Smart fortwo coupe and smart fortwo cabriolet (2019). Manual

seat manufacturer’s instructions. For
children larger than the typical
12‑month‑old child, the passenger front
air bag may or may not be activated.

Warning!

Infants and small children should never
share a seat belt with another occupant.
During an accident, they could be crushed
between the occupant and seat belt.
A child’s risk of serious or fatal injuries
is significantly increased if the child
restraint are not properly secured in the
vehicle and/or the child is not properly
secured in the child restraint.
Children too big for a toddler restraint
must ride in a seat using regular seat belt.
Position shoulder belt across chest and
shoulder, not face or neck. A booster seat
may be necessary to achieve proper seat
belt positioning for children over 41 lbs
until they reach a height where a lap-
shoulder belt fits properly without a
booster.
When the child restraint is not in use,
remove it from the vehicle or secure it with
the seat belt to prevent the child restraint
from becoming a projectile in the event of
an accident.
Do not leave children unattended in the
vehicle, even if the children are secured in
a child restraint system. Unsupervised
children in a child restraint system may
use vehicle equipment and may cause an
accident and/or serious personal injury.

If you are using a rear-facing child
restraint system on the passenger seat, you
must verify that the passenger front air bag
is deactivated. When the passenger front
air bag is deactivated, the
40 indicator lamp is
illuminated (

page 42).

Top tether
Top tether permits an additional
connection between a child restraint
system and the passenger seat. Proper
usage of the top tether, in accordance with
instructions provided by the child
restraint manufacturer, can further reduce
the risk of injuries.
The top tether anchorage is located on the
floor of the cargo compartment. The top
tether guide for the top tether strap is
located above, on the head restraint.

Top tether guide

;

Passenger seat

Top tether anchorage

Top tether hook

Top tether strap of the child restraint
system

Occupant safety

>> Safety.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Thread top tether strap A into top tether
guide : from the front and lead it to the
rear over the head restraint.

Attach top tether hook ? in top tether
anchorage = on the floor of the cargo
compartment.

If you are using divider plus*, the

hooks of the top tether and the divider
plus* are attached to the same anchorage.

Fit the restraint system with top tether.
Always follow the manufacturer’s
assembly instructions!

Warning!

After installing top tether straps, make
sure the seat backrests are in an upright
position and are properly locked. Check for
secure locking by pushing and pulling on
the seat backrests. If a seat backrest is not
properly locked, the seat backrest could
fold. The child seat would no longer be
properly supported or positioned to
provide its intended benefit.

Panic alarm

¯ button

Activating: Press and hold button : for
at least 1 second.
An audible alarm and flashing exterior
lamps will operate briefly.

Deactivating: Press button : once more.

Insert the key in the starter switch.

USA only:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:

1. This device may not cause harmful

interference, and

2. this device must accept any

interference received, including
interference that may cause
undesired operation.

Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.

Canada only:

This device complies with RSS‑210 of
Industry Canada. Operation is subject to
the following two conditions:

1. This device may not cause

interference, and

2. this device must accept any

interference received, including
interference that may cause
undesired operation of the device.

Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.

Panic alarm

>> Safety.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving safety systems

Introduction

Warning!

The following factors increase the risk of
accidents:

Excessive speed, especially in turns

Wet and slippery road surfaces

Following another vehicle too closely

The driving safety systems described in
this section cannot reduce these risks or
prevent the natural laws of physics from
acting on the vehicle.
Always adapt your driving style to the
prevailing road and weather and traffic
conditions and keep a safe distance to
other road users and objects on the street.

In winter operation, the maximum

effectiveness of the ABS, the hydraulic
brake assistant, and the ESP

is only

achieved with winter tires (

page 136)

or snow chains* as required.

Antilock Brake System (ABS)

Warning!

Do not pump the brake pedal. Use firm,
steady brake pedal pressure instead.
Pumping the brake pedal defeats the
purpose of the ABS and significantly
reduces braking effectiveness.

The Antilock Brake System (ABS) regulates
the brake pressure so that the wheels do not
lock during braking. This allows you to
maintain the ability to steer your vehicle.
On slippery road surfaces, the ABS will
respond even to light brake pressure.
The ABS indicator lamp in the instrument
cluster (

page 24) comes on when you

switch on the ignition. It goes out when the
engine is running.

Braking

At the instant one of the wheels is about to
lock up, a slight pulsation can be felt in
the brake pedal, indicating that the ABS is
regulating the brake pressure.

