Seat Tarraco (2022 year). Manual in english

Infotainment system

Privacy and Services Settings

SEAT CONNECT services can be activated
and deactivated individually. To do this, just
check the box corresponding to the service
you want to activate or deactivate. Use the
privacy mode option if you want to deacti-
vate all of the services at the same time.

Privacy mode

Allows you to deactivate or activate the serv-
ices depending on the selected privacy level.



Tracking

Share location.

Main users and co-

users can view position data on the

SEAT CONNECT portal or app.



Location

Use location.

Position, vehicle, and

user data are used for services.



Personal

No location.

Only the vehicle data

and user data are used for services.



Incognito

Maximum privacy.

Your services are

disabled. Only services required for
legal reasons use data.

Setting options are not available in all mar-
kets or in all vehicle models.

Note

If you deactivate each and every SEAT
CONNECT service, the OCU may continue
to transmit data.

Full Link

Introduction

With Full Link it is possible to view and use the
contents and functions that are shown on the
mobile phone device on the infotainment
screen.

To do this, the mobile phone device must be
connected with the infotainment system
through a USB interface.

Some technologies can also be used by
Wireless Full Link through the Bluetooth® in-
terface and a Wi-Fi connection.

The following technologies may be availa-
ble:

●

Apple CarPlay™

●

Android Auto™

●

MirrorLink®

The availability of the technologies that Full
Link includes depends on the country and the
mobile phone device used.

You will find more information on the SEAT
website (www.seat.com).

Access the Full Link main menu

Browsing the Full Link main menu depends on
the infotainment system used.

●

Click on



Full Link

Configure Wireless Full Link

In order to use Wireless Full Link, you must first
pair the mobile phone device with the info-
tainment system. To do this, proceed as fol-
lows:

Connect a mobile phone device for the first
time.

●

Unlock the mobile phone device.

●

Enable Wi-Fi reception and Bluetooth® on

the mobile phone device.

●

Connect the mobile phone device to the in-

fotainment system using a USB cable or via
Bluetooth®.

●

Access the Full Link main menu, unless it

appears automatically.

●

Select the mobile phone device and the

technology you want.

●

Confirm authorisation inquiries on the mo-

bile phone device to grant the necessary au-
thorisations to the infotainment system.

●

Disconnect the USB connection and con-

nect with the infotainment system again via
Wi-Fi or Bluetooth®. Wireless Full Link is now
configured.

The pairing has concluded. The connected
mobile phone device can also use Wireless
Full Link from now on without the USB con-
nection.

188

Data transfer

If pop-up menus are rejected during the con-
nection process, Wireless Full Link will not be
available. In this case, SEAT recommends de-
leting the devices in both the telephone set-
tings and the infotainment system, and re-
starting the connection process.

WARNING

The use of applications while driving can
distract your attention from the traffic. Any
distraction affecting the driver in any way
can lead to an accident and cause injuries.

●

Always drive as carefully and responsibly

as possible.

WARNING

Any applications that are not suitable or
execute incorrectly may cause damage to
the vehicle, accidents and serious injuries.

●

Protect the mobile phone device and its

applications from inappropriate use.

●

Never carry out modifications to the ap-

plications.

●

Follow instructions in the instruction

manual for the mobile phone device.

CAUTION

SEAT cannot be held liable for any damage
caused to the vehicle as a result of the use
of applications that are of poor quality or
are defective, the inadequate program-
ming of the applications, the insufficient

coverage of the network, the loss of data
during transmission or the improper use of
mobile phone devices.

Note

●

Wireless Full Link may not be compatible

with all technologies.

●

Wireless Full Link (Android Auto ™ and Ap-

ple CarPlay ™) is disabled in countries
whose radio frequency regulations do not
allow it to operate.

Applications (apps)

With SEAT Full Link, the display of the con-
tents of SEAT applications and other provid-
ers installed on mobile phone devices can be
transferred to the infotainment screen.

