button.

●

The parking brake is activated when the

control light of button

›››

and the

red



control lamp on the instrument panel is

always on.

●

Release the button.

Disconnecting the electronic parking
brake

●

Switch the ignition on.

●

Press the button



›››

. At the same

time step hard on the brake pedal or, if the
engine is running, press the accelerator pedal
slightly.

●

The control lamp of button

›››

and

the

red



control lamp on the instrument

panel go out.

Automatic release of the electronic park-
ing brake upon moving off

The electronic parking brake is automatically
switched off when starting if, after the driver's
door is closed and the driver's seat belt fas-
tened,

any

of the following situations take

place:

272

Braking and parking

●

In vehicles with automatic gearboxes:

gear is engaged or changed to another and
the accelerator is pressed gently.

●

In vehicles with manual gearboxes:

the

clutch pedal is pressed fully before starting
off and the accelerator is pressed gently.

●

To facilitate certain manoeuvres there are

exceptions that allow the automatic parking
brake to be released without the driver's seat
belt being fastened.

The parking brake can be prevented from be-
ing automatically released by continuously
pulling up the



›››

switch when

starting off.

The electronic parking brake is not discon-
nected until the



button is released. This

can facilitate starting off when a heavy load
is towed

›››

page 294

Automatic activation of the electronic
parking brake when exiting the vehicle in-
correctly

In vehicles with automatic transmission, the
electronic parking brake is activated auto-
matically when exiting the vehicle incorrectly
if:

●

The selector lever is in the

D/S

or is in

tiptronic mode.

●

AND:

the vehicle is stationary.

●

AND:

the driver door is open.

Automatic activation of the electronic
parking brake when turning the ignition off

In vehicles with manual transmission, the
electronic parking brake is activated auto-
matically when turning the ignition off. This
function can be deactivated through the Info-
tainment system

›››

page 93

Emergency brake function

Only use the emergency brake function if you
are unable to stop the vehicle with the foot
brake

›››

●

Pull and hold the



›››

page 274, Conditions for keeping

button in

this position to

forcefully

stop the vehicle. At

the same time, an acoustic warning can be
heard.

●

To stop the braking process, release the



button or press the accelerator.

WARNING

The improper use of the electronic parking
brake can cause accidents and serious in-
jury.

●

Never use the electronic parking brake to

stop the vehicle, unless it is an emergency.
Braking distances can be considerably lon-
ger, since, under certain circumstances,
only the rear wheels brake. Always use the
foot brake.

●

Never accelerate from the engine when a

gear range or a gear is engaged and the
engine is running. The vehicle could move,

even if the electronic parking brake is acti-
vated.

●

When the electronic parking brake is

switched on or off, there is a slight move-
ment of the brake pedal. Be careful not to
position your foot under the pedal.

CAUTION

To prevent the vehicle from unintentionally
moving when parking it, first apply the
electronic parking brake and then remove
your foot from the brake pedal.

Note

●

In vehicles with a manual gearbox, re-

leasing the clutch and accelerating at the
same time automatically disconnects the
electronic parking brake.

●

If the 12-volt vehicle battery is flat, it will

not be possible to switch off the electronic
parking brake. Use the jump-start

›››

page 53

●

When the electronic parking brake is ap-

plied or released, noises may be heard.

●

The system performs automatic and au-

dible tests sporadically in the parked vehi-
cle if some time elapses without the elec-
tronic parking brake being used.

273

Driving

Auto Hold Function

Fig. 199

In the lower part of the centre con-

sole: Auto Hold function button.

The Auto Hold

›››

Fig. 199

button's indicator

lamp remains on while the Auto Hold function
is switched on.

Once connected, the Auto Hold function as-
sists the driver in keeping the vehicle station-
ary at repeated intervals or for a certain peri-
od of time with the engine running, for exam-
ple, when going up a slope, when stopped at
traffic lights or in heavy traffic with intermit-
tent stops.

When connected, the Auto Hold function au-
tomatically prevents the vehicle from rolling
when stationary without pressing the brake
pedal.

After detecting that the vehicle is stationary
and the brake pedal has been released, the

Auto Hold function holds the vehicle. The driv-
er can lift their foot off the brake pedal.