Keep firm and steady pressure on the
brake pedal while experiencing the
pulsation.

Continuous, steady brake pedal pressure
yields the advantages provided by the ABS,
namely braking power and the ability to
steer the vehicle.
A pulsating brake pedal can be an
indication of hazardous road conditions
and functions as a reminder to take extra
care while driving.

Emergency brake maneuver

Keep continuous full pressure on the
brake pedal.

Warning!

When the ABS is malfunctioning, the
hydraulic brake assistant and the ESP

are

also switched off.
When the ABS is malfunctioning, the wheels
may lock during hard braking, reducing
steering capability and extending the
braking distance.

Warning!

The ABS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking or steering efficiency
beyond that afforded by the condition of the
vehicle brakes and tires or the traction
afforded. The ABS cannot prevent
accidents, including those resulting from
excessive speed in turns, following
another vehicle too closely, or
hydroplaning. Only a safe, attentive, and
skillful driver can prevent accidents. The
capabilities of an ABS equipped vehicle
must never be exploited in a reckless or

Driving safety systems

>> Safety.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

dangerous manner which could jeopardize
the user’s safety or the safety of others.

Electronic Stability Program (ESP

)

Your vehicle is equipped with the
Electronic Stability Program (ESP

). The

ESP

is operational as soon as the engine

is running and it monitors the vehicle’s
traction (force of adhesive friction
between the tires and the road surface) and
handling.
The ESP

recognizes when a wheel is

spinning or if the vehicle starts to skid.
By applying brakes to the appropriate
wheel and by limiting the engine output,
the ESP

works to stabilize the vehicle. The

ESP

is especially useful while driving off

and on wet or slippery road surfaces. The
ESP

also stabilizes the vehicle during

braking and steering maneuvers.
The ESP

warning lamp d in the

instrument cluster flashes when the ESP

engaged.
The ESP

warning lamp d in the

instrument cluster comes on when you
switch on the ignition. It goes out when the
engine is running.
Depending on the driving situation, the
ESP

reduces the speed

selectively brakes individual wheels

equalizes the speed of the driven wheels

stabilizes the vehicle when braking

assists you in evasive maneuvers on all
roads

Warning!

If the ESP

warning lamp d in the

instrument cluster flashes, proceed as
follows:

While driving off, apply as little
throttle as possible.

While driving, ease up on the accelerator
pedal.

Adapt your speed and driving style to the
prevailing road conditions.

Failure to observe these guidelines could
cause the vehicle to skid.

The ESP

cannot prevent accidents

resulting from excessive speed.

Warning!

The ESP

cannot prevent the natural laws of

physics from acting on the vehicle, nor can
it increase the traction afforded. The
ESP

cannot prevent accidents, including

those resulting from excessive speed in
turns, or hydroplaning. Only a safe,
attentive, and skillful driver can prevent
accidents. The capabilities of an ESP

equipped vehicle must never be exploited
in a reckless or dangerous manner which
could jeopardize the user’s safety or the
safety of others.

Because the ESP

operates

automatically, the engine must be turned
off (ignition switched off) when the
parking brake is being tested on a brake
test dynamometer. Active braking action
through the ESP

may otherwise seriously

damage the brake system which is not
covered by the smart Limited Warranty.

The ESP

will only function properly if

you use wheels of the recommended tire
size (

page 206).

Driving safety systems

>> Safety.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Hydraulic brake assistant

The hydraulic brake assistant operates in
emergency situations. If you apply the
brakes very quickly, the hydraulic brake
assistant automatically provides full
brake boost, thereby potentially reducing
the braking distance.

Apply continuous full braking pressure
until the emergency braking situation is
over.
The ABS will prevent the wheels from
locking.

When you release the brake pedal, the
brakes function again as normal. The
hydraulic brake assistant is then
deactivated.

Warning!

When the hydraulic brake assistant is
malfunctioning, the brake system is still
functioning normally, but without the
additional brake boost that would normally
be provided during an emergency braking
maneuver. Therefore, the braking distance
may increase.

Warning!

The hydraulic brake assistant cannot
prevent the natural laws of physics from
acting on the vehicle, nor can it increase
braking efficiency beyond that afforded by
the condition of the vehicle brakes and
tires or the traction afforded. The
hydraulic brake assistant cannot prevent
accidents, including those resulting from
excessive speed in turns, following
another vehicle too closely, or
hydroplaning. Only a safe, attentive, and
skillful driver can prevent accidents. The
capabilities of a hydraulic brake assistant
equipped vehicle must never be exploited
in a reckless or dangerous manner which
could jeopardize the user’s safety or the
safety of others.