In the case of third-party applications, there
may be compatibility problems.

Applications, their use and the necessary
mobile phone connection may be pay per
use.

The offer of applications can be varied and
designed for a vehicle or a specific country.
The content and volume of applications, as
well as the companies that offer them, may
vary. Some applications also depend on the
availability of third-party services.

It cannot be guaranteed that all the applica-
tions offered will work on all mobile phone
devices or with all their operating systems.

The applications offered by SEAT can be
modified, cancelled, deactivated, reactivated
and extended without prior notification.

To avoid distracting the driver while driving,
only certified applications can be used.

Full Link symbols and settings

To show more information
To open the Full Link settings menu
To select Apple CarPlay™ technology.
To select Android Auto™ technology.
To select MirrorLink® technology.

Apple CarPlay™

In order to use Apple CarPlay™, the following
requirements must be met:

●

The iPhone™

must

be compatible with Ap-

ple CarPlay™.

●

Voice control (Siri ™)

must

be active on the

iPhone™.

●

Apple CarPlay™

must

be active without

limitations in the iPhone™ settings.











189

Infotainment system

●

The iPhone ™

must

be connected to the in-

fotainment system via a USB connection. On-
ly USB connections with data transmission
are suitable for the use of Apple CarPlay™.

●

The USB cable used

must

be an original

Apple™ cable.

Apple CarPlay™ Wireless

: Bluetooth® and

Wi-Fi must also be activate on the iPhone™.

Establish connection

When you first connect an iPhone™, follow
the instructions on the infotainment system
screen and on the iPhone ™.

The requirements must be met to use Apple
CarPlay™.

Launch Apple CarPlay™:

●

Press



Full Link

to access the Full Link

main menu.

●

Press Apple CarPlay™ to establish a con-

nection with the iPhone™.

Disconnecting

●

On the Apple CarPlay™ mode, press the

SEAT

icon to access the Full Link main menu.

●

Press



to interrupt the active connection.

The representation of function buttons on the
screen may vary.

Special characteristics

During an active Apple CarPlay™ connection,
the following characteristics are applicable:

●

Bluetooth® connections between the

iPhone™ and the infotainment system are not
possible.

●

If there is an active Bluetooth® connection,

it is automatically interrupted.

●

The phone functions are only available

through Apple CarPlay™. The functions de-
scribed for the Infotainment system are not
available.

●

The connected iPhone™ cannot be used as

a multimedia device in the Media main menu.

●

It is not possible to use the built-in naviga-

tion system and the Apple CarPlay™ naviga-
tion system at the same time. The last route
started interrupts the one that was previously
active.

●

Depending on the infotainment system you

use, on the instrument panel screen you can
view data from the Telephone and Media
mode.

●

With the multifunction steering wheel you

can accept or reject incoming calls, as well
as end an ongoing telephone conversation.

Voice control

●

Press



briefly to start voice control using

the infotainment system.

●

Press this button for a long time to start

voice control (Siri™) of the connected
iPhone™.

Note

●

The availability of technologies depends

on the country and may vary.

●

You will find information about technical

requirements, compatible iPhones, certi-
fied applications and their availability on
the SEAT (www.seat.com) and Apple Car-
Play ™ websites, or at SEAT dealerships.

Android Auto™

Requirements for Android Auto™

In order to use Android Auto™, the following
requirements must be met:

●

The mobile phone device, called smart-

phone from here on, has to be compatible
with Android Auto™.

●

The smartphone must have an Android Au-

to™ application installed.

●

The smartphone has to be connected

through the USB connection with data trans-
mission with the infotainment system.

●

The USB cable used must be an original ca-

ble provided by the smartphone manufactur-
er.

190

Data transfer

Android Auto™ Wireless:

Bluetooth® and Wi-Fi

also have to be activated on the device.

Establish connection

When you first connect a smartphone, follow
the instructions on the infotainment system
screen and on the smartphone.