When the driver touches the accelerator
pedal or accelerates slightly to continue driv-
ing, the Auto Hold function releases the brake.
The vehicle moves according to the slope of
the road.

If the vehicle is stationary and one of the con-
ditions required by the Auto Hold function is
impaired, it disconnects itself and the button's
control light goes out

›››

Fig. 199

. The elec-

tronic parking brake connects automatically,
if necessary, to park the vehicle safely

›››

Conditions for keeping the vehicle station-
ary with the Auto Hold function

●

The driver door must be closed.

●

The driver's seat belt must be fastened.

●

The engine is running.

Switching the Auto Hold function on and
off

Press the Auto Hold

›››

button. The control

lamp on the button goes out when the Auto
Hold function is switched off.

Automatically engaging and disengaging
the Auto Hold function

If the Auto Hold function was switched on with
the Auto Hold button before switching off the

ignition, the function will remain on the next
time the ignition is switched on.

If the Auto Hold function was not switched on,
it will automatically remain off next time the
ignition is engaged.

The Auto Hold function connects automat-
ically if the following conditions are met

(all points must be met

at the same time

›››

The vehicle is kept

stationary

with the

brake pedal on a flat surface or on a
slope.
The engine rotates “correctly”.

The Auto Hold function is automatically
turned off if the following conditions are
met:

If any of the conditions mentioned on

›››

the vehicle stationary with the Au-
to Hold function

are no longer met.

If the engine is running irregularly or an
anomaly is detected.
If the engine stalls.

Manual gearbox:

The clutch and the ac-

celerator are pressed at the same time.

Automatic gearbox:

If the accelerator is

pressed

Automatic gearbox:

If any of the tyres

has only minimal contact with the

3.
4.

274

Braking and parking

ground, e.g. in the case of axle articula-
tion.

WARNING

The smart technology incorporated into
the Auto Hold function cannot defy the
laws of physics; it only works within the lim-
its of the system. The greater convenience
provided by the Auto Hold function should
never tempt you to take any risk that may
compromise safety.

●

Never leave the vehicle running and with

the Auto Hold function switched on.

●

The Auto Hold function cannot always

keep the vehicle stationary uphill or down-
hill or stop it sufficiently, for example, on
slippery or frozen surfaces.

Note

Before entering a car wash tunnel, always
switch off the Auto Hold function and the
automatic connection of the parking brake
when switching off the ignition

›››

page 273

since if the electronic parking brake is au-
tomatically connected, this may lead to
damages.

Stabilisation and brake as-
sistance systems

Control lamps



It lights up

Fault in the ESC or ABS, or disconnection caused by
the system.

The ESC works in combination with the ABS. If the
ABS fails, the lamp also lights up.



Flashes

ESC or TCS activated.



It lights up

TCS switched off manually.

: ESC in Sport mode

›››



It lights up

ABS faulty or does not work.

WARNING

When the ignition is switched on, the status
of the brake system and the brake assist
functions is automatically checked. The
control lights on the instrument cluster
light up briefly and then turn off again. If a
warning light stays on permanently, there

is a fault. Seek qualified technical assis-
tance immediately.

Brake assist systems

Electronic Stability Control (ESC)

The ESC helps to improve safety. It reduces
the tendency to skid and improves the stabili-
ty and roadholding of the vehicle. The ESC
detects critical handling situations, such as
vehicle understeer or oversteer, or wheelspin
on the driving wheels. It stabilises the vehicle
by braking individual wheels or by reducing
the engine torque. The warning lamp will
flash on the instrument panel when the ESC is
intervening



The ESC includes the anti-lock brake system
(ABS), the hydraulic brake assist (HBA), the
traction control system (TCS), electronic dif-
ferential lock (EDS), electronic torque control
(XDS) and the tractor-trailer sway mitigation.

ESC also helps stabilise the vehicle by
changing the torque.

The TCS can be deactivated when wheel
spin is desirable

›››

Anti-lock brake system (ABS)

ABS prevents the wheels from locking up un-
der braking until the vehicle has reached a
virtual standstill. You can continue to steer the

275

Driving

vehicle even when the brakes are on full.
Keep your foot on the brake pedal and do not
pump the brakes. You will feel the brake pedal
pulsate while the ABS is working.

