X

Have the system checked at an authorized smart center.

G

Warning!

If the SRS indicator lamp does not come on when you switch on the ignition or does not go
out again after a few seconds once the engine is running or comes on again, the supplemental
restraint systems are malfunctioning.
In the event that a malfunction of the SRS is indicated as described in scenario 2, the SRS
may not be operational. For your safety, we strongly recommend that you contact an
authorized smart center immediately to have the system checked; A malfunctioning SRS
system may not deploy when needed in an accident resulting in serious or fatal injury, or
it might deploy unexpectedly and unnecessarily which could result in an accident and/or
injury to you or to others.

If the SRS indicator lamp comes on while driving, have the system checked at an

authorized smart center immediately.
It is possible that the air bag and the emergency tensioning device could be activated
unintentionally or will not function in the event of an accident.

i

Information on the operating principle of the air bags can be found in the “Safety”

section (

Y

 page 35).

156

What to do if ...

>> Practical hints

.

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     7      8      9      10     ..