The requirements must be met to use Android
Auto™.

Launch Android Auto™:

●

Press



Full Link

to access the Full link

main menu

●

Press Android Auto™ to establish a connec-

tion with the smartphone.

Disconnecting

●

In Android Auto™ mode, press the

SEAT/Exit

icon to access the Full Link main menu.

●

Press



to interrupt the active connection.

Special characteristics

During an active Android Auto™ connection,
the following characteristics are applicable:

●

An active Android Auto™ device can be

connected at the same time via Bluetooth®
(HFP profile) with the infotainment system.

●

It is possible to use the phone’s functions

through Android Auto™. If the Android Auto™
device is connected at the same time via
Bluetooth® with the infotainment system, the

telephone function of the infotainment can
also be used.

●

An active Android Auto™ device

cannot

used as a multimedia device in the Media
main menu.

●

It is

not

possible to use the built-in naviga-

tion system and the Android Auto™ navigation
system at the same time. The last route star-
ted interrupts the one that was previously ac-
tive.

●

On the instrument panel screen you can

view data from the Telephone and Media
mode.

●

With the multifunction steering wheel you

can accept or reject incoming calls, as well
as end an ongoing telephone conversation.

voice control

●

Press



briefly to start voice control using

the infotainment system.

●

Press and hold this button to start voice

control (Google Assistant) on the connected
smartphone.

Note

●

The availability of technologies depends

on the country and may vary.

●

You will find information about technical

requirements, compatible mobile phone
devices, certified applications and their
availability on the SEAT (www.seat.com)

and Android Auto™ websites, or at SEAT
dealerships.

MirrorLink®

Requirements for MirrorLink®

In order to use MirrorLink™, the following re-
quirements must be met:

●

The mobile device must be compatible with

MirrorLink™.

●

The mobile phone device must be connec-

ted to the infotainment system via a USB con-
nection that is suitable for data transmission.

●

The USB cable used must be an original ca-

ble provided by the mobile phone device
manufacturer.

●

Depending on the mobile phone device

used, a Car-Mode application that is suitable
for using MirrorLink® must be installed.

Establish connection

When you first connect a mobile phone de-
vice, follow the instructions on the infotain-
ment system screen and on the mobile phone
device.

The requirements must be met to use Mirror-
Link™.

191

Infotainment system

Launch MirrorLink®:

●

Press



Full Link

to access the Full Link

main menu.

●

Press to establish the connection with the

mobile phone device.

Disconnecting

●

In the MirrorLink® mode, press the

APP

icon

to access the Full Link main menu.

●

OR:

press



to access the MirrorLink® main

menu.

●

Press



to interrupt the active connection.

Special characteristics

During an active MirrorLink® connection, the
following characteristics are applicable:

●

An active MirrorLink® device can be con-

nected to the infotainment system at the
same time via Bluetooth®.

●

If the MirrorLink® device is connected to the

infotainment system via Bluetooth®, the tele-
phone function of the infotainment system
can be used.

●

You cannot use an active MirrorLink® de-

vice as a multimedia device in the Media
main menu.

●

On the instrument panel screen you can

view data from the Telephone mode.

●

The instrument panel screen does not dis-

play any indication to turn or the Media
mode.

●

With the multifunction steering wheel you

can accept or reject incoming calls, as well
as end an ongoing telephone conversation.

Function buttons

Function buttons and their function:

Return the Full Link main menu. Here you

can end the MirrorLink® connection,
connect another mobile phone device or
select another technology.
Press to close the open apps. Then press
the apps to be closed or the

Close all

function button to close all the open ap-
plications.
Press to display the mobile phone device
screen on the infotainment system
screen.
To open the MirrorLink® settings.
Press to return to the MirrorLink® main
menu.

Note

You will find information about technical re-
quirements, compatible mobile phone de-
vices, certified applications and their avail-
ability on the SEAT (www.seat.com) and
MirrorLink® websites, or at SEAT dealer-
ships.