If the running gear or brake system is modi-
fied, the effectiveness of the ABS could be se-
verely limited.

Hydraulic Brake Assist (HBA)

The brake assist system can reduce the re-
quired braking distance. The braking force is
automatically boosted if you press the brake
pedal quickly in an emergency. You must
keep pressing the brake pedal until the dan-
ger has passed.

Traction control (TCS)

In the event of the wheels spinning, the TCS
reduces the engine torque to adapt to the
road condition. This helps the car to start
moving, accelerate or climb a gradient.

Electronic differential lock (EDL)

When the EDL detects wheelspin, it brakes
the spinning wheel and directs the power to
the other driven wheel. This function is active
up to approximately 100 km/h (62 mph).

To prevent the disc brake of the braked wheel
from overheating, the EDL cuts out automati-
cally if subjected to excessive loads. The ve-
hicle can still be driven. The EDL will switch on

again automatically when the brake has
cooled down.

Tractor-trailer sway mitigation

If the vehicle is pulling a trailer, it will control
the following: tractor-trailers tend to sway.
When the swaying of the trailer is felt by the
vehicle and detected by the ESC, it will auto-
matically brake the towing vehicle within the
limits of the system and mitigate the sway.
Tractor-trailer sway mitigation is not available
in all countries

›››

page 299

Electronic engine torque management
(XDS)

When taking a curve, the driveshaft differen-
tial allows the outer wheel to turn at a higher
speed than the inner wheel. In this way, the
wheel that is turning faster (outer wheel) re-
ceives less drive torque than the inner wheel.
This may mean that in certain situations the
torque delivered to the inner wheel is too
high, causing the wheels to spin. On the other
hand, the outer wheel is receiving a lower
drive torque than it could transmit. This can
cause a loss of grip on the drive axle, in this
case the front axle, which results in under-
steer or “lengthening” of the trajectory.

The XDS can detect and correct this effect
via the sensors and signals of the ESC.

Via the ESC, the XDS will brake the inside
wheel and counter the excess driving torque

of that wheel. This means that the requested
trajectory is much more precise.

XDS works in combination with the ESC and is
always active, even when TCS is switched off,
or when the ESC is in Sport mode or discon-
nected.

Multi-collision brake

The multi-collision brake consists of automat-
ic braking activated by the Airbag control
unit. It is activated when, in the event of an
accident, the Airbag control unit detects de-
celerations above the activation level, and
braking is managed by the ESC system.

In the event of an accident, the multi-collision
brake can help the driver by braking to avoid
the risk of skidding during the accident and
causing other collisions.

The following actions control automatic brak-
ing during the accident:

●

When the driver presses the accelerator,

the automatic braking does not take place.

●

When the braking pressure through press-

ing the brake pedal is greater than the sys-
tem’s braking pressure the vehicle will brake
automatically.

●

Multi-collision braking will not be available

if there is an anomaly in the ESC system.

276

Braking and parking

Electromechanical brake servo (eBKV)

With the ignition switched on, the electrome-
chanical brake servo supports the force of
the foot by increasing the pressure that the
driver exerts on the brake pedal. When the
brakes are applied by the driver assist sys-
tems, such as those regulated by the ACC
(adaptive cruise control) or emergency brak-
ing, the brake pedal may move downwards.
After disconnecting the ignition, the assis-
tance of the brake servo is progressively re-
duced. Once stopped, immobilise the vehicle
to prevent it from moving.

Please follow the parking instructions

›››

If the electromechanical brake servo does
not work, the red symbol



indicating failure

in the brake system appears in the instrument
panel. When braking with the faulty electro-
mechanical brake servo, vibration of the
brake pedal may occur.

If the electromechanical brake servo is not
working, the brake pedal must be pressed
harder, as the braking distance increases due
to the lack of assistance from the servo brake.

Brake blending

The brake energy recuperation can generate
a braking effect. This braking effect depends

on the selected driving programme and the
level of charge of the high-voltage battery.

If the braking effect caused by the recupera-
tion is very intense, the vehicle’s brake lights
with turn on. The electric engine, when oper-
ating as an alternator, can generate braking
torque on the front wheels based on the RPM
and the temperature and charge level of the
high-voltage battery.