Activating the hazard warning flasher
after an emergency braking maneuver

If you bring the vehicle to a complete stop
by strongly braking at a speed of more than
43 mph (70 km/h), the hazard warning
flasher automatically comes on as soon as
the vehicle is at a standstill. The hazard
warning flasher will remain on until it is
switched off using the hazard warning
flasher switch (

page 70) or until the

speed of the vehicle has exceeded 6 mph
(10 km/h).

Anti-theft systems

Electronic immobilizer

The electronic immobilizer prevents
unauthorized persons from starting your
vehicle.
When leaving the vehicle, always take the
key with you and lock the vehicle. The
engine can be started by anyone with a key
that is left inside the vehicle.

Activating: Remove the key from the
starter switch.

Deactivating: Insert the key in the
starter switch.

Turn the key to starter switch position
1.

Anti-theft warning system*

Once the anti-theft warning system has
been armed, a visual and audible alarm is
triggered when

someone opens a door or the tailgate

someone enters the vehicle’s interior

there is motion inside the vehicle

someone attempts to raise the vehicle

The alarm will also be triggered when
unlocking and opening the driver’s door
with the key.

Anti-theft systems

>> Safety.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The alarm will stay on, even if the

driver’s door is immediately closed. For
canceling the alarm, see (

page 50).

Close the windows and the tailgate before
arming the alarm system. Make sure there
are no moving objects inside the vehicle.

Arming: Lock the vehicle using the
remote control.
Warning system indicator lamp :
flashes rapidly. The anti-theft warning
system arms after about 25 seconds. When
the anti-theft warning system is armed,
warning system indicator lamp :
flashes about every three seconds.

You can also arm the anti-theft warning

system by locking the vehicle without
using the remote control (

page 166).

Disarming: Unlock the vehicle using the
remote control.
The anti-theft warning system is
disarmed. Warning system indicator
lamp : stops flashing.

Canceling the alarm

Insert the key in the starter switch.

Turn the key to starter switch position
1.

Press button # or * on the key.

Tow-away alarm* and interior motion
sensor*

Once the anti-theft warning system has
been armed, a visual and audible alarm is
triggered when someone attempts to raise
the vehicle or if motion is detected inside
the vehicle.

Arming: Lock the vehicle using the
remote control.
The tow-away protection and the interior
motion sensor arm after about
25 seconds.

Disarming: Unlock the vehicle using the
remote control.
The tow-away protection and the interior
motion sensor are disarmed.

Canceling the alarm

Insert the key in the starter switch.

Turn the key to starter switch position
1.

Press button # or * on the key.

Switching off tow-away protection and
interior motion sensor

Switch off the tow-away protection and the
interior motion sensor when locking the
vehicle and

transporting the vehicle,

board, e.g. a ferry or auto train,

there are people or animals in the
vehicle,

the side windows remain open.

This prevents any false alarm.

Anti-theft systems

>> Safety.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Opening and closing

Key

Key with remote control
:

* Lock button

;

$ Opening the retractable soft top

unlocking the upper tailgate

# Unlock button

The remote control centrally locks and
unlocks:

the driver’s door

the fuel filler flap

the passenger door

the upper tailgate

Warning!

When leaving the vehicle, always remove the
key from the starter switch, take it with
you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is
possible for children to open a locked door
from the inside, which could result in an
accident and/or serious personal injury.

To prevent possible malfunction, avoid

exposing the remote control to high
levels of electromagnetic radiation.

If you can no longer lock or unlock the

vehicle with the remote control, the

batteries in the remote control are
discharged, or the remote control is
malfunctioning.

Check the batteries in the remote
control and replace them if necessary.

If you do not have a spare transmitter
battery at hand, use the key to open the
driver’s door and the fuel filler flap.

If the remote control is malfunctioning,
contact an authorized smart center.

USA only:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:

1. This device may not cause harmful

interference, and

2. this device must accept any

interference received, including
interference that may cause
undesired operation.

Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.

Canada only:

This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions:

1. This device may not cause

interference, and

2. this device must accept any

interference received, including
interference that may cause
undesired operation of the device.

Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.

The remote control has an operating

range of approximately 50 ft (15 meters).

cabriolet only.

coupé only.