APP









WLAN access point

Introduction

Not available for model: Media System

The infotainment system can be used to
share a WLAN connection with up to 8 devi-
ces

›››

page 193, Configuration for sharing

a connection over WLAN

The infotainment system can also use the
WLAN hotspot of an external device to pro-
vide Internet to the devices connected to the
hotspot (WLAN client)

›››

page 193

Note

●

Data transmission may incur charges.

Due to the high volume of data exchanged,
SEAT recommends the use of a flat rate tar-
iff for data transmission. Mobile phone op-
erators can provide the relevant informa-
tion.

●

The exchange of data packages may

generate additional costs, depending on
your mobile phone rate, particularly if you
are abroad (for example, roaming rates).

192

Data transfer

Configuration for sharing a con-
nection over WLAN

Establishing the connection with the wire-
less network (WLAN)

●

Press the



Settings

button.

●

Activate the wireless network. To do this,

press the function button

Wi-Fi > Infotain-

ment system as hotspot

●

Activate the wireless network (WLAN) on the

device that is to be connected. If necessary,
refer to the manufacturer’s instruction man-
ual.

●

Activate the mobile device assignment in

the infotainment system. To do this, press the
function button

Enable as hotspot

and

check the checkbox.

●

Enter and confirm the network key dis-

played on the device.

The following adjustments can also be made
in the

Infotainment system as hotspot

menu:

●

Security level:

WPA2 encryption automati-

cally generates a network key.

●

Network key:

Network key automatically

generated. Press the function button to man-
ually change the network key. The network
key must have a minimum of 8 characters
and a maximum of 63.

●

SSID:

WLAN Network name (maximum of 32

characters).

The wireless (WLAN) connection is establish-
ed. To complete the connection, it may be
necessary to enter other data into the device.

Repeat this process to connect other devices.

There is also the option of scanning the QR
code by connecting the device directly to the
infotainment system’s Wi-Fi network without
having to enter the password: select

Settings

> Wi-Fi > Quick connection to infotainment
system

Wi-Fi Protected Setup (WPS)

This depends on the equipment and the coun-

try in question.

Wi-Fi Protected Setup

can be used to create

a ciphered local wireless network quickly and
simply.

●

Establish the connection with the wireless

network (WLAN).

●

Press the WPS button on the WLAN router

until the warning light on the router starts
flashing. If the WLAN router does not support
WPS the network must be configured man-
ually.

●

OR:

Press and hold the WLAN button on the

WLAN router until the WLAN light on the router
starts flashing.

●

Press the WPS button on the WLAN device.

The wireless (WLAN) connection is establish-
ed.

Repeat this process to connect other devices.

Configure Internet access

The infotainment system can use the WLAN
hotspot of an external device to establish an
Internet connection.

Establishing the connection with the wire-
less network (WLAN)

●

Activate and share a wireless hotspot with

Internet on the external device. Refer to the
manufacturer’s instruction manual.

●

Press the



Settings

button;

access

the

Media

and press the

Settings

menu.

●

Press the

Wi-Fi > Connect to Wi-Fi

and put a check in the checkbox.

●

Press the

Search for Wi-Fi

button and se-

lect the device you want from the list.

●

If necessary, enter the network key of the

device in the infotainment system and con-
firm with

Manual settings:

●

To manually enter the network settings of

an external (WLAN) device.

193

Infotainment operation

Infotainment operation

voice control

Introduction

Voice control works both online and offline. In
online mode, commands are recorded more
accurately, as more data is available.

Voice control understands questions and ex-
pressions without having to learn commands.
Commands can be formulated freely and
can be colloquial. You will find suggested in-
fotainment commands in the



Help

menu.

Functions are reduced in offline mode.

Loud noises inside or outside the vehicle can
cause malfunctions, as well as confusing
phrases and answers.