These variable parameters cause fluctuating
electric decelerations which are hydraulical-
ly compensated according to the driver’s de-
sires. This function is called “brake blending”
and it combines mechanical braking with the
engine brake effect.

WARNING

Driving at high speed on icy, slippery wet
ground can result in loss of vehicle control
and serious injury to the driver and passen-
gers.

●

The ESC, ABS, TCS, EDS or electronic tor-

que management are not in a position to
overcome the limits imposed by physics.
Always bear this in mind, especially on wet
or slippery roads. If you notice the systems
cutting in, you should reduce your speed
immediately to suit the road and traffic
conditions. Do not be encouraged to take

risks by the presence of more safety sys-
tems. If you do, an accident may occur.

●

Please remember that the accident risk

always increases if you drive fast, espe-
cially in corners or on a slippery road, or if
you follow too close behind the vehicle in
front of you. The ESC, ABS, brake assist,
EDS and the electronic torque control sys-
tem cannot prevent accidents: risk of acci-
dents!

●

Accelerate with caution on slippery sur-

faces (for example, icy or snow-covered).
Despite the control systems, the driven
wheels could spin, affecting the stability of
the vehicle: risk of accident!

Note

●

The ABS and TCS will only operate cor-

rectly if the four wheels have identical
tyres. Any differences in the rolling radius
of the tyres can cause the system to re-
duce engine power when this is not desired.

●

The regulating processes of the systems

can make noises due to their operation.

●

If the warning lamp





lights up,

there could be a fault

›››

page 87

●

Any modifications made to the vehicle

(for example, to the engine, brake system,
running gear or to the combination of

Valid for hybrid vehicles

277

Driving

wheels and tyres) may affect the operation
of the ABS, TCS and EDS.

Connecting and disconnecting the
ESC and TCS

The ESC is switched on automatically when
the engine is started, and only works when
the engine is running and includes the ABS,
EDS and TCS systems.

The TCS function should only be switched off
in situations where traction is insufficient.

Depending on the finishes and versions, it is
possible to only switch off the TCS, or to
switch on the ESC in “Sport” mode.

Switching the TCS off and on

●

The TCS can be turned on or off in the info-

tainment system: function button



> Assis-

tants > ESC menu

›››

page 93

. In vehicles

with a driver information system the corre-
sponding indication will be displayed.

When the TCS is switched off, the indicator
lamp



lights up on the instrument cluster.

Disconnecting and connecting the ESC in
“Sport” mode

●

The ECS in “Sport” mode can be turned on

or off in the infotainment system: press the
function button



> Assistants > ESC Menu

›››

page 93

. In vehicles with a driver informa-

tion system the corresponding indication will
be displayed.

When “Sport” mode is connected, the inter-
ventions of the ESC to stabilise the vehicle,
and the traction control (TCS) interventions
are limited. In addition, the



control lamp

lights up on the instrument panel.

WARNING

The ESC Sport mode should be activated
only when traffic conditions and the ability
of the driver allow it. Danger of skidding!

●

With ESC in Sport mode, the stabilising

function will be limited to allow for a sporti-
er drive. The driving wheels could spin and
the vehicle could skid.

Note

If the TCS is switched off or the Sport mode
is selected, the cruise control is switched
off.

Parking

To park the vehicle

When parking your vehicle, all legal require-
ments should be observed.

Always note the following points when park-
ing the vehicle:

●

Park the vehicle on a suitable surface

›››

●

Connect the electronic parking brake

›››

page 272

●

Automatic transmission: switch on the park-

ing lock by pressing button

●

Stop the engine and turn off the ignition.

Turn the steering wheel slightly to engage the
steering lock.

●

With a manual gearbox, engage first gear

on flat ground and slopes, or even reverse
gear on hills, and release the clutch pedal.

●

When leaving the vehicle, take all keys with

you.

Additionally, on steep slopes and inclines

Before switching off the engine, rotate the
steering wheel so that if the vehicle should
move, it will be held by the kerb.

●

On slopes, turn the front wheels so that

they are against the edge of the kerb.

●

Uphill, turn the wheels towards the centre of

the road.