Opening and closing

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

This can fluctuate greatly as a
consequence of local conditions
(reflective or absorbing objects) and
interference emitted by other radio-
transmission systems. Similarly, the
operating range fluctuates in line with
the direction from which the remote
control is activated.
To prevent theft, however, it is advisable
to only unlock the vehicle when you are
in close proximity to it.

Locking and unlocking from the
outside

Selective unlocking: Press button # on
the key once.
All turn signal lamps flash once.
The anti-theft warning system* is
disarmed.
The driver’s door and the fuel filler flap
are unlocked.

Global unlocking: Press button # on the
key twice.
All turn signal lamps flash once again.
The passenger door and the tailgate are
unlocked in addition to the driver’s door
and the fuel filler flap.

Global locking: Press button * on the
key.
With the doors, the tailgate(s), and the
fuel filler flap closed the turn signal
lamps flash three times.
The anti-theft warning system* is armed.
The indicator lamp on the central
locking switch flashes (

page 56).

The interior and exterior

lamps come

on and then go out again after 12 seconds.

Automatic locking

Auto-relock function

The vehicle will lock again automatically
within approximately 60 seconds of
unlocking with the key if neither the
driver’s nor passenger door is opened.

To prevent an inadvertent lockout,

never leave your key lying in the vehicle.

Drive lock function

The vehicle locks automatically when the
ignition is switched on and the wheels are
turning at vehicle speeds of approximately
8 mph (14 km/h) or more. The drive lock
function is enabled at the factory.

Switching on: Switch off the ignition.

Press the central locking switch
(

page 56) and button * on the key

simultaneously.
An acoustic signal sounds.
The drive lock function is switched on.

Switching off: Switch off the ignition.

Press the central unlocking switch
(

page 56) and button # on the key

simultaneously.
An acoustic signal sounds.
The drive lock function is switched off.

Locking and unlocking from the inside

Warning!

When leaving the vehicle, always remove the
key from the starter switch, take it with
you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.

You can lock and unlock the vehicle from
inside using the central locking or

Vehicles with rain-light sensor* only.

Opening and closing

>> Controls.

* optional

-------------------------------------------------------------------------------------------------------------------------------------------------------------

unlocking switch. This can be useful, for
example, if you want to unlock the
passenger door from inside or lock the
vehicle before starting to drive.

Locking: Press central locking
switch :.
The indicator lamp on central locking
switch : comes on, when the starter
switch is in position 1.
The indicator lamp on central locking
switch : flashes, when the starter
switch is in position 0.
With the doors and the tailgate closed,
the vehicle locks.

Unlocking: Press central unlocking
switch ;.
The vehicle unlocks and the indicator
lamp on central locking switch : goes
out.

Opening the doors from the inside

You can open a locked door from the inside.
Open door only when conditions are safe to
do so.

Pull on inside door handle :.
With the driver’s door open a warning
signal sounds if the exterior lamps are
switched on and the ignition is switched
off.

Opening the upper tailgate on the
coupé

Warning!

Make sure the tailgate is closed when the
engine is running and while driving.
Among other dangers, deadly carbon
monoxide (CO) gases may enter vehicle
interior resulting in unconsciousness and
death.

Opening and closing

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Press button # on the key twice.

Press and hold button $ on the key for
approximately two seconds.

Pull the release handle in handle
recess : of the lower tailgate.
The upper tailgate is unlocked.

Swivel the upper tailgate upwards to
open.

Observe information on loading the
vehicle (

page 105).

For information on vehicle weights, see
“Vehicle specification” (

page 203).

Opening the lower tailgate on the
coupé

Warning!

High outside temperature, stop-and-go
traffic, driving on long uphill grades, or
driving at high engine speed may increase
the temperature in the engine
compartment. Therefore the area around the
air slots in the rear apron may be hot. Let
the engine cool off before touching this
area to prevent burns.

Open the upper tailgate (

page 56).

Pull both release levers : backwards
either simultaneously or one after the
other.
The lower tailgate is unlocked.

Swivel the lower tailgate downwards to
open.
The lower tailgate is held in the
horizontal position by means of the two
retaining straps.

When folded down, the lower tailgate

can bear loads up to maximum of 220 lbs
(100 kg).

Observe information on loading the
vehicle (

page 105).

For information on vehicle weights, see
“Vehicle specification” (

page 203).

Closing the tailgate(s) on the coupé

Warning!

To prevent possible personal injury,
always keep hands and fingers away from the
cargo compartment opening when closing
the tailgate(s). Be especially careful when
small children are around.

Swivel the lower tailgate upwards to
close. Allow the two release levers to
engage audibly.