Languages available depending on the
market

Online and offline:

German, American Eng-

lish, British English, French, Italian, Spanish,
Czech, Dutch, Polish, Portuguese, Swedish,
Danish and Norwegian. These languages
have advanced functions such as Online
Commands, and natural interaction (e.g. “I’m
cold” turns on the heater), etc.

The other languages of the infotainment sys-
tem

do not

offer Online Commands, air con-

ditioning control or natural interaction.

Requirements

●

Online and offline:

voice control with the

corresponding infotainment installed in the
vehicle.

●

Online

current SEAT CONNECT Plus con-

tract active.

Note

●

Voice control only recognises commands

in the language that is set in the infotain-
ment system.

●

Test the voice control with the vehicle

stopped before starting to move to famili-
arise yourself with its operation.

●

Additional information and examples can

be found in the menu



Help > Voice con-

trol

●

The online voice search will be faster and

more reliable if the privacy setting “Use lo-
cation” is selected and you consent to the
use of location data in the app on your mo-
bile device.

Activation word and commands

Voice control activation words

Voice control starts when the infotainment
recognises the activation word.

If you have connected the voice control via
the wake word, the connected infotainment

responds with

an audible signal.

It then

scans the words spoken after the wake word.

You can also ask the voice control questions
after the wake word, without waiting for the
audible signal, or interrupt speech with a new
command.

Connect and disconnect the activation
word

●

Press



Settings > Voice control > Acti-

vate/deactivate wake word

Activation word:

Hola Hola

Tips

To help the voice control recognise com-
mands reliably:

●

Pronounce clearly. Confusing commands

are not recognised. Speak in a normal tone of
voice. Speak a little louder if you are driving
at high speed.

●

Avoid outside noises. Open windows and

doors can interfere with voice control.

●

Avoid other secondary noises, such as con-

versations in the vehicle. Do not direct the air
flow from the outlets towards the microphone
or the interior lining of the roof.

●

Do not make long pauses.



Voice control is active and recognises the
words pronounced.

195

Infotainment system

Note

●

When the activation word is disconnec-

ted, the infotainment system cannot be ac-
tivated by means of the activation word.
Voice control is still available via the



button on the multifunction steering wheel.

●

Availability depends on the country and

equipment.

Start and stop voice control

Depending on the equipment, you can start
voice control in different ways.

Start voice control

●

Voice control activation:

say the word that

activates voice control.

●

Multifunction steering wheel:

press the

voice control button



In some cases you can also start voice con-
trol of the connected mobile phone device,
by pressing and holding the voice control
button.

Manually ending voice control

Voice control can be cancelled with the

Can-

cel

command.

●

Multifunction steering wheel:

press the

voice control button



twice in a row, or a

long press.

The voice control ends automatically

you use infotainment functions, if the parking
system is activated or if there is an incoming
call.

196

Infotainment operation

Radio mode

Introduction

Fig. 155

Schematic representation: Radio view

In Radio mode you can tune in the available
radio stations in different frequency bands
and memorise your favourites on the preset
buttons to access them quickly.

The types of reception and frequency bands
available depend on the equipment and the
country. In certain countries, frequency
bands may stop broadcasting or not be
available again.

Access the RADIO menu

●

Press

HOME >



›››

Fig. 155

Access the settings

●

Press

HOME >





Online functions in Radio mode

Online functions in Radio mode are only
available under the following conditions:

●

SEAT CONNECT or SEAT CONNECT Plus

equipment.

●

You have an active SEAT CONNECT user

account.

●

Add the vehicle is assigned to your user ac-

count.

●

You have a corresponding data package

acquired from the In-Car store or have a data
volume for your own mobile phone device via
Wi-Fi access point.

Note

●

For streaming services you need to have

an account with the provider in question.

●

Radio stations are responsible for the

content of the information they transmit.
Additional electrical equipment connected
to the vehicle can cause interference in the
reception of the radio signal and noise in
the speakers.