WARNING

●

Avoid parking the vehicle where the hot

exhaust system could ignite inflammable
materials, such as dry grass, low bushes,
spilt fuel or flammable materials.

278

Help with parking and manoeuvring

●

Do not leave passengers inside a closed

vehicle, they may not be able to open
doors or windows. Locked doors hinder the
possibility of a rescue.

●

Children should not be left alone in the

vehicle. They could tamper with the hand-
brake or the gears, which could cause the
vehicle to move without control.

●

Depending on weather conditions, it may

become extremely hot or cold inside the
vehicle. This can be fatal.

Help with parking and ma-
noeuvring

Assisted parking system
(Park Assist)

Introduction

The parking assist system is an additional
function of the ParkPilot

›››

page 286

and

helps the driver find a suitable parking space
from among the following types:

●

park driving in reverse in suitable perpen-

dicular and parallel spaces,

●

park driving forwards in suitable perpendic-

ular spaces,

●

exit a parking space driving forwards from a

parallel space,

●

park in a suitable space driving forward on

angle partially entering into the selected
parking space. The system will centre the ve-
hicle in said parking space.

In vehicles with a Park Assist system and fac-
tory infotainment system, the front, rear and
side areas are represented, and the position
of obstacles is shown relative to the vehicle.

The Park Assist system is subject to certain
limitations inherent to the system and its use
requires special attention by the driver

›››

WARNING

The technology used in the park assist sys-
tem involves a series of limitations inherent
in the actual system and in the use of ultra-
sonic sensors. The use of Park Assist should
never tempt you to take any risk that may
compromise safety. The system is not a re-
placement for driver awareness.

●

Any accidental movement of the vehicle

could result in serious injury.

●

Adapt your speed and driving style at all

times to suit visibility, weather, road and
traffic conditions.

●

Certain surfaces of objects and gar-

ments do not reflect the ultrasound sen-
sors' signals. The system cannot detect, at
least correctly, these objects or people
wearing such clothes.

●

Ultrasound sensor signals may be affec-

ted by external sound sources. In certain
circumstances this may prevent them from
detecting people or objects.

●

The ultrasound sensors may have blind

spots in which obstacles and people are
not detected.

●

Monitor the area around the vehicle at all

times, since the ultrasound sensors do not
detect small children, animals or certain
objects in all situations.

279

Driving

WARNING

Quick turns of the steering wheel when
parking or exiting a parking space with
Park Assist can cause serious injury.

●

Do not hold the steering wheel during

manoeuvres to park or exit a parking space
until the system requests it. Doing so disa-
bles the system during the manoeuvre, re-
sulting in the parking being cancelled.

CAUTION

●

In certain circumstances, the ultrasonic

sensors do not detect objects such as trail-
er tongues, bars, fences, posts or thin trees,
or an open (or opening) rear lid, which
could damage the vehicle.

●

Retrofitting of certain accessories to the

vehicle, such as a bicycle rack, may inter-
fere with the operation of the Park Assist
system and cause damage.

●

The Park Assist system uses as a refer-

ence parked vehicles, curbs and other ob-
jects. Make sure that the tyres and wheels
are not damaged while parking. If necessa-
ry, opportunely interrupt the parking ma-
noeuvre to avoid damaging the vehicle.

●

The ultrasound sensors on the bumper

may be damaged or shifted in the event of
a collision, for example, when entering or
exiting a parking space.

●

If you use high-pressure or vapour equip-

ment to clean the ultrasound sensors, do

not apply it directly unless very briefly and
always from a distance of more than 10 cm.

●

A registration plate or plate holder on the

front with larger than the space for the reg-
istration plate, or a registration plate that is
curved or warped can cause:

–

False detections.

–

The sensors to lose visibility.

–

Cancellation of the parking manoeuvre
or defective parking.

●

If one of the ultrasonic sensors is dam-

aged, the area corresponding to that group
of sensors (front or rear) is deactivated and
cannot be activated until the fault is cor-
rected. However, you can still use the sen-
sors of the other bumper as per usual. If
there is a fault in the system, consult a spe-
cialist workshop. SEAT recommends visiting
a SEAT dealership for this.