Swivel the upper tailgate downwards to
close.

Opening and closing

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Warning!

When leaving the vehicle, always remove the
key from the starter switch, take it with
you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.

Opening and closing the retractable
soft top (cabriolet only)

You can fully open the retractable soft top
with the key.

Key with remote control
:

* Lock button

;

$ Opening the retractable soft top

# Unlock button

Opening: Press button $ on the key for
approximately two seconds.
The retractable soft top opens.

Pressing symbols #, * or $ on the

key with remote control while opening
the retractable soft top will interrupt
the opening procedure.

Closing: Press symbol G on the
retractable soft top switch
(

page 74).

Warning!

When closing the retractable soft top, make
sure there is no danger of anyone being
harmed by the closing procedure.

The remote control has an operating

range of approximately 50 ft (15 meters).
Take care that you do not open your
vehicle’s retractable soft top
inadvertently.

Opening the tailgate on the cabriolet

Warning!

Opening and closing

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Press button # on the key twice.

Pull the release handle in handle
recess : of the tailgate.
The tailgate is unlocked.

Swivel the tailgate downwards to open.

Opening and closing the rear soft top
(cabriolet only)

You can open the rear soft top to ease
loading and unloading.

Opening: Push release levers : to the
left and right of the retaining clip
upwards.

Swivel the rear soft top upwards to open.

Warning!

To prevent possible personal injury,
always keep hands and fingers away from the
cargo compartment opening when closing
the rear soft top. Be especially careful
when small children are around.

Closing: Swivel the rear soft top
downwards to close.

Pull soft top down.

Pull release levers : to the left and
right of the retaining clip downwards.

Make sure the rear soft top is correctly
locked in place on both sides.

Closing the tailgate on the cabriolet

Warning!

To prevent possible personal injury,
always keep hands and fingers away from the
cargo compartment opening when closing
the tailgate. Be especially careful when
small children are around.

When closing the tailgate, you must

first close the rear soft top. Otherwise
you might break the release levers of the
rear soft top.

Swivel the tailgate upwards to close. Let
the tailgate lock into place.

Warning!

When leaving the vehicle, always remove the
key from the starter switch, take it with
you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.

Starter switch positions

Starter switch

Starter switch positions

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

For removing key

Ignition (power supply for all
electrical consumers) and driving
position
All lamps (except low‑beam
headlamp indicator lamp,
high‑beam headlamp indicator
lamp, and turn signal indicator
lamps unless activated) in the
instrument cluster come on. If a
lamp in the instrument cluster fails
to come on when the ignition is
switched on, have it checked and
replaced if necessary. If a lamp in
the instrument cluster remains on
after starting the engine or comes
on while driving, refer to “Warning
and indicator lamps in the
instrument cluster” (

page 153).

Starting (

page 79)

When you switch on the ignition, the

indicator and warning lamps (except
low‑beam headlamp indicator lamp,
high‑beam headlamp indicator lamp, and
turn signal indicator lamps unless
activated) in the instrument cluster
come on. The indicator and warning
lamps (except low‑beam headlamp
indicator lamp, high‑beam headlamp
indicator lamp, and turn signal
indicator lamps if activated) will go out
when the engine is running. This
indicates that the respective systems
are operational.

Seats

Safety notes

Warning!

All seat adjustments, as well as fastening
of seat belts, must be done before the
vehicle is operated.

Warning!

When adjusting the seat, make sure no one
becomes trapped.
Do not adjust the driver’s seat while
driving. Adjusting the seat while driving
could cause the driver to lose control of the
vehicle.
Never ride in a moving vehicle with the seat
backrest in an excessively reclined
position as this can be dangerous. You
could slide under the seat belt in a
collision. If you slide under the seat belt,
it could apply force at the abdomen or neck,
potentially causing serious or fatal
injuries. The seat backrest and seat belts
provide the best restraint when the wearer
is in a position that is as upright as
possible and seat belts are properly
positioned on the body.
Your seat must be adjusted so that you can
correctly fasten your seat belt.
Observe the following points:

Adjust the seat backrest until your arms
are slightly angled when holding the
steering wheel.

Adjust the seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The
position should be as far to the rear as
possible, consistent with ability to
properly operate controls.

Never place hands under the seat or near
any moving parts while a seat is being
adjusted.

Failure to do so could result in an accident
and/or serious personal injury.

Seats

>> Controls.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Smart fortwo coupe and smart fortwo cabriolet (2019). Manual - part 3