197

Infotainment system

●

Foil or metal-coated stickers attached to

the windows may affect reception on vehi-
cles with a window aerial.

Radio equipment and symbols

The functions, as well as the types of recep-
tion and frequency bands available depend
on the equipment and the country.

●

AM tuner.

●

Dual FM receiver (diversity antenna).

●

Summarised FM station list.

●

Fusion of DAB and FM stations into one list.

●

Fusion of all stations stored in preset but-

tons into one list. Maximum 36 favourite sta-
tions.

●

Station logos.

●

DAB presentation (slideshow). Images that

are emitted sequentially.

●

Internet radio.

Universal symbols in Radio mode

To select the desired AM frequency
band.

To select the desired FM/DAB fre-

quency band.

To select the type of Internet

radio reception.

FM/DAB

Online radio

Next to the name of the station, monitor-
ing of active traffic information stations
(TP).

Symbols on the FM/DAB frequency band

To display the frequency band for man-
ual selection of the FM frequency. Only
possible when the summary station list is
disconnected.
DAB not available.
DAB stations support presentations (sli-
deshow).

Symbols on the AM frequency band

Manually updating the station list.
To display the frequency band for man-
ual selection of the AM frequency.

Menus in Internet radio mode

Show station selection.
Open text search.
Show the last online radio stations
heard.
Show the 100 most played radio stations
and podcasts.
Show available online radio podcasts.

Show online radio stations, grouped by
country.
Show online radio stations by the de-
sired language.

























Show online radio stations whose pro-
gramme belongs to the desired musical
genre.

Selecting, tuning and saving a sta-
tion

Select the frequency band

Before selecting a station you have to select
a frequency band or a type of reception. Dif-
ferent stations are available depending on
the frequency band selected or the type of
reception.

The types of reception and frequency bands
available depend on the equipment and the
country.

●

Select the frequency band or type of re-

ception: AM, FM/DAB, FM (for devices that do
not have DAB), Internet radio.

Search and select a station

You can select radio stations in different
ways. The options vary depending on the fre-
quency band and the type of reception.

Select via the frequency band (AM and
FM)

●

Activate the frequency band.



198

Infotainment operation

●

Click on the cursor, scroll through the fre-

quency band and release it when you reach
the frequency band you want.

●

OR:

press on a point on the frequency

band. The cursor will automatically jump to
the corresponding frequency.

The station of the set frequency is tuned.

Select from the station list (AM and
FM/DAB)

The station list shows the stations that are
currently tunable. In the AM frequency band,
you may have to update the station list if you
are no longer in the area where you last ac-
cessed the station list. In the FM/DAB fre-
quency band, the station list is automatically
updated.

●

Open the station list

●

Press the station you want.

The selected station is tuned. In the case of
FM/DAB and if the station is available, the
best quality reception is automatically selec-
ted.

Search and filter stations (Internet radio)

In Online Radio mode, stations can be filtered
by categories and can be searched by text.

●

Open the station list.

●

Select the category by which the stations

are to be filtered.

●

OR:

press



to start the text search. The in-

put field is displayed.

●

Enter the name of the station you want. The

list of the stations found is updated while en-
tering the text.

●

Press the station you want.

The selected station is tuned.

Search in SCAN mode (AM and FM/DAB)

In SCAN mode the stations are automatically
tuned in a sequential manner and each of
them is played for approx. 5 seconds.

●

To start the SCAN mode, under

Settings

press

SCAN

SCAN mode starts and the station currently
tuned in is shown on the screen. Next to it is a
SCAN function button.

●

To select a station press SCAN.

SCAN mode stops and the station is tuned.
The SCAN function button is hidden.

Storing the station on the preset buttons

You can store up to 36 stations of different
frequency bands and reception types as fa-
vourites using the preset buttons.

●

Tune the station you want.

●

Access the preset buttons.