Note

●

In order to guarantee good system oper-

ation, keep the ultrasound sensors of the
bumper clean, free of snow or ice, and do
not cover them with adhesives or other ob-
jects.

●

Certain sources of noise, such as rough

asphalt or paving stones and the noise of
other vehicles can induce the Park Assist
system or ParkPilot to give erroneous warn-
ings. The presence of metal objects can al-
so affect the manoeuvre.

●

In order to become familiar with the sys-

tem and its functions, SEAT recommends
that you practice operating the Park Assist
system in an area where there is not too
much traffic or in a car park.

Description of the parking assist
system

The components of the Park Assist system
are the ultrasonic sensors located in the front
and rear bumpers, the



to switch the sys-

tem on and off and the messages on the in-
strument cluster display.

Prerequisites for parking

●

The traction control (TCS) must be switch-

ed on

›››

●

Speed when passing next to the parking

space: do not exceed approx.

50 km/h (31

mph)

●

Keep a distance between

0.5 and 2.0 me-

tres

when driving past the parking space.

●

Space length (parallel parking):

vehicle

length + 0.8 meters

●

Space width (angle parking):

vehicle width

+ 0.8 meters

●

Do not exceed approximately

7 km/h

(4 mph)

when parking. The vehicle will per-

form an automatic braking only once if this
speed is exceeded. If you exceed the speed

280

Help with parking and manoeuvring

more than once, the Park Assist system
switches off.

Requirements for leaving the parking
space (only for parallel parking)

●

The traction control (TCS) must be switch-

ed on

›››

●

Space length:

length of the vehicle + 0.5

metres

●

Do not exceed approximately

7 km/h

(4 mph)

when exiting the parking space.

Prematurely stopping or automatically in-
terrupting the manoeuvres for parking or
exiting a parking space

Park Assist interrupts the manoeuvres for
parking or exiting a parking space in any of
the following cases:

●

Press button



in the infotainment system,



> Assistants > Parking > Park assist sys-

tem

●

When exceeding a speed of approximately

7 km/h (4 mph) more than once.

●

The driver takes control of the steering

wheel.

●

The parking manoeuvre does not end within

6 minutes from the activation of automatic
steering.

●

There is a fault in the system (the system is

temporarily unavailable).

●

The TCS is disconnected.

●

TCS or ESC intervene with regulation.

●

The driver door is opened.

To restart the manoeuvre it is necessary that
none of these things occur and that the



button on the infotainment system is pressed
again.

Special characteristics

The Park Assist system is subject to certain
limitations inherent to the system. For exam-
ple, it is therefore not possible to enter or exit
a parking space on sharp bends.

While entering or exiting a parking space, a
brief signal sounds to prompt the driver to
change between forward and reverse gears
(depending on the case). In successive ma-
noeuvres, the assistant tells the driver to
change gears, at the latest, when the contin-
uous audible signal is given (object present at
a distance of ≤30 cm) by Park Pilot.

When the Park Assist system turns the steer-
ing wheel with the vehicle stationary, the in-
strument panel also displays the symbol



Keep the brake pedal depressed while the
symbol remains on the dash panel display to
turn the wheels with the vehicle stopped. This
way, the system will require fewer manoeu-
vres to complete the parking action.

Trailer mode

The Park Assist system cannot be switched
on if the factory-fitted towing bracket

›››

page 294

is electrically connected to a

trailer.

After changing a wheel

If, after changing a wheel, the vehicle stops
entering and exiting parking spaces correct-
ly, the circumference of the new wheel may
be different and the system may need to
adapt to it. The adaptation is automatic and
takes place during driving. Making turns slow-
ly and in both directions (20 km/h [12 mph])
for a few minutes may contribute to this
adaptation process

›››

in Introduction on

page 279

281

Driving

Selecting a parking type

Fig. 200

On the instrument panel display:

view of the parking assist system with reduced

view.

Fig. 201

On the Infotainment system screen.:

indication of parking modes.

Park assist has the following 6 parking types:

Reverse parallel parking.
Reverse angle parking.
Forward angle parking.
Reverse parallel parking without driving
past first: “Help me”.
Forward parking in a parking bay without
driving past first.
Reverse parking in a parking bay without
driving past first.

