Anti-theft wheel bolts
Anti-theft wheel bolt and upper
The anti-theft wheel bolts protect the wheels from theft. The upper section
must be used to loosen/tighten these.
Insert the upper section
on the anti-theft wheel bolt
until it stops.
Insert the wrench on the attachment
until it stops and loose/tighten the
Removing the upper section.
The attachment for the anti-theft wheel bolts must always be kept in the
vehicle in case of a possible wheel change!
anti-theft wheel bolt should be installed in the position marked on the back of
the wheel trim.
We recommend that you retain the label with the code number. A replacement
upper section can be acquired from ŠKODA original parts based on this.
Loosening/tightening wheel bolts
Loosening the wheel bolts
Push the wheel wrench onto the wheel bolt to the stop. Use the associated
upper section for the anti-theft wheel bolts
To loosen the screws, hold the wrench end and turn the screw about one
turn in the direction of arrow
To tighten the screws, hold the wrench end and turn the screw against the
direction of the arrow
If it proves difficult to undo the bolts, carefully apply pressure to the end of
the wrench with your foot. Keep hold of the vehicle when doing so, and
make sure you keep your footing - risk of accident.
Raising the vehicle
Jacking points for the jack
Fig. 336 Attach lifting jack
Before the vehicle is raised, the safety instructions must be observed
Use the jack from the tool kit to raise the vehicle. Position the jack at the jack-
ing point closest to the wheel to be replaced.
Emergency equipment and self-help