●

Press the preset button and keep it pressed

until the station is stored.

●

OR:

press the station on the station list and

keep it pressed. The preset buttons are dis-
played.

●

Press the preset button.

The station is stored in the selected preset
button.

If a station was already stored in the preset
button, it is overwritten with the new station.

Special functions in Radio mode

Traffic information (TP)

The TP function monitors the announcements
of a station with traffic information and auto-
matically reproduces them in the Radio mode
or in the multimedia playback that is active.
To do this, you have to be able to tune into a
station with traffic information.

Some stations without their own traffic infor-
mation support the TP function by broad-
casting traffic information from other stations
(EON).

In the AM frequency band or in the Multime-
dia mode, a station with traffic information in
the background is automatically tuned while

199

Infotainment system

it is possible to tune into a station with traffic
information.

If no station with traffic information can be
tuned in, the device automatically searches
for stations with tunable traffic information.

Stations with traffic information are not avail-
able in all countries.

Activating and deactivating the TP func-
tion

●

In Radio mode or Multimedia mode, press

Settings > Traffic station (TP)

Online radio

Online radio is a type of reception for Internet
radio stations and podcasts that are inde-
pendent of AM, FM and DAB. Thanks to Inter-

net transmission, reception is not limited to
the region.

Online radio is only available through the In-
ternet connection of the active infotainment
system. The use of online radio can generate
expenses due to the transmission of data
from the Internet.

●

In Online radio mode, press and set the au-

dio quality to high or low to tune the online ra-
dio.

Station logos

In the case of some frequency bands, station
logos may already be pre-installed in the in-
fotainment system.

If in the FM/DAB frequency band settings the

automatic selection of station logos

is ac-

tivated, station logos are automatically as-
signed to the stations.

In the Online radio mode, the infotainment
system accesses the station logos of the on-
line database and automatically assigns
them to the stations

Assign station logos manually

●

In FM/DAB mode, press

Station logos

●

Press on the



icon and then select the

station to which a station logo is to be as-
signed.

●

Select the station logo. If desired, repeat

the same process with other stations.

●

, via the menu

Settings > Station logos

200

Infotainment operation

Media Mode

Introduction

Fig. 156

Schematic representation: Multimedia

view

In Media mode you can play multimedia files
from data media and streaming services
through the infotainment system.

Depending on the equipment, the following
data media can be used:

●

USB storage support (for example, a USB

stick, a mobile phone connected via USB).

●

Bluetooth® device (for example, a mobile

phone or a tablet).

Depending on the equipment, the following
types of multimedia files can be played:

●

Audio files.

●

Video files (depends on the system).

You can also use streaming services. The
availability of streaming services depends on
the equipment and the country.

To use streaming services you need to have
your own user account in the streaming serv-
ice in question.

Access the MEDIA menu

●

Press

HOME >



›››

Fig. 156

Access the settings

●

Press

HOME >





Limitations and indications of data media

Data media may not work if they have been
exposed to high temperatures or have been
damaged. Please bear in mind the manufac-
turer’s indications.

Quality differences between data media pro-
duced by different manufacturers can cause
multimedia playback malfunctions.

Incorrect configuration on a data media may
cause the data media to be unreadable.

Playlists only specify a playback order and
refer to the storage location of the multime-
dia files within the folder structure. In a

201

Infotainment system

playlist there are no multimedia files saved.
To play a playlist, multimedia files have to be
found in the storage places of the data media
to which the playlist refers.

Note

SEAT assumes no liability for any deteriora-
tion or loss of files on data storage devices.

Features of the multimedia equip-
ment and symbols

Audio, multimedia and connectivity:

●

Multimedia playback and control via Blue-

tooth®.

●

Audio playback in these formats: AAC,

ALAC, AVI, FLAC, MP3, MP4, WMA.