Selecting a parking type after passing in
front of the space

After activating the Park Assist system and af-
ter detecting a parking space, the display on
the instrument panel proposes a parking
type. The Park Assist system selects the park-
ing type automatically. The selected type is
displayed on the instrument cluster display

›››

Fig. 200

and on the infotainment system

display.

●

The necessary conditions to park with Park

Assist have to be met

›››

page 280

●

Press button



in the infotainment system,



> Assistants > Parking > Park assist sys-

tem

●

When the system is switched on, the sym-

bol



on the infotainment system display is

highlighted. Additionally, the selected parking
type is shown on the instrument panel dis-
play. You can change the type of parking on
the infotainment system display.













●

If there are more spaces available, another

space can be selected by clicking on it on
the infotainment system display.

●

Follow the instructions displayed on the in-

strument panel while paying attention to traf-
fic and drive the vehicle past the parking
space.

Reverse parallel parking without driving
past first (type



)

With this type of parking



, press button



so that the system resolves the parking that
has already been started. The system will on-
ly switch on if sufficient progress has been
made with the manoeuvre (the side sensor
must be able to detect the reference vehicle).
If it is impossible to successfully complete the
manoeuvre that has been started, the system
itself will drive out of the parking space be-
fore starting parking in a similar way to type



Special case of driving forwards into a
type



parking bay without driving past

first

●

The necessary conditions to park with Park

Assist have to be met

›››

page 280

●

Move forward towards the parking space

while paying attention to traffic and stop the
vehicle with the front part partially inside the
parking space.

282

Help with parking and manoeuvring

●

Press button



once in the infotainment

system,



> Assistants > Parking > Park as-

sist system

●

When the system is switched on, the sym-

bol



on the infotainment system display is

highlighted. Additionally, the selected parking
mode is shown on the instrument panel dis-
play without reduced display.

●

Release the steering wheel

›››

in Intro-

duction on page 280

Parking with the parking assist system

Fig. 202

On the instrument panel display: paral-

lel parking.



Finding a parking space.



Park-

ing position.



Manoeuvring.

Fig. 203

On the instrument panel display: angle

parking.



Finding a parking space.



Parking

position.



Manoeuvring.

Message to move forwards
Your vehicle

Parking space detected
Message to park

Message to press the brake pedal
Progress bar

283

Driving

The necessary conditions have to be met to
park with Park Assist

›››

page 280

and the

parking mode must be selected

›››

page 282

Parking

●

Look at the display on the instrument panel

to see if the space has been detected as “ap-
propriate” and if the correct position for park-
ing has been reached

›››



›››



. The space is considered

“appropriate” if the display on the instrument
panel shows the message to park

●

Stop the vehicle and, after a brief pause,

engage reverse gear,

press the button



the infotainment system,



> Assistants >

Parking > Park assist system

●

Release the steering wheel

›››

in Intro-

duction on page 280

●

Please note the following message:

Inter-

vention in active direction. Watch
your surroundings!

. While you keep watch

around you, carefully start accelerating up to
no more than 7 km/h (4 mph). During the
parking manoeuvre, the system

only

takes

charge of the steering.

You, as the driver,

have to accelerate, engage the clutch if
necessary, change gears and brake.

●

Reverse until the continuous ParkPilot sig-

nal sounds;

OR:

reverse until the indication to

move forward appears on the instrument
panel display

›››



›››



;

OR:

reverse until the

Park Assist fin-

ished

message appears on the instrument

panel display. The progress bar

indicates

the distance to cover

›››

page 284

●

Press the brake pedal until the parking as-

sist system completes the steering wheel
turns;

OR:

until the symbol



goes out on the

instrument panel screen.

●

Select first gear.

●

Move forward until the continuous ParkPilot

signal sounds;

OR:

move forward until the re-

verse indication appears on the instrument
panel display. The Park Assist system steers
the vehicle forward and back until it centres it
in the space

›››



›››



●

For best results, wait at the end of each

manoeuvre until the Park Assist system has
finished turning the steering wheel. The park-
ing manoeuvre ends when a corresponding
message is displayed on the instrument pan-
el and, in some cases, an acoustic signal
sounds.

Progress bars

The progress bar

›››

and

›››