●

Video playback in these formats: MPEG-1

and MPEG-2 (.mpg, .mpeg), ISO MPEG4, DivX
3, 4 and 5 Xvid (.avi), ISO MPEG4 H.264
(.mp4, .m4v, .mov), Windows Media Video 10
(.wmv, .asf).

●

Playlists on any type of device.

●

Multimedia streaming (online).

●

Multimedia search.

Universal symbols in Media mode

To start playback.
To pause playback.





To change to the previous title.
To change to the next title.
Repeat the current track.
Repeat all titles.
To activate the shuffle playback order.
To display the favourites list.
Add multimedia file as favourite.
Top right: Select multimedia source.
Access the settings.
Open the search.
To return to the top folder of the multi-
media source.

Select and play a multimedia
source

Select multimedia source

Before playing multimedia files you must first
connect a multimedia source.

To use streaming services you must be con-
nected to the Internet.

●

Connect an external multimedia source.

●

Select the connected media source to be

used for playback.























Playing audio and video files

You can search and play multimedia files
from an available multimedia source in differ-
ent ways.

Search in the folder structure

Multimedia files can be catalogued by cate-
gories (for example, album, artist, title). In

media

this category view is always dis-

played. The classic folder structure of individ-
ual USB data media is also found in

My me-

dia

Activate the folder structure.
The folder structure of the selected mul-
timedia source is displayed. When

media

is selected, the categories (mu-

sic, videos, playlists) and connected
multimedia sources are displayed first.
Search for the title you want in the folder
structure.

OR:

press



to start the text search. The

input field is displayed.
Enter the name of the desired title. The
list of the titles found is updated while
entering the text.
Press the desired title.
If at the beginning of the playback your
selection is in a folder of a multimedia
source, the multimedia files that are in it
are also added to the playback.

202

Infotainment operation

If a playlist is played, all available titles
in the playlist are added to the play-
back.
Close your selection with



Select favourites

In favourites you can save titles, music gen-
res, artists and albums individually for play-
back.

●

Access favourites



●

Press the favourite you want.

Depending on your selection, all the titles be-
longing to the favourite are added to the
playback.

Configure streaming services

Depending on the equipment you can use
streaming services directly through the info-
tainment system. For this you need to have a
premium user account of the streaming serv-
ice in question and you have to log in with it in
the infotainment system. You also need to be
connected to the Internet.

Select



Streaming

as the multimedia

source.
A list of available streaming services is
displayed.

Select the streaming service you want.
Follow the steps indicated by the info-
tainment system.
The streaming service is added to the list
of multimedia sources as a new function
button.

Save favourites

Only multimedia files in

My media

of the info-

tainment system can be saved as favourites.
You can save up to a maximum of 30 titles, al-
bums, artists and music genres individually as
favourites.

Start playback.
Access favourites.
Tap a favourite that is not assigned.

OR:

press on an existing favourite and

old for approx. 3 seconds.
Select from the selection list: Title, Al-
bum, Artist, Music genres, Playlist.

The selection is saved instead of the previ-
ously selected favourite. If the favourite was
already assigned, the previously saved fa-
vourite is overwritten.

The selectable options in the selection list
depend on the data attached to the multime-

2.
3.

1.
2.
3.

dia file. If the music genre is not indicated in
the music files, for example, you cannot save
the music genre as favourite.

If a video file is playing, only that video can
be saved as favourite.

Playing entertainment content in
the infotainment system

Depending on the infotainment system, vid-
eos can be played.

Video mode

When in video mode, a video can be played
on the infotainment screen if this is stored on
a data media, in

My media

or is sourced from

a streaming service. In this case, the video
sound is played through the vehicle's speak-
ers.

The image is only displayed if the vehicle is
stopped. When the vehicle is in motion, the in-
fotainment screen turns off. The sound of the
video can still be heard.

A stable Internet connection is required for
playback from a streaming service. In this
case, telephony costs may be generated.

203

Seat Tarraco (2022 year). Manual in english - page 12
